OWNERS MANUAL
Versa Single-Station Strength
VS-S42 Seated Triceps Press

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS-S42 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix VS-S42

Summary of Contents for Matrix VS-S42

  • Page 1 OWNERS MANUAL Versa Single-Station Strength VS-S42 Seated Triceps Press...

  • Page 2: Table Of Contents

    Table Of Contents Safety, General Care & Maintenence ..........3 Getting Started (Product Specifications) .......... 5 Assembly Information ................6 Markings ....................7 Parts List ....................8 Installation & Assembly: Value Line Part 1 Weight Stack & User Frame Assembly ......10 Part 2 Cable Assembly ..............

  • Page 3: Safety, General Care & Maintenence

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION It is the sole responsibility of the purchaser of Matrix products to instruct all individuals, whether they are the end user or supervising personnel on proper usage of the equipment. It is recommended that all users of Matrix exercise equipment be informed of the following information prior to its use.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID INJURY! Never allow children on strength training equipment. Teenagers must be supervised at all times while using this equipment.

  • Page 5: Getting Started (Product Specifications)

    GETTING STARTED EXERCISE PLACARD | PRODUCT SPECIFICATIONS | MAINTENANCE CHECKLIST EXERCISE PLACARD PRODUCT SPECIFICATIONS TECH SPECS Overall dimensions 60”L X 42”W X 66”H Light Stack = 564 lbs (256 kg), Heavy Stack = 634 lbs (288 Weight Shipping weight 404 lbs (184 kg) WARRANTY (Valid in USA only) Frame (not coatings) 10 years...

  • Page 6: Assembly Information

    UNPACKING Thank you for purchasing a Matrix product. This machine is an EN957-1 and EN957-2 compliant Class S product. Your Ma- trix product is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the machine.

  • Page 7: Markings

    MARKINGS WARNING LABEL LOCATIONS...

  • Page 8: Parts List

    Parts List DESCRIPTION M10 X 125L Socket Head Cap Screw M10 Flat Washer Wide Cupped Flange M10 Nylock Nut Lower Connecting Tube M10 X 20L Socket Head Cap Screw Upper Connecting Tube User Frame Weight Stack Frame M10 X 50L Socket Head Cap Screw M8 X 50L Socket Head Cap Screw M8 Flat Washer M8 Nylock Nut...
  • Page 9 Parts List DESCRIPTION Front Shroud Rear Shroud Large M8 Flat Washer (Ø20 mm) Top Cap Top Cap Cover PREMIUM KIT COMPONENTS Wing Rep Counter Towel Hook Premium Grips Premium Pullpin Seat Assist Gas Shock...

  • Page 10: Installation & Assembly: Value Line Part 1 Weight Stack & User Frame Assembly

    ASSEMBLY PART 1: STACK & USER FRAME ASSEMBLY STEP 1 | WEIGHT STACK TO USER FRAME INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M10 X 125L SHC M10 Flat Washer Wide Cupped Flange M10 Nylock Nut Lower Connecting Tube M10 X 20L SHC After weight plates have been assembled, torque Upper Connecting Tube...

  • Page 11: Part 2 Cable Assembly

    ASSEMBLY PART 2: CABLE ASSEMBLY STEP 1 | CABLE ROUTING & ASSEMBLY INSTRUCTIONS & NOTES Cable must be routed as shown below.

  • Page 12: M8 Flat Washer

    ASSEMBLY PART 2: CABLE ASSEMBLY STEP 2 | CABLE ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M10 Flat Washer M10 Nylock Nut M10 X 50L SHC M8 X 50L SHC M8 Flat Washer M8 Nylock Nut Torque M10 hardware to: 77N-m/57 ft-lbs. Cable Tie Rod End Left side Mounting Plate...

  • Page 13: Part 3 Arm Assembly

    ASSEMBLY PART 3: ARM ASSEMBLY STEP 1 | RIGHT ARM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M10 X 20L SHC Axle Right Arm Assembly Key (7 X 8 mm) Ø M10 Flat Washer ( 35 mm) Torque hardware to: 77 N-m/57 ft-lbs.

  • Page 14: Left Arm Assembly

    ASSEMBLY PART 3: ARM ASSEMBLY STEP 2 | LEFT ARM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M10 X 20L SHC Ø M10 Flat Washer ( 35 mm) Left Arm Assembly Torque hardware to: 77 N-m/57 ft-lbs.
  • Page 15 ASSEMBLY PART 3: ARM ASSEMBLY STEP 3 | ARM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M8 Flat Washer M8 Nylock Nut M8 X 35L SHC Raise left arm first to start assembling hardware. Raise right arm to complete assembly. Torque M8 hardware to: 39 N-m/29 ft.-lbs.

  • Page 16: Part 4 Counter Weight Assembly

    ASSEMBLY PART 4: COUNTER WEIGHT ASSEMBLY STEP 1 | COUNTER WEIGHT ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M8 Flat Washer M8 X 20L SHC Counter Weight Install the user frame hardware as shown. Torque Hardware to: 39 N-m/29 ft/lbs.

  • Page 17: Part 5 Handlebar Assembly

    ASSEMBLY PART 5: HANDLEBAR ASSEMBLY STEP 1 | HANDLEBAR ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M8 X 25L SHC Handlebar Sleeve 26 28 Install the user frame hardware as shown. Torque Hardware to: 39 N-m/29 ft/lbs.

  • Page 18: Part 6 Pad Assembly

    ASSEMBLY PART 6: PAD ASSEMBLY STEP 1 | BACK PAD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M10 Flat Washer Back Pad M10 X 75L SHC Torque item to: 57 N-m/41 ft-lbs.

  • Page 19: Bottom Pad

    ASSEMBLY PART 6: PAD ASSEMBLY STEP 2 | PAD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY Bottom Pad M10 X 20L Hex Bolt Torque item to: 57 N-m/41 ft-lbs.

  • Page 20: Part 7 Plastics Assembly

    ASSEMBLY PART 7: PLASTICS ASSEMBLY STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY Front Shroud Rear Shroud (Not shown) Position hangers in their lowest position Install the weight stack shrouds as shown.
  • Page 21 ASSEMBLY PART 7: PLASTICS ASSEMBLY STEP 2 | TOP CAP ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY M8 X 25L SHC M8 Flat Washer (20 mm diameter) Top Cap Install the top cap onto the weight stack as shown. Torque to 17 N-m/147 in-lbs. Position top cap so that the instructional placard faces the user.
  • Page 22 ASSEMBLY PART 7: PLASTICS ASSEMBLY STEP 3 | TOP CAP COVERS INSTRUCTIONS & NOTES DESCRIPTION QUANTITY Top Cap Cover Install the top cap covers.

  • Page 23: Part 8 Cable Adjustment

    ASSEMBLY PART 8: CABLE ADJUSTMENT STEP 1 | CABLE ADJUSTMENT INSTRUCTIONS & NOTES Cable tension is adjusted by raising or lowering pulley as shown. Note: Nuts for adjustable pulley must be on inside towards weight plates.

  • Page 24: Part 9 Premium Kit Assembly

    ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANTITY Wing Rep Counter Towel Hook Premium Grips Premium Pullpin Seat Assist Gas Shock I M PO RTA NT NOTI CE PLEASE NOTE: Be sure to remove the insulating sheet when installing the Rep Counter.

  • Page 25: Weight Stack Frame

    ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 1 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES Rep Counter - Magnet 1. Remove the (2) top cap covers using a flat blade screw driver. 2. Remove the (4) M8 bolts and 20 mm diameter washers that hold the top cap to the weight stack frame.
  • Page 26 ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 2 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES Rep Counter - Sensors 1. Assemble Rep Counter sensor base using (4) screws included with the kit. 2. Assemble (3) sensors located per machine chart shown below. Thread zip ties through holes to secure cables Route wires in groove...
  • Page 27 ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 3 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES Rep Counter 1. Remove and discard hole caps using caution not to scratch the paint. 2. Attach plug to Rep Counter. 3. Assemble Towel Hook (3P) and Rep Counter (2P) using the M8 X 35L SHC bolts provided.
  • Page 28 ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 4 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES Wing Assemble the wing (1P) as shown using the M8 hardware provided with the kit. Tighten to 39N-m (29 ft-lbs.).
  • Page 29 ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 5 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES ASG Grips 1. Remove cap screws. 2. Slide out basic arm assemblies 3. Assemble Premium Grip assemblies 4. Replace cap screws to secure new grip assemblies.
  • Page 30 ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 6 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES Pull Pin Remove the pull pins using an adjustable wrench, and replace with the Premium pull pin. (5P).
  • Page 31 ASSEMBLY PART 9: PREMIUM KIT ASSEMBLY STEP 6 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES Gas Shock Raise the seat to the highest position before adding gas shock (6P) Disassembly and assembly for both ends of shock (Only one end is shown)
  • Page 32 Matrix Fitness 1600 Landmark Drive Cottage Grove WI 53527 matrixfitness.com Toll-free 866.693.4863 Facsimilie 608.839.8687 Versa Seated Triceps Press Owners Guide Rev.1.3 Copyright© 2016 Matrix Fitness...
