Summary of Contents for avertX HD838IRM
- Page 1 HD838IRM HD Indoor/Outdoor IP Camera User Manual...
- Page 2 The information in this publication is provided “as is” without warranty of any kind. The entire risk arising out of the use of this information remains with recipient. In no event shall AVERTX be liable for any direct, consequential, incidental, special, punitive, or other damages whatsoever (including without limitation,...
- Page 3 Before using, make sure power supply and others are properly connected. • While operating, if any abnormal condition or malfunction is observed, stop using the camera immediately and then contact AvertX Customer Support. Handling Do not disassemble or tamper with parts inside the camera.
- Page 4 REGULATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC.
-
Page 5: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ............................5 INTRODUCTION ............................... 7 Overview ..............................7 Camera Default Settings ......................7 Product Features ........................7 GETTING STARTED ..............................8 Box Contents ............................8 Camera Overview ............................. 9 Camera Diagram ........................9 Dimensions ..........................9 Connections .......................... - Page 6 Authentication ........................27 IP Address Filter ........................ 27 User Management ........................28 Online Users ........................28 Network ..............................29 Basic Settings ........................... 29 Basic Settings > TCP/IP ....................29 Basic Settings > DDNS ..................... 30 Basic Settings > Port ......................30 Advanced Settings ........................
-
Page 7: Introduction
INTRODUCTION OVERVIEW The AVX-HD838IRM HD Indoor/Outdoor IP camera is capable of streaming real time ultra HD 4K video. The dual streaming can be used in a variety of building surveillance installations. Power over Ethernet (PoE), eliminates the need for separate power cables and significantly reduces installation costs. -
Page 8: Getting Started
BOX CONTENTS Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, do not install or operate the product and contact your dealer for assistance. AVX-HD838IRM Camera Mounting Screws Plastic Anchors... -
Page 9: Camera Overview
CAMERA OVERVIEW Before installing or connecting the bullet camera, please refer to this section and complete preparations for camera setup and all switch settings. Camera Diagram Dome Cover Lens MicroSD Card Slot Supports up to 128GB MicroSD card Reset Button Use the reset button to restore the factory default settings. -
Page 10: Connections
For outdoor installations, seal any holes in the wall or ceiling with silicone caulk to protect against • water intrusion. AvertX recommends using Cat5e cable to connect the camera to your network. For the best transmission quality, the cable length should not exceed 300 feet. Weather Resistant Cable Connector This camera features an IP66-rated weather resistant connector. - Page 11 To Install the weather resistant cable connector: 1. Slide all pieces of the waterproof cable connector over the cable plug in this order: Thread Lock Cap • Flexible silicone seal ring. You will need to stretch the silicone seal over the RJ-45 plug. •...
-
Page 12: Installing The Camera
13. Replace and secure the dome cover. Tip: Use the AvertX Connect mobile app to view the camera while adjusting view. Note: AvertX recommends sealing the opening at the wall and at the base of the camera with silicone caulking. 37084AB... -
Page 13: Resetting The Camera
2. Hold the reset button down while reconnecting cat5e and continue holding the reset button for 30 seconds after reconnecting. 3. Allow 2 minutes before attempting to rediscover camera. Cleaning the Lens Cover The Lens Cover of the AVX-HD838IRM is extremely durable but can be damaged if cleaned improperly. To clean the lens cover: •... -
Page 14: Connecting
AvertX recorders will automatically apply a DHCP IP address. If you are not connecting the camera to an AvertX recorder or DHCP network, you must set a static IP address. NCM allows you to do this in the bottom left corner: 1. -
Page 15: Connecting To The Camera
AvertX IP cameras using third party software like VLC media player (http://www.videolan.org). To connect the camera, you may need to provide the stream URL. All AvertX IP cameras are capable of delivering two RTSP streams over HTTP. The stream URLs are listed below: •... -
Page 16: Live View
LIVE VIEW Description Browse to Live View page to view live video Browse to Playback page to view video recorded to onboard storage Browse to the Picture page to view snapshots saved to onboard storage Browse to the Analytics Page Browse to the Advanced Page Change Aspect Ratio in Live View Select which stream displays in Live View... -
Page 17: Analytics
ANALYTICS Intrusion Detection Area Settings Analytic: Choose between Person Detection and Vehicle Detection. Use the checkbox to Enable/Disable the selected analytic. Start Recording: Start/Stop a live video recording and save to selected location. Capture: Capture live view image and save to selected location. Max. - Page 18 To Create a Detection Area: 1. Click on Detection Area. 2. Click on the image to set the first corner of the detection area. 3. Move to the next corner point and click to set. Repeat this process to complete the shape. Note: The detection area can be adjusted by clicking on a corner and dragging to the new position.
-
Page 19: Arming Schedule
Arming Schedule applies only to event-triggered recording video and snapshots to onboard storage and does not impact what, when, or how video is recorded on AvertX recorders. Check Enable and set a weekly schedule for the times when Intrusion Detection is active. -
Page 20: Linkage Method
Linkage Method Use the checkboxes to enable the available actions. ACTIONS (Arming Schedule must be configured to enable): Record Video to Memory Card – Video will be recorded when a person or vehicle is detected. Upload Snapshots to Memory Card – Capture the image when a person or vehicle is detected and save the picture to the onboard microSD card. -
Page 21: Advanced
ADVANCED LOCAL Local configuration refers to the parameters of the live view, record files and captured pictures. Live View Parameters Set the protocol type and live view performance. Protocol Type: TCP, UDP, MULTICAST and HTTP are selectable. TCP: Ensures complete delivery of streaming data and better video quality, although the real- •... -
Page 22: System
Record File Settings Set the saving path of the recorded video files. Valid for the record files you recorded with the web browser. Record File Size: Select the packed size of the manually recorded and downloaded video • files to 256M, 512M or 1G. After the selection, the maximum record file size is the value you selected. -
Page 23: Time Settings
Time Settings Configure the time synchronization and DST settings. Select the Time Zone of your location from the drop-down menu. To configure the NTP settings: 1. Click to enable the NTP function. 2. Configure the following settings: Server Address: IP address of NTP server. NTP Port: Port of NTP server. -
Page 24: Dst (Daylight Savings Time)
DST (Daylight Savings Time) Configure daylight savings time, if needed. To configure DST: 1. Select the Start Time and the End Time. 2. Select the DST Bias. 3. Click Save to activate the settings. About Click View Licenses to check information about the open source software that applies to the IP camera. 37084AB... -
Page 25: Maintenance
Maintenance Upgrade & Maintenance Process the operations, including reboot, partly restore, restore to default, export/import the configuration files, and upgrade the device. Reboot: Restart the device. • Restore: Reset all the parameters, except the IP parameters and user information, to the default •... -
Page 26: Log
Export the camera log files. To export log files: 1. Set the log search conditions to specify the search, including Major Type, Minor Type, Start Time and End Time. 2. Click Search to search log files. The matched log files will be displayed on the log list interface. -
Page 27: Security
Security Configure the parameters, including Authentication, IP Address Filter. Authentication 1. Set up authentication method for RTSP Authentication and WEB Authentication. CAUTION: Digest is the recommended authentication method for better data security. Be aware of the risk if you adopt basic as the authentication method. 2. -
Page 28: User Management
User Management As Administrator: The admin user can Add, Modify or Delete user accounts, and grant them different permissions. We highly recommend you manage the user accounts and permissions properly. Note: Admin password is required for adding and modifying a user account. Adding a User The admin user has all permissions by default and can create, modify or delete other accounts. -
Page 29: Network
NETWORK Basic Settings Basic Settings > TCP/IP Configure the basic network settings, including the NIC Type, IP Address, Subnet Mask, Gateway, MTU settings and Multicast Address. (Optional): 1. Check Enable Multicast Discovery, and then the online network camera can be automatically detected by client software via private multicast protocol in the LAN. -
Page 30: Basic Settings > Ddns
Basic Settings > DDNS Before you start: Registration on the DDNS server is required before configuring the DDNS settings of the camera. 1. Check the Enable DDNS checkbox to enable this feature. 2. Select DDNS Type. Two DDNS types are selectable: DynDNS and NO-IP. DynDNS: 1. -
Page 31: Advanced Settings
Advanced Settings Advanced Settings > HTTPS HTTPS provides authentication of the web site and its associated web server, which protects against Man-in-the-middle attacks. Note: • HTTPS is enabled by default. • If HTTPS is enabled, the camera creates an unsigned certificate automatically. 1. -
Page 32: Stream Settings
H.264+, H.265, and H.265+. H.265 is a new encoding technology which reduces the transmission bitrate under the same resolution, frame rate and image quality compared with H.264. Note: The camera will require a reboot to turn H.264+/H.265+ on or off. IMPORTANT: AvertX ProConnect recorders do not currently support H.265/H.265+ video encoding. 37084AB... -
Page 33: Audio
Audio Configure the following audio settings: Input Volume 0-100 adjustable. Environmental Noise Filter Set it as OFF or ON. When the function is enabled, the noise in the environment can be filtered to improve the clarity of voices. 37084AB... -
Page 34: Image
IMAGE Display Settings Configure the image adjustment, exposure settings, day/night switch, backlight settings, white balance, image enhancement, video adjustment, and other parameters in display settings, OSD settings, and privacy mask. Image Adjustment Brightness describes brightness of the image, which ranges from 1 to 100. •... -
Page 35: Exposure Settings
Saturation Set the intensity of color in the image. Low saturation High saturation Contrast Set the degree of difference between the blackest pixel and the whitest pixel. Low contrast High contrast Sharpness Contrast of boundaries of objects in an image. Low sharpness High sharpness Digital Noise... -
Page 36: Backlight Settings
Night: The camera provides high-quality black and white images using the existing light. Auto: The camera outputs the optimum images according to the light condition. In this mode, the camera can switch between night mode and day mode automatically. Scheduled-Switch: Set the start time and the end time to define the duration for day/night mode. -
Page 37: Image Enhancement
Image Enhancement Digital Noise Reduction: DNR reduces the noise in the video stream. OFF, Normal and • Expert are the available options. Normal Mode: 0 to 100 • Expert Mode: • Space DNR level: 0 – 100 • Time DNR level: 0 – 100 Video Adjustment Image Flip: mirrors the image so you can see it inversed. -
Page 38: Osd Settings
OSD Settings Customize the camera name, time/date format, display mode, and OSD size displayed in live view. To configure OSD settings: 1. Check the applicable checkbox to display the camera name, date or week. 2. Edit the camera name in the text field of Camera Name. 3. -
Page 39: Privacy Mask
Privacy Mask Privacy mask enables you to cover certain areas on the live video to prevent certain spots in the surveillance area from being viewed and recorded. rivacy mask areas are used to protect privacy. For example, a privacy mask can cover the keypad of an ATM machine or the entry to fitting rooms. To configure privacy masks: 1. -
Page 40: Event
EVENT Motion Detection Motion detection detects moving objects in the defined areas. In order to detect the moving objects accurately and reduce the false alarm rate, normal configuration and expert configuration are available for varied motion detection environments. To configure Normal motion detection: 1. -
Page 41: Auto-Switch
2. Select OFF for Scheduled Image Settings. 3. Select the Area by number. 4. Adjust the Sensitivity of an object in the motion detection area. 5. Set the Arming Schedule and Linkage Method as in the normal configuration mode. 6. Click Save to save the settings. Auto-Switch 1. -
Page 42: Set The Arming Schedule For Motion Detection
Set the Arming Schedule for Motion Detection To configure the motion detection schedule: 1. Click on the time bar and drag the mouse to select the time period. Note: Click on the selected time period, you can adjust the time period to the desired time by either moving the time bar or input the exact time period. -
Page 43: Set The Linkage Method For Motion Detection
Set the Linkage Method for Motion Detection Use the checkboxes to enable the available actions. ACTIONS (Arming Schedule must be configured to enable): Record Video to Memory Card – Video will be recorded when a person or vehicle is detected. Upload Snapshots to Memory Card –... -
Page 44: Storage
STORAGE Schedule Settings Schedule Settings > Record Schedule This camera includes an integrated microSD™ card slot that can be used to record video. The card slot is compatible with a microSD™ card up to 128GB. This section is used to define when video should be recorded to the microSD card. -
Page 45: Schedule Settings > Capture Schedule
3. Select the Record Type: Continuous: video will be recorded automatically according to the time of the schedule. Motion: video will be recorded when the motion is detected. Note: In addition to configuring the recording schedule, the schedule and actions must also be configured in the Motion Detection settings. -
Page 46: Schedule Settings > Capture Parameters
3. Click Save to save the settings. Schedule Settings > Capture Parameters 1. Check Enable Timing Snapshot. 2. Select the Quality and Capture Interval. Quality: Low, Medium, High • Capture Interval: length of time between images • 3. Check Enable Event-triggered Snapshot. 4. -
Page 47: Storage Management
Storage Management View the capacity, free space, status, type, formatting type, and property of the disk. Note: The camera must be powered off when installing the microSD card. If the status of the disk is Uninitialized, check the corresponding checkbox to select the disk and click Format to start initializing the disk. - Page 48 All rights reserved. No part of this publication may be reproduced by any means without written permission from AvertX. The information in this publication is believed to be accurate in all respects. However, AvertX cannot assume responsibility for any consequences resulting from the use thereof. The information contained herein is subject to change without notice.
