Vector
Our successfully tested wheelchairs
are provided with this international
symbol on the type sign and are
additionally marked on our order
form with our "crash If necessary,
inform yourself by your retailer or
under www.sorgrollstuhltechnik.
de, if your model is approved as a
seat in a vehicle.

2.11.3 Attachment points

ATTENTION
(1+2) When using the Vector in a vehicle as a seat,
only the attachment points with an international
anchor symbol (A) can be used for the belts
• (1) back left and right
• (2) front left and right
ATTENTION
(3) Be sure that all four belts of the wheelchair
back restraint system (B) are tight according to the
manufacturers specifications.
ATTENTION
It is necessary to use a head rest! We recommend
one which is independent from the wheelchair and
firmly attached in the vehicle.
When using a head rest which is attached to
the wheelchair, a second stabilizing rod may be
necessary. For this please read the regulations
and instructions in our info brochure "Crash-Test
ISO 7176-19". You can download these at
sorgrollstuhltechnik.de.
ATTENTION
(4) Be sure that the patient in the wheelchair is
secured with at least a 3 point belt (C) according
to the specifications of the manufacturer for person
restraint systems.
ATTENTION
Be sure that the chest belt goes over the sternum
and does not touch the neck.
20
(1)
(2)
(3)
www.
(4)
(C)
(A)
(A)
(B)
