3.21 OUTDOOR FRONT END (PUSH AID FOR
OUTSIDE)
ATTENTION
The push aid can only be attached if there is no user
sitting in the wheelchair.
ATTENTION
The push aid is designed for a max. speed of 8 km/h.
A higher speed is not allowed.
ATTENTION
Going downhill and driving with a tilted seat, it is
important to be extra careful.
(1-4) Mounting the pushing aid
• Close the wheelchair's wheel locks.
• Tip the wheelchair slightly back and/or place
the casters on the jack up aid (A).
• Lock the latches (B) left and right in an opened
position (pull out and turn 90°),
• insert both bars (C) on both sides all the way
into the adaption (D).
• Close the latches again, (the latches (B) need
to snap into place on the left and right),
• Remove jack up aid.
ATTENTION
After mounting, be sure to check whether the
construction is firm and secure in the fixture and
that it is locked safely.
Removing the push aid
To remove, proceed in reverse order.
ATTENTION
Let your rehab technician do the necessary work in
order to extend/widen the push aid.

3.22 BAGGAGE HOLDER

ATTENTION
Fold the baggage holder back whenever possible to
avoid hurting someone.
ATTENTION
Load the baggage holder after you are seated in the
wheelchair.

3.23 PELVIC BELTS

Pelvic belts can be requested when putting together
your wheelchair either with the SORG order form or
by ordering with a spare parts catalogue. Mounting is
done by your rehab technician.
(1)
(C)
(A)
(2)
(3)
(4)
User Manual
(C)
(E)
(B)
(D)
35
