Ruijie RSR30-X-SPU10 Hardware Installation And Reference Manual page 10

Dimensions (W x H x
D) (mm)
Weight
1.3.2 PD240I
Product Image
Figure 1-5 Appearance of Two RG-PD240I Power Supply Modules
Indicators
Indicator
Indicator on the panel
Specifications
Table 1-1 Technical Specifications of the
Module Model
Rated Voltage Range
Power
Hot Swapping
Power Redundancy
Overvoltage
Protection
Overcurrent Protection
Power Supply Mix
Power Cord
Requirement
Dimensions (W x H x
D) (mm)
Weight
N+1 power redundancy: In terms of a system requiring N power supply modules, if a module fails, the backup
module starts to operate immediately. In this way, system reliability is guaranteed.
203.3mm x 81mm x 40mm (Excluding the connecting finger and the handle.)
236.9mm x 81mm x 40mm (Including the connecting finger and the handle.)
0.6kg
Description
Green: Power output is normal.
Red: Power output is abnormal.
Off: There is NO power output due to faulty power supply module or no inserted cable.
M5000E-AC60 Module
RG-PD240I
-36VDC- -72VDC
60W
Supported
Supporting 1+1 power redundancy
18VDC
5.5A-10A
Not supported
Power cord supplied with the RG-PD240I router
203.3mm x 81mm x 40mm (Excluding the connecting finger and the handle.)
236.9mm x 81mm x 40mm (Including the connecting finger and the handle.)
0.6kg
·
