Table Of Contents Safety, General Care & Maintenence ....................3 Getting Started (Product Specifications) ..................5 Assembly Information ........................6 Parts List............................7 Installation & Assembly: Value Line Part 1 Weight Stack & User Frame Assembly ............... 9 Part 2 Seat Assembly ......................13 Part 3 Arm Assembly ......................
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION It is the sole responsibility of the purchaser of Matrix products to instruct all individuals, whether they are the end user or supervising personnel on proper usage of the equipment. It is recommended that all users of Matrix exercise equipment be informed of the following information prior to its use.
Page 4
IMPORTANT SAFETY INSTRUCTIONS WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID INJURY! Never allow children on strength training equipment. Teenagers must be supervised at all times while using this equipment.
GETTING STARTED EXERCISE PLACARD | PRODUCT SPECIFICATIONS | MAINTENANCE CHECKLIST EXERCISE PLACARD PRODUCT SPECIFICATIONS TECH SPECS Maximum User Weight 136 kg / 300 lbs. Maximum Training Weight 109 kg / 240 lbs. Product Weight 307 kg / 675 lbs. Overall Dimensions (L x W x H) 155.4 x 106.8 x 129.6 cm / 61.2"...
Thank you for purchasing a Matrix product. This machine is an EN957-1 and EN957-2 compliant Class S product. Your Matrix product is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the machine.
Parts List DESCRIPTION User Frame Arm Axle M10 Flat Washer M10 X 75L Socket Head Cap Screw Upper Connecting Tube M10 Saddle Washer M10 X 30L Hex Head Bolt Lower Connecting Tube Weight Stack M10 Nylock Nut M10 X 140L Socket Head Cap Screw M10 X 45L Socket Head Cap Screw Pulley Cable...
Parts List DESCRIPTION M8 Flat Washer Pulley Spacer M5 Shoulder Bolt M5 Nylock Nut Counter Weight M8 X 30L Special Screw Sleeve Handlebar M10 X 75L Button Head Cap Screw Back Pad Assembly M10 X 20L Hex Bolt Left Front Shroud Right Front Shroud Rear Shroud M8 X 60L Socket Head Cap Screw...
ASSEMBLY PART 1: USER FRAME ASSEMBLY STEP 1 | USER FRAME INSTRUCTIONS & NOTES DESCRIPTION QUANITY User Frame Arm Axle • Apply red Loctite 262 to axle threads and fully tighten.
ASSEMBLY PART 2: SEAT ASSEMBLY STEP 1 | SEAT LINK ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY *Note: Shoulder M8 X 25L SHC Press seat assembly Medium Pivot Cap is shown - but steps Seat Link and components Axle are identical for the Spring Triceps Press Seat...
ASSEMBLY PART 2: SEAT ASSEMBLY STEP 2 | SEAT ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M8 X 25L SHC Medium Pivot Cap Seat Link Axle Spring Rotate seat to engage pull pin Assemble upper axles, links and pivot caps Tighten to 39 N-m/29 ft-lbs.
ASSEMBLY PART 3: ARM ASSEMBLY STEP 1 | LEFT AND RIGHT* ARM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X15L SHC Small Pivot Cap Snap Ring Right Arm Wave (Spring) Washer Left Arm *Only right arm assembly is shown Apply blue Loctite 242 and tighten to 77 N-m/57 ft-lbs.
Page 16
ASSEMBLY PART 3: ARM ASSEMBLY STEP 2 | PULLEY ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 Nylock Nut Pulley Cable Large Pivot Cap M8 Nylock Nut M10 X 65L SHC M8 X 20L SHC M8 Flat Washer Pulley Spacer Torque M8s to: 39 N-m/29 ft-lbs. Torque M10 to 77 N-m/57 ft-lbs.
Page 17
ASSEMBLY PART 3: ARM ASSEMBLY STEP 3| CABLE ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M5 Shoulder Bolt M5 Nylock Nut Raise arms up to attach cable end and torque to 16 N-m/142 in-lbs.
Page 18
ASSEMBLY PART 3: ARM ASSEMBLY STEP 4 | COUNTER WEIGHT ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M8 X 20L SHC M8 Flat Washer Counter Weight Torque to: 39 N-m/29 ft-lbs.
Page 19
ASSEMBLY PART 3: ARM ASSEMBLY STEP 5 | HANDLEBAR ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M8 X 30L Special Screw Sleeve Handlebar *Only right arm assembly is shown Torque to: 39 N-m/29 ft-lbs.
ASSEMBLY PART 4: PAD ASSEMBLY STEP 1 | BACK PAD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 75L BHC Back Pad Assembly Install the pad as shown. Tighten to 27 N-m/20 ft-lbs.
Page 21
ASSEMBLY PART 4: PAD ASSEMBLY STEP 2 | BOTTOM PAD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 20L Hex Bolt Install the pad as shown. Tighten to 27 N-m/20 ft-lbs.
ASSEMBLY PART 5: PLASTICS ASSEMBLY STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY Left Front Shroud Right Front Shroud Rear Shroud Install the weight stack shrouds as shown.
Page 23
ASSEMBLY PART 5: PLASTICS ASSEMBLY STEP 2 | TOP CAP ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M8 X 60L SHC Top Cap Install the top cap and connect rep counter plug as shown. Torque to 17 N-m/147 in-lbs. Position top cap so Rep Counter faces the user. I M PO RTA NT NOTI CE PLEASE NOTE: Be sure to remove the insulating...
