INSTRUCTION MANUAL
INSTRUCTION MANUAL
SIMRAD HS52
GPS compass and DGPS navigator
20222360E
English
i
20222360 / E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS52 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simrad HS52

Summary of Contents for Simrad HS52

  • Page 1 INSTRUCTION MANUAL INSTRUCTION MANUAL SIMRAD HS52 GPS compass and DGPS navigator 20222360E English 20222360 / E...
  • Page 2 Simrad HS52 GPS compass and DGPS navigator Document revisions Date Written by Checked by Approved by 27.04.2006 22.06.2006 02.08.2006 05.09.2006 16.01.2007 Document history Rev. A Original issue. Rev. B Documentation of the PSXN,20 and RRE format included. Description of system performance at alarms has been changed Rev.
  • Page 3 About this manual This manual is intended as a reference guide for operating, installing and maintaining the HS52 Heading Sensor. Please take time to read this manual to get thorough understanding of the operation and system components. In this manual the following notations are used:...
  • Page 4 Simrad HS52 GPS compass and DGPS navigator THIS PAGE INTENTIONALLY LEFT BLANK 20222360 / E...

  • Page 5: Table Of Contents

    INSTRUCTION MANUAL Contents INTRODUCTION ..............1 1.1 HS52 System Components ..........1 1.2 Definitions, Abbreviations and Acronyms ......3 Definitions ...............3 Abbreviations and Acronyms..........3 TECHNICAL SPECIFICATIONS ...........5 2.1 Health, Environment and Safety ........5 2.2 Restrictions in Guarantee ..........5 2.3 Restrictions in Use............5 2.4 Performance Data ............
  • Page 6 Simrad HS52 GPS compass and DGPS navigator Waterproofing of Connectors ..........14 3.5 Display Unit..............15 Location of the Unit ............15 Panel Mounting............... 15 Bracket Mounting (option)..........16 Display Unit Cable............17 3.6 Processing Unit ............18 Cable Connections ............18 Connecting to Simrad Equipment ........
  • Page 7 INSTRUCTION MANUAL 4.6 Operation..............52 Adjust Backlight on Display ..........52 SBAS Corrections............52 Height Aided GPS Position ..........53 MAINTENANCE ..............55 5.1 General ..............55 5.2 Periodic Maintenance ...........55 Sensor Unit..............55 Processing Unit............... 56 Display Unit ..............56 5.3 Repairs and Modifications ..........57 Replacing Damaged Cables ..........
  • Page 8 Simrad HS52 GPS compass and DGPS navigator THIS PAGE INTENTIONALLY LEFT BLANK viii 20222360 / E...

  • Page 9: Introduction

    INTRODUCTION 1. INTRODUCTION HS52 System Components The Simrad HS52 provides position and true heading output with no moving parts. The HS52 combines several vessel instruments with compact navigation package; gyrocompass, GPS receiver equipment, speed log and Rate Of Turn indicator.
  • Page 10 GPS elements of the system insure accurate, continuous and robust heading information. The Processing unit includes configurable output serial lines and Ethernet connections making it easy to distribute HS52 data to multiple users on board the vessel. The HS52 requires no scheduled maintenance or re-calibration.

  • Page 11: Definitions, Abbreviations And Acronyms

    Circular Error Probability Course Over Ground DGPS Differential GPS European Space Agency Federal Aviation Administration, USA HS52 Display Unit Estimated Position Error Global Positioning System A standard NMEA message including GPS satellite ID numbers, PDOP, HDOP and VDOP HDOP Horizontal Dilution Of Precision...
  • Page 12 Simrad HS52 GPS compass and DGPS navigator Positional Dilution Of Precision. A three dimensional geometry PDOP only, dependent on accuracy figure. 1PPS One Pulse Per Second PSXN20 A proprietary NMEA message including position, height and heading quality information HS52 Processing Unit...

  • Page 13: Technical Specifications

    Restrictions in Guarantee The liability of the manufacturer is limited to repair of the HS52 only, and excludes consequential damages such as customer's loss of profit or damage to other systems traceable back to HS52 malfunction.

  • Page 14: Performance Data

    Excessive multipath, GPS signal obstructions or interference may reduce the performance. The HS52 Sensor unit includes two 16-channel GPS receivers. Frequency GPS L1 1575.42 MHz CA code. The position data As specified by GPS SPS Performance Standards of October 2001...

  • Page 15: Physical Dimensions

    TECHNICAL SPECIFICATIONS output from the system is referred to the centre of the Sensor unit both horizontally and vertically. Physical Dimensions Sensor Unit Width ..............850 mm (33.5 in.) Height: ..............205 mm (8.1 in.) Depth: ...............262 mm (10.3 in.) Weight: ..............8 kg (17.6 lbs.) Color: ...................White Dimensional drawing............Page 64 Display Unit...

  • Page 16: Processing Unit

    Simrad HS52 GPS compass and DGPS navigator Processing Unit Width: ...............287 mm (11.3 in.) Height: ..............203 mm (8 in.) Depth: ..............60 mm (2.4 in.) Weight: ..............1.3 kg (2.9 lbs.) Color: ................... Black Dimensional drawing............Page 65 Power Processing Unit Nominal Voltage:....12 or 24 VDC in range 10 to 31 VDC Power consumption: .............15 W...

  • Page 17: Processing Unit

    TECHNICAL SPECIFICATIONS Processing Unit IEC 60945 Category: ............. Protected Enclosure material: ......Plastic/Anodized aluminum Enclosure protection: ............IP-44 Operating temperature range: ... -25 to +55ºC (-13 to 131°F) Storage temperature range: ....-25 to +60ºC (-13 to 140°F) Safe distance to standard compass:......0.3 m (1.0 ft) Cable Processing Unit to Sensor Unit Cable Type: ............2x2x0.5 mm...
  • Page 18 Ashtech format RRE. See page 69 for description of these formats. • Radar output on the AD-10 format (Simrad and Furuno radar compatible) and a 1PPS signal. • 1 Hz. An NMEA ZDA message that is output at 1 Hz interval and according to IEC 61162-1.

  • Page 19: Installation

    RF or high current, such as VHF and SSB transmitters, battery charges/generators and winches. Grounding All units in the HS52 system use the Processing unit as a common ground/shield connection. The Processing unit should therefore have a proper ground connection to the hull/bonding system.

  • Page 20: Sensor Unit

    Simrad HS52 GPS compass and DGPS navigator Sensor Unit Location of the Unit The Sensor unit is the most important part of the HS52 system, and great care should be taken when deciding the mounting location. The space above the Sensor unit has to be free of obstructions of any kind.

  • Page 21: Mechanical Installation

    INSTALLATION Mechanical Installation The Sensor unit may be mounted in the mast or directly on the deck. The dimensional drawing for the Sensor unit on page 64 shows dimensions and internal distance for the mounting holes and the cable outlet. If necessary, a user-made holder may be used as shown on the figure when installing the unit.

  • Page 22: Waterproofing Of Connectors

    Simrad HS52 GPS compass and DGPS navigator If the Sensor unit connector needs to be reconnected to the cable, the wiring for the cable within the Sensor unit connector is as follows: Sensor Unit Cable Wire Signal Description Connector Pin no.

  • Page 23: Display Unit

    Two mounting methods may be used when panel mounting the HS52 Display unit. A drilling template, part no. 22084883, is supplied with the HS52 documentation. Use this template when making panel cut- out and drilling holes. 1. Remove the front panel corners.

  • Page 24: Bracket Mounting (Option)

    Simrad HS52 GPS compass and DGPS navigator 1. Remove the front panel corners. Gasket 2. Use the template and drill hole(s) only for the connectors. 3. Place the 7.5 mm gasket (part no. 22086029) between panel and unit, correctly oriented (see marking on gasket).

  • Page 25: Display Unit Cable

    The connector is of crimp type. It can be easily disassembled, if desired for ease of installation. The extracting tool (p.no. 44161792) may be ordered from Simrad. HOW TO REMOVE PINS: Extraction tool...

  • Page 26: Processing Unit

    Simrad HS52 GPS compass and DGPS navigator Processing Unit The Processing unit is not waterproof and should be mounted vertically in a protected place. Reserve sufficient space below the unit to allow insertion for cable connections. It is recommended that ventilation or air conditioning is provided in order to keep the ambient operating temperature below +55ºC (+130ºF).
  • Page 27 INSTALLATION 2. Strip about 3 cm (1.2") of the cable's insulation and pull the screen backward to cover the insulation. Position the straps as shown in the drawing below and tighten well to make sure the screen has good contact with the chassis. 3.
  • Page 28 Simrad HS52 GPS compass and DGPS navigator Green ALARM Yellow POWC P200 Display White BUS+ Unit Brown BUS- Pink Grey P201 Sensor COMM+ Unit COMM- P210 Used Ethernet RJ45 J600 Used Used 232 OUT P202 Data 422- OUT Out 1...

  • Page 29: Connecting To Simrad Equipment

    All equipment using NMEA signal is connected to 232 OUT and GND, alternatively to 422– OUT and 422+ OUT on P202, P203 or P204. After the equipment is connected to HS52, the data output line has to be configured as described in Data Output on page 31.
  • Page 30 Simrad HS52 GPS compass and DGPS navigator J50/J300 Junction Unit HS52 J50 / J300X PROCESSING UNIT JUNCTION UNIT P202, P203 P204 232 OUT RX2+ 422- OUT 422+ OUT RX2- NI300X HS52 NI300 PROCESSING UNIT JUNCTION UNIT P202, P203 P204 232 OUT...

  • Page 31: 1Pps Signal Connection

    RGC12 Gyro Compass HS52 RGC12 PROCESSING UNIT TERMINAL BOARD P202, P203 P204 232 OUT GRXL 422- OUT 422+ OUT GRXH Simrad RA40/RA50 Radar HS52 RADAR PROCESSING UNIT P208 AD10_C GYRCK+ AD10_D GYRCK+ AD10_GND GYRCK- GYRCK- Note! Requires the optional 36-pins connector 72099 for the Radar.

  • Page 32: Zda 1 Hz Message

    Simrad HS52 GPS compass and DGPS navigator is possible to output 1PPS time tag messages from HS52. This message is the ZDA 1 Hz format and is selectable as output format in the Data Output 1 and 2 menu. Select 1PPS as clock data format in the General setup menu to activate 1PPS signal output on the P208 connector.

  • Page 33: External Alarm

    To comply with the IMO Transmitting Heading Device type approval (not mandatory for GPS Receiver Equipment approval), the Simrad HS52 has to be connected to an external alarm. This since the acoustic alarm in the Display unit is not within the required minimum level of 75 dB. Therefore the Processing unit has built-in alarm functionality.

  • Page 34: Software Setup Procedure

    Software Setup Procedure This chapter describes a number of basic installation settings that must be performed as part of the Simrad HS52 installation. Some of these settings may also need to be changed during operation. In addition to the basic installations settings, a number of advanced setting are available.

  • Page 35: Display Adjustments

    INSTALLATION The arrow buttons are also used to return from a submenu to the SETUP menu. Note! Activate and Discard selection together with the rotary knob are used to exit the SETUP menu: changes are accepted by using Activate, and all changes are erased when selecting Discard. Example: The following example shows how to change the ROT Max value in the Display adjustment submenu using the keys and...

  • Page 36: Differential Corrections

    Simrad HS52 GPS compass and DGPS navigator Differential Corrections The signal cable with the differential corrections is connected to the terminal block P207 on the Processing unit. If data from more than three stations are available on the input serial line, the nearest three stations are used.

  • Page 37: Sbas Setup

    INSTALLATION For a Sensor unit with internal IALA beacon receiver built-in (not available for HS52 due to IMO type approval) the mode and frequency for the built-in beacon receiver can be set under the title “Internal DGPS”. For Sensor units with internal IALA beacon receiver the setting in Internal DGPS is as follows: •...

  • Page 38: 3.10 Advanced Software Setup Procedure

    SBAS corrections, see page 52. 3.10 Advanced Software Setup Procedure The Simrad HS52 includes a number of advanced installation settings that may need to be changed to optimize the installation onboard the vessel. The advanced setup menu is entered by first pressing the SETUP button twice (two slight presses) and then holding the button for at least 5 seconds.

  • Page 39: Data Output

    INSTALLATION Note! The advanced setup submenus are reserved for users with dedicated responsibility for the Simrad HS52 product on board the vessel. Data Output The Processing unit has two individually configurable output serial lines. On output line Data output 1 two RS-232 and two 422 serial lines are available.
  • Page 40 If “none” is selected as output format, no data will be sent to output line. Caution! All HS52 output serial lines connected to equipment requiring data from a IMO approved GPS Receiver Equipment have to be output as RS-422 signal and with 4800 baud rate. The RS- 232 serial lines are to be used for non IMO critical purposes only, like monitoring, logging of data and for maintenance.

  • Page 41: Ethernet

    None WARNING! If “None” is selected as output format, no data will be sent to Ethernet line. Caution! A change in IP Address and IP Net mask parameter will not take effect before the HS52 is restarted! 20222360 / E...

  • Page 42: General

    Simrad HS52 GPS compass and DGPS navigator General The General submenu includes the selections; height aiding, accuracy level for integrity indication, velocity filtering, position filtering, heading filtering, clock data output format, NMEA id and number of decimals used in the NMEA GGA/GLL position solution.
  • Page 43 NAV1/POS display on page 46. Velocity Filtering The Simrad HS52 outputs raw data for SOG and COG with the default velocity filter setting OFF. When smoothing of the SOG and COG measurements is required, the filter period could be selected in the range 1 to 99 seconds in steps of one second.

  • Page 44: Expert Setup

    Simrad HS52 GPS compass and DGPS navigator Nmea Decimals The number of decimals used in the NMEA GGA/GLL position solution can be selected in the range 3 to 6. The value is 6, which gives the highest position resolution. The default value is Expert Setup The Expert setup submenu includes the selections;...
  • Page 45 The average value for observations from each of the two different systems should then be used, and the offset between the two systems (reference value minus HS52 reading) input as the Head offset value. The offset value can be either positive or negative.
  • Page 46 However, its recommended to restart the system anyway to be 100% sure that the GPS receivers have been reset. The default setting is OFF. Run Mode Used for switching the HS52 between NORMAL and DEMO mode. DEMO mode is used for simulating input data to the system. WARNING!
  • Page 47 INSTALLATION Log Data, Server Address, User Name and Password Used for service purposes. 20222360 / E...
  • Page 48 Simrad HS52 GPS compass and DGPS navigator THIS PAGE INTENTIONALLY LEFT BLANK 20222360 / E...

  • Page 49: Operating Instructions

    OPERATING INSTRUCTIONS 4. OPERATING INSTRUCTIONS Overview The Display unit is used for setup and operation of the HS52. Each of the push buttons is clearly identified with the primary function in large text, and a secondary function listed in smaller text.

  • Page 50: Turning The System On/Off

    Since there normally is no reason for turning the unit off, it should be left running continuously. The HS52 will be shut down in a controlled way when the button is pressed for 1-2 seconds. Then the message POWER Shutdown in process will appear on the screen.
  • Page 51 SOG is calculated (one black bar graph) or not (one white bar graph). The Simrad HS52 GPS receivers include a RAIM exclusion and detection algorithm implemented to detect satellite failure. The RAIM algorithm is implemented as described in "Guidelines for the use of differential GPS in offshore surveying".
  • Page 52 Simrad HS52 GPS compass and DGPS navigator The integrity indication for different position accuracy levels are expressed in three states that satisfies the requirements in IEC 61108-1 second edition 2003-07. The states are Safe, Unsafe and Caution. On the display, the visual indicators are shortened into SAFE, CAUTN and USAFE.

  • Page 53: Navigation/Hdt Display

    Primary NAV1/HDT display, shown after the start-up screen when the HS52 is turned ON. True heading is shown as a big number in the centre of the compass with the COG value above it.

  • Page 54: Navigation/Pos Display

    The third display appears when pressing the NAV1/POS button three times. This display shows satellites in sight by the Sensor unit, and which satellites the Simrad HS52 is tracking. The satellites are presented according to satellite geometry. The bars on the left side of this display indicate the signal-to-noise level for each satellite.
  • Page 55 Shows the average signal-to-noise ratio on GPS receivers 1 and 2. Correction age Indicates the age of differential corrections. If Simrad HS52 receives no differential correction, the displayed correction age will be high. See No Differential Corrections on page 60 for troubleshooting loss of differential signal.
  • Page 56 The other information in this display is only of interest to service personnel. In the SBAS page information of which SBAS system used by the Simrad HS52 is presented together with the selected satellite by its PRN number, the message rate of this satellite and status on SBAS warnings.

  • Page 57: Alarms

    Sensor unit status. The Sensor unit status is mainly used by service personnel. Alarms The Simrad HS52 will generate three types of alarms. These are position, heading and no data alarm. It is possible to enable the heading alarm and the position alarm individually and to set all alarms enabled or all alarms disabled.

  • Page 58: Position Alarm Display

    The alarm text will remain in the display until the NAV1 or NAV2 button is pressed. No heading data will be output from HS52 and shown on the display as long as the heading alarm situation is present. The last valid position determined will be output from HS52 and shown on the display as long as the position alarm situation is present.

  • Page 59: Position And Heading Alarm Display

    OPERATING INSTRUCTIONS displays will be blanked out and the system stops sending out heading data. The alarm text shown in the figure below will be displayed. See Invalid Heading on page 61 for troubleshooting. Position and Heading Alarm Display If both heading and position data is invalid, the display will show: System Restart System restart is activated at power up of the system and when...

  • Page 60: Watchdog

    If so, a message will appear after restart on the display indicating this (system restart). Operation The HS52 will normally output signals on the serial lines without any involvement from the user. However, the following should be taken into consideration during operation: Adjust Backlight on Display The rotary knob is used for adjusting the display brightness.

  • Page 61: Height Aided Gps Position

    OPERATING INSTRUCTIONS Use of SBAS Corrections It is possible either to specify which Geo satellite to track or to let the receiver choose which Geo satellites to track using Automatic mode. However, it is recommended specifying which Geo satellites to track. This enables the receiver to keep better track of the specified satellites without starting to search for PRN numbers every time it looses track of the satellite.
  • Page 62 Simrad HS52 GPS compass and DGPS navigator Height aiding is active only with input of differential GPS. For more information on how to enable height aiding, see chapter General on page 34. 20222360 / E...

  • Page 63: Maintenance

    The return address is provided in the last pages of this manual. The software in HS52 can be upgraded to latest version in the field by connecting an external PC to the Processing unit. A software upgrade has to be performed by Simrad service people or representatives.

  • Page 64: Processing Unit

    Simrad HS52 GPS compass and DGPS navigator Processing Unit No special maintenance is required. It is advisable, however, at the start of each season to make a visual inspection of the terminals below the bottom cover (terminal cover) and check all connections.

  • Page 65: Repairs And Modifications

    Terminate the cable to the Processing unit as described in Cable Connections, page 18. Replacing Damaged Units No HS52 units are designed for service in the field, and a damaged unit has to be shipped back to Simrad for repair. Caution!

  • Page 66: Troubleshooting

    Refer to the table below for hints and try to solve the problem yourself, or consult your nearest Simrad dealer for assistance. The next sections contain some hints for troubleshooting.

  • Page 67: Invalid Position

    Check the mounting location and consider relocation according to the guidance described in “Location of the Unit” on page 12. If there are still no valid data, contact your nearest Simrad dealer for assistance. Invalid Position The reason for invalid position can be one of the following: •...

  • Page 68: Reduced Position

    Simrad HS52 GPS compass and DGPS navigator If invalid position, then proceed as follows: • The Sensor unit is unable to see enough GPS satellites. Press the NAV2/POS button until the Skyplot appears, and check that at least three satellites are listed in the Satellite Skyplot - see “Navigation/POS Display”...

  • Page 69: Invalid Heading

    Location of the Unit on page 12. If it is still not working after checking the above items, consult your nearest Simrad dealer for assistance. Reduced Heading Indication The reason for reduced heading can be one of the following: •...

  • Page 70: Simulated Data

    If it is still reduced after checking the above items, consult your nearest Simrad dealer for assistance. Simulated Data If the HS52 system is not sending out real data, check whether the system is operation in demonstration mode with only simulated output data. If the system operates in demonstration mode the text DEMO appear at the bottom of the status field as shown in the figure.

  • Page 71: Figures And Drawings

    FIGURES AND DRAWINGS 6. FIGURES AND DRAWINGS This section contains outline drawings showing the mechanical dimensions of the different HS52 parts. To scale drawings are available upon request. The following drawings are enclosed: Name Drw. no Rev. Sensor Unit, dimensions...

  • Page 72: Sensor Unit, Dimensions

    Simrad HS52 GPS compass and DGPS navigator Sensor Unit, Dimensions 20222360 / E...

  • Page 73: Processing Unit, Dimensions

    FIGURES AND DRAWINGS Processing Unit, Dimensions 20222360 / E...

  • Page 74: Display Unit, Dimensions

    Simrad HS52 GPS compass and DGPS navigator Display Unit, Dimensions Note! Mounting bracket is optional 20222360 / E...

  • Page 75: Parts List

    Standard Delivery The standard HS52 consists of: Part no. No. Description 20214136 HS52 Sensor unit, including 1 meter cable and 4 fastening bolts 20214144 HS52 Processing unit including 4 fastening screws 20214151 HS52 Display unit, including 15 meter cable, flush mounting...
  • Page 76 Simrad HS52 GPS compass and DGPS navigator THIS PAGE INTENTIONALLY LEFT BLANK 20222360 / E...

  • Page 77: Appendix A - Propr. Nmea Message

    8. APPENDIX A – PROPR. NMEA MESSAGE This chapter describes the NMEA 0183 proprietary message PSXN, 20 and the special Ashtech RRE format output from HS52. The PSXN,20 format is according to IEC 61162-1 and follows the standard regarding unused fields on talker. Description: $PSXN,20,horiz-qual,hgt-qual,head-qual,rp-qual*csum term $GPRRE,nsat,id,res...id,res,hpos-err,vpos-err*csum term...
