- Page 1 HD40D Night Vision HD Indoor/Outdoor IP Dome Camera User Manual...
- Page 2 AVERTX be liable for any direct, consequential, incidental, special, punitive, or other damages whatsoever (including without limitation, damages for loss of business profits, business interruption or loss of business information), even if AVERTX has been advised of the possibility of such damages or whether in an action, contract or tort, including negligence.
- Page 3 Read Instructions Operating Read all of the safety and operating instructions before using the Before using, make sure power supply and others are properly product. connected. Retain Instructions While operating, if any abnormal condition or malfunction is Save these instructions for future reference. observed, stop using the camera immediately and then contact Attachments / Accessories your local dealer.
- Page 4 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC.
- Page 5 Connections ........................................11 Weather Resistant Cable Connector ................................ 11 TWO: CAMERA FINDER ..........................................12 Bench test..........................................13 AvertX Camera Finder ..................................... 13 Finding IP Cameras....................................13 Accessing the Camera ..................................... 13 Changing the IP Address ..................................13 THREE: SETUP AND CONFIGURATION ..................................... 14 Installing the Camera ......................................
- Page 6 Connecting to the Camera ...................................... 18 Connecting In a Web Browser ..................................18 Administrator/User Privileges ..................................18 Default Username and Password ................................18 Connecting a Stream ....................................... 18 Camera Settings ........................................19 Viewer Tabs ........................................19 Home ..........................................19 Changing the Language ................................... 19 Using Digital Zoom Control ..................................
- Page 7 Storage Management ....................................31 Recording ......................................... 32 Schedule ........................................32 File Location ......................................32 View Information ...................................... 32 Factory Default ......................................33 Software Version ...................................... 33 Software Upgrade ....................................33 Maintenance ......................................33 Streaming ........................................33 Video Format ......................................33 Camera..........................................
- Page 8 Progressive Scan CMOS Sensor 1080p and 4MP Resolution Available H.264 Encoding The HD40D Night Vision HD Indoor/Outdoor IP Bullet Cameras are Dual Streaming compact cameras designed for easy setup and use. The 4 megapixel Multi-Language Support resolution provides high definition images.
- Page 9 Box Contents Camera Overview 32332AE...
- Page 10 Before installing or connecting the camera, please refer to this section here. If any item is missing or has defects, DO NOT install or operate and complete preparations for setup and all switch settings. the product and contact your dealer for assistance. HD40D Camera Desiccant Self-Tapping Screws Plastic Screw Anchors...
- Page 11 This camera features an IP66-rated weather resistant connector. For AvertX HD40D cameras use Power over Ethernet (PoE). The only unprotected outdoor connections, screw the connector on the included connection on the camera is the RJ45 Ethernet dongle located on the Ethernet camera cable onto the camera dongle.
- Page 12 AvertX IP Finder...
- Page 13 Once the camera is connected to the recorder, test all functions to ensure proper If you are not directly connecting to an AvertX HDIP recorder, you must operation. manually change the IP address. Change the IP address to a number in...
- Page 14 Installing the Camera Connecting to the Camera Viewer Software...
- Page 15 Bullet cameras are suitable for mounting on either a wall or ceiling. Note HD40D cameras are equipped with a seal inside the housing Use the included mounting template to pre-drill holes for the to prevent moisture from entering. If you have any concerns...
- Page 16 SD card in a series of 5 minute long .avi files, and you can 12. Reinstall the front cover and fasten the screw access the recordings via any card reader that reads MicroSD cards. NOTE: The microSD card needs to be formatted to FAT32. A formatting utility is available at avertx.com...
- Page 17 To enable recording to the microSD card, insert the card into the camera and then you will need to enable recording using the camera software. 13. Open Microsoft Internet Explorer (IE) web browser. 14. If your camera is connected directly to the HDIP recorder: Type the IP address of the recorder, followed by : and then /admin.
- Page 18 AvertX IP cameras are optimized for use with AvertX HDIP recorders, but you can also connect to your AvertX IP cameras using third party software like VLC media player (http://www.videolan.org). To connect the camera you may need to provide the stream URL. All AvertX IP cameras are capable of delivering two RTSP streams, as well Type the IP address of the camera in a web browser.
- Page 19 You can access the camera setup menu using an internet browser on your computer. The camera viewer software will install automatically the first time you connect to the camera. If your internet browser doesn’t install the viewer software, check the security settings or ActiveX controls and plug-in settings.
- Page 20 (MAC) address that can be used for identification. The MAC address is located on the bottom of each camera, and on the box label (AvertX IP Finder also displays the MAC address for To change the administrator password, type a new password in the identification).
- Page 21 When using static IP address to log in to the IP Camera, you can access it either through the AvertX IP Finder software or type the IP address directly in the Address bar of your internet browser. On the Streaming tab, you can configure specific video resolution, video compression mode, and video protocol and audio transmission mode.
- Page 22 If your camera is installed on a wall or table top the image may appear You can adjust your picture quality on both streams using the Camera to be upside down. Rotate the camera video image using the software section of the Setup tab. to get a right-side-up image.
- Page 23 You can adjust these values as necessary for your installation. Motion Detection allows the camera to detect motion and trigger alarms when the motion level in the detected area exceeds the determined Brightness sensitivity threshold value. Sharpness Saturation ...
- Page 24 Use the Software Upgrade page to view the current version of camera When motion detection is activated, When motion is detected, the signals firmware, and upgrade the firmware if necessary. the Motion pop-up window will open. will be displayed on the Motion window as shown below.
- Page 25 Click Upgrade. The system will check the upgrade file, and then upload the file. The upgrade status bar will display on the page. Your AvertX camera will automatically log you out when you close your browser window. If you want to log in as a different user, you will need to use the logout tab.
- Page 26 The Admin Camera Controls gives greater control of camera functions.
- Page 27 Camera Control– Allows the User to change camera controls in the Setup menu. Click Add. Host Name – The Host Name is used to identify the camera on your system. If camera based Motion Detection is enabled and is set to send alarm message by Mail/FTP, the host name entered here will display in Select the user name on the User Name list.
- Page 28 Type a new address in the Default Gateway box. When using static IP address to log in to the IP Camera, you can access it either through AvertX Camera Finder software or type the IP address directly in the address bar of Internet Explorer.
- Page 29 Friendly Name – Set a name to easily identify the camera. the new port must be defined when attempting to web connect (ex: if your camera’s IP address is 192.168.0.100 and you change the web port to 8001, then you must type http://192.168.0.100:8001 in your browser).
- Page 30 When motion detection is activated, When motion is detected, the signals the Motion pop-up window will open. will be displayed on the Motion The camera can send alarm messages to a specific Hypertext Transfer window as shown below. Protocol (HTTP) site when motion is detected or when the sensor input is activated.
- Page 31 Triggered Action – Designate the actions that will occur upon Network Failure Detection activation. All AvertX IP cameras include an integrated microSD™ card slot that can be Tampering Alarm – Turn the Tampering Alarm On, Off, or On By used to record video or images. The card slot is compatible with a Schedule.
- Page 32 Type a Start Time and Duration. Note: If you are using Windows Vista, 7, or 8, you will need to change the Snapshot location. Windows UAC does not allow Click Save. internet programs to write directly to C:\ for security reasons. Repeat steps 3-5 for each desired day of the week until the desired schedule is completed.
- Page 33 Close the internet browser. Go to the Windows Control Panel and double-click Add or Remove Your AvertX IP camera can transmit three streams of video at the same Programs. Locate the Camera Viewer software on the Currently time. One stream can be in high definition for recording, and the other installed programs list and click Remove to uninstall the previous can be a lower resolution used for live display.
- Page 34 Video Resolution – Set the resolution and compression codec for each 1024kbps, highest compression, lowest quality stream. 2048kbps Text Overlay – allows you to select text to be displayed over the video. 4096kbps, middle compression, default Three options are available: Date, Time, and a Custom String (up to 20 ...
- Page 35 Select One Push. Click the Check button to confirm RTSP over HTTP MJPEG over HTTP Place a large white object (paper or cardboard works well) in the center of the camera’s field of vision. The camera should be In the case of multicast networking, users can select the Multicast mounted in its final location mode.
- Page 36 You can set custom camera setting profiles and switch between them manually or automatically via a schedule. If your camera is aimed at a doorway or window, and you need to see detailed footage of people in front of that doorway, the difference between light and shadow can make the people difficult to recognize.
- Page 37 32332AE...
- Page 38 Model HD40D Rev D Resolution (4MP) 2560 x 1440 (3 MP) 2048 x 1536, (2MP / 1080p)1920 x 1080 (1.3 MP) 1280 x 1024, (1MP / 720p) 1280 x 720 (D1) 720 x 480, (CIF) 352 x 240 Video Format H.264, MJPEG...
