- Page 1 MG-PL Series Service Manual...
- Page 2 Product Browse...
-
Page 9: Table Of Contents
Contents CHAPTER 1: SERIAL NUMBER LOCATION 1.1 Serial Number Location ......................10 CHAPTER 2: ASSEMBLY INSTRUCTION 2.1 Tools Required For Assembly ....................17 CHAPTER 3: MAINTENANCE & TROUBLESHOOTING 3.1 Plate Loaded & Free Weight Benches Maintenance ............... 18 3.2 Troubleshooting ........................18 CHAPTER 4: PART REPLACEMENT GUIDE 4.1 Plastic Bushing Replacement .................... -
Page 10: Chapter 1: Serial Number Location
CHAPTER 1: Serial Number Location 1.1 Serial Number Location MG-PL12 MG-PL13... - Page 11 CHAPTER 1: Serial Number Location MG-PL14 MG-PL15...
- Page 12 CHAPTER 1: Serial Number Location MG-PL23 MG-PL33...
- Page 13 CHAPTER 1: Serial Number Location MG-PL34 MG-PL50...
- Page 14 CHAPTER 1: Serial Number Location MG-PL62 MG-PL70...
- Page 15 CHAPTER 1: Serial Number Location MG-PL71 MG-PL76...
- Page 16 CHAPTER 1: Serial Number Location MG-PL77 MG-PL79...
-
Page 17: Chapter 2: Assembly Instruction
CHAPTER 2: Assembly Instruction 2.1 TOOLS REQUIRED FOR ASSEMBLY Note: For additional assembly information, please refer to the Assembly Guide. -
Page 18: Chapter 3: Maintenance & Troubleshooting
3.2 Troubleshooting Due to the simple structure of the PL series, most issues are easily recognized and can be corrected by replacing the related part. Please contact the Matrix Fitness customer service team with any questions. -
Page 19: Chapter 4: Part Replacement Guide
CHAPTER 4: Part Replacement Guide 4.1 PLASTIC BUSHING REPLACEMENT 1) Loosen the screw at the end of the bar. 2) Replace the plastic bushing and lock the screw. -
Page 20: Swing Arm Replacement
CHAPTER 4: Part Replacement Guide 4.2 SWING ARM REPLACEMENT 1) Loosen the screw on the swing arm. 2) Replace the swing arm and secure it with a bolt. -
Page 21: Pad Replacement
CHAPTER 4: Part Replacement Guide 4.3 PAD REPLACEMENT 1) Loosen the screw and remove the pad. 2) Replace new pad and lock it with bolts. -
Page 22: Leg Adjustment Cover Replacement
CHAPTER 4: Part Replacement Guide 4.4 LEG ADJUSTMENT COVER REPLACEMENT 1) Remove the plastic end cap and interval ring. 2) Replace the new leg adjustment cover. 3) Assembly the interval ring and the plastic end cap. -
Page 23: Hand Grip Foam Replacement
CHAPTER 4: Part Replacement Guide 4.5 HAND GRIP FOAM REPLACEMENT 1) Loosen the screws on the end cap, and then remove the end cap. 2) Cut off the original foam and position replacement foam on the hand grip. 3) Fix the end cap and lock it. -
Page 24: Bushing Replacement
CHAPTER 4: Part Replacement Guide 4.6 BUSHING REPLACEMENT 1) Loosen the screws and remove the pull-pin. 2) Remove the top cap and take off the bushing. 3) Position the new bushing and fix it.
