HD30 QUICK START GUIDE

About this Guide

This guide is a quick reference for users to install and operate HDIP video
surveillance systems. It provides only basic information regarding the network
recorders and cameras. For further details on installation and operation, please refer
to the Hardware and Software User Manuals.
CONTENTS
Before proceeding, please check to confirm that the box contains the items listed
here. If any item is missing or has defects, DO NOT install or operate the product and
contact AvertX for assistance.
HD30 Dome Camera Torx Security Tool
Anchors
Screws
Quick Start Guide & Installation CD
INSTALLATION
Remove Cover
Align Holes on Wall
Adjust Aim
1. Remove the dome cover using the
supplied Torx tool.
2. Mark the positions of the 2 screw holes
on the base of the camera at your
chosen location.
3. Use a 3/16" drill bit to drill the holes for
the anchors.
4. If necessary, drill a 1 1/16" hole for your
IP Connection Dongle.
5. Insert the anchors into the drilled holes.
6. Fasten the camera to the wall or ceiling
with the supplied screws.
7. Connect the Ethernet cable to the
camera.
8. Adjust the camera to the desired angle.
9. If necessary, cut the hole in the
designated spot on the housing to allow
the dongle to connect without binding.
10. Replace the dome cover. Screw the two
Torx screws on the side of the dome
cover to tightly fasten the cover in place.
31506AA
