Matrix MX-FW80 Assembly Manual

IMPORTANT SAFETY INSTRUCTIONS
PROPER USAGE
1. Do not use any equipment in any way other than designed or intended by the manufacturer.
It is imperative that weight stack machines as well as any other MATRIX Fitness Systems, Inc. equipment are used properly
to avoid injury.
2. Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
MATRIX Fitness Systems, Inc.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your local dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over.
This must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping your
liability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
MATRIX Fitness Systems, Inc. will provide service and maintenance training at our corporate facility upon request.
SPECIFIC OPERATING WARNINGS
1. Routinely inspect all accessory clips that join attachments to the machine and replace at the first sign of wear.
2. Use only weight selector pins supplied by MATRIX Fitness Systems, Inc. on weight stacks. Substitutes are forbidden.
3. Belts and cables pose an extreme liability if used when frayed. Always replace any belts and cables at first sign of wear
(consult MATRIX Fitness Systems, Inc. if uncertain).
4. Do not allow users to wear loose fitting clothing while using equipment. It is also recommended to have users' secure long
hair back and up to avoid contact with moving parts.
5. Fully insert weight selector pins. Partial insertion can cause weights to fall unexpectedly.
Never remove selector pin if any weights are suspended. Never attempt to release jammed weights or parts.
PARTS DESCRIPTIONS
B02 SN1102001E Adjustment Pin Assembly 2
B38 MJ4803023K Pull Pin 1
SWP
B39 ME1120001D Spring 1
S45C
B40 MB0258001H Pull Pin Cover 1
C03 MJ2315001B Back Fixing Bracket SPC 6.0t 1
C04 MJ2316001C Front Fixing Bracket SPC 6.0t 1
C05 MJ2901025D Main Support Bracket SPC 1
C10 MJ3915001B Pull Pin Housing SS41 2
C14 MB06D6001C Pull Pin Knob TPR 2
C15 MJ3329002B Wheel Shaft Q235 2
C16 MB0103004F Wheel 2
6002ZZ(SKF)
C17 MD0501002 Bearing 4
S-15
C18 ME0902006 C-Clip 4
M8×1.25P×25L
C19 ME0112132 Screw 4
C20 MB0304026E Molded Rubber Foot 89mm 1
C21 MB0314001A Foot Pad 2
C22 ME0111022 Bolt, Round-Hex Socket M8×1.25P×20L 3
C23 MJ4212001C Axle (SCM-21) 20×144L 1
C24 MB0420001C Grip 31.8×5.0t×105L 1
C25 ME0112161 Screw M10×1.5P×15L 2
10.2× 25×1.5t
C26 ME0502182AB Flat Washer 2
SW10 10.2×18.4×2.5t
C27 ME0501027 Spring Washer 2
LFF-2015
C28 MD0504016 Bushing 4
J01 MJ2304002D Seat Bracket SPC 5.0t 1
J02 MJ2319001C Middle Seat Bracket SPC 5.0t 1
J03 SW3019001C Handle 31.8×3t×154L 1
J04 MJ4213001F Rotation Housing SS41 2
J05 MJ2908003B Attachment Plate SPC 6.0t 2
J06 MJ2320001H Back Bracket SPC 5.0t 1
J08 MJ4214001G Back Rotation Housing SS41 1
J10 MJ2322001D Seat Adjustment Plate SPC 12.0t 1
J11 MJ2323001D Seat Adjustment Bracket SPC 10.0t 1
J14 MJ2325001F Back Adjustment Bracket SPC 10.0t 1
J19 ME0112144 Screw M10×1.5P×25L 12
J20 ME0112159 Screw M8×1.25P×25L 4
J21 ME0104070AB Bolt, Round-Head Allen M8×1.25P×12L 2
J22 ME0502027AC Flat Washer 8.4× 15.5×2.0t 12
J23 ME0501016 Spring Washer SW8 8.2×15.4×2t 12
J25 MB06D3003E Rubber Detent Bolt Cover 2
J27 MB06D4008AA Back Stop 2
J28 MJ4827002D Annodized Grip End Cap, 31mm 1
J29 ME0114060A Set screw M6×1.0P×4L 2
J30 ME0112024AE Screw M8×1.25P×20L 4
V12 ME1201002 Rivet 1/8"×7.5L 2
Z01 ME1007031A Wrench M6×80L 1
Z02 ME1007024A Wrench M5×70L 1
Sep 24, 2004

ASSEMBLY GUIDE

MX-FW80
MULTI ADJUSTABLE BENCH
F I T N E S S S Y S T E M
