Ruijie RSR30-X-SPU10 Hardware Installation And Reference Manual page 7

Mark
SFP
1-8F
USB
FUNC
U-Console
Note: The Console and U-Console share the same port and either is available at a time. The port for mini USB is
the mini USB-B connector and only the 5-pin mini-B connector or compatible connector cable can be used.
To use the U-Console port, install the dedicated driver on the console. For details, see the RGOS Configuration
Guide.
USB Port
RSR30-X-SPU10 provides one USB port. This port allows routers to read configurations from the USB device or save
configurations to the USB device. Ruijie RGOS operating system can be stored in the USB device. You can press the
FUNC button to upgrade the operating system.
Features
Interface standard
Connection component
Interface mode
Hot swapping
Hot swapping of the USB device must be operated according to the "Reliability Configuration" section in the
RGOS Configuration Guide. Hot swapping is not allowed before you run the USB remove command.
The USB device here mainly refers to a USB flash disk.
SD Slot
RSR30-X-SPU10 provides one SD slot. Ruijie RGOS operating system can be stored on the SD card. You can press
the FUNC button to upgrade the operating system.
Features
Note
Status indicator for
optical ports 1F to 8F
USB status indicator
One-click reset/upgrade
button
U-Console port
Description
at 1000 Mbps.
Solid yellow: The port is connected at 10/100 Mbps.
Blinking yellow: The port is transmitting or receiving data
at 10/100 Mbps.
Off: The port is not connected.
Solid green: The port is connected at 1000 Mbps.
Blinking green: The port is transmitting or receiving data
at 1000 Mbps.
Solid yellow: The port is connected at 100 Mbps.
Blinking yellow: The port is transmitting or receiving data
at 100 Mbps.
Off: The USB device is not installed, is not properly
inserted, or can be unplugged.
Blinking green: The system is accessing the USB device.
Solid green: The device is operational.
See the description of the FUNC button in the following
section.
Connected to the console through a USB cable.
Settings
USB 2.0
USB Host
Host
Support
Settings
·
