A8239A
05/18
Copyright © 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
7000
Series M1/ELR
Multi-Point Lock with
SE LP10 Reader
Installation Instructions
Advertisement
Table of Contents
Related Manuals for Sargent SE LP10 7000 Series
Summary of Contents for Sargent SE LP10 7000 Series
- Page 1 Multi-Point Lock with SE LP10 Reader Installation Instructions A8239A 05/18 Copyright © 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 3: Table Of Contents
Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 4: General Description
SE LP10 7000 Series Multi Point Lock General Description The SARGENT SE LP10 brings a new level of flexibility to our Integrated Wiegand access control solutions for 7000 series multipoint locks. Featuring multiCLASS SE® Technology from HID Global®, the SE LP10 is ideal for mixed credential environments and enables easy migration to higher security credentials and mobile access. -
Page 5: Wiring Diagrams
SE LP10 7000 Series Multi Point Lock Wiring Diagrams 8 PIN CONNECTOR 4 PIN CONNECTOR 1-Black 2-Red 3-White 4-Green 5-Orange 6-Blue 7-Brown 8-Yellow 1-Violet 2-Gray 3-Pink 4-Tan 12VDC WIEGAND WIEGAND EGND TAMPER 12/24 VDC (NC) (COM) (LOCK RELAY) (Reader) OPEN... - Page 6 SE LP10 7000 Series Multi Point Lock Typical SE LP10 Application Diagram (12/24VDC System) DIAGRAM #1 – MODE 1: RED LED ‘ON’ WHEN POWERED Standard Application Shown - For Alternative Applications Contact 1-800-810-WIRE (9473) Reader Requires 5 to 16VDC Filtered and Regulated 12VDC System / 24VDC System •...
-
Page 7: Parts Breakdown
SE LP10 7000 Series Multi Point Lock Parts Breakdown SE LP10 (M1) 7000 Series Tools Required • Phillips screw driver (standard size) • Slotted screw driver (standard size) • #8-32 tap & tap drill (for metal door applications) • T10 Torx Driver... - Page 8 SE LP10 7000 Series Multi Point Lock Parts Breakdown (Continued) SE LP10 (M1) 7000 Series Tools Required • Phillips screw driver (standard size) • Slotted screw driver (standard size) • #8-32 tap & tap drill (for metal door applications) • T10 Torx Driver...
- Page 9 SE LP10 7000 Series Multi Point Lock Parts Breakdown (Continued) SE LP10 (M1) 7000 Series ITEM PART # Description Req. WD/MD/AD Inside Trim Assembly Outside Trim Assembly 94-2411 MD/AD Inner Chassis Assembly 94-2412 MD/AD Inner Chassis Assembly, Fire (12-) 94-2414...
-
Page 10: Installation Instructions
SE LP10 7000 Series Multi Point Lock Installation Instructions 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. The Multi-Point lock may be handed. • Door should be fitted and hung. Left Hand... - Page 11 SE LP10 7000 Series Multi Point Lock 3 Install Outside Trim and Inside Trim A. Outside Trim Outside Exit trim 1. For exterior applications, use ET gasket (52-0263) to seal ET escutcheon and outside door surface (Fig. 3A). 2. Feed wire through the through hole and attach the outside exit trim to the door.
- Page 12 SE LP10 7000 Series Multi Point Lock 5 Installation of SE LP10 Reader & Trim Bezel Observe precautions for handling electrostatic sensitive devices. If the SE LP10 reader is installed with a module (Fig. 5A), make sure that the reader is powered down when inserting/removing the module; i.e., do not “hot-plug”...
- Page 13 SE LP10 7000 Series Multi Point Lock 6A Inside Mounting Plate and Wire Connections (Non-ELR) 1. Attach mounting plate using (2) #8 x 1/2” self-drilingl screws (Fig. 6A). 2. Connect 6- and 2-pin connectors from device to 6- and 2-pin connectors on reader harness (Fig.
- Page 14 SE LP10 7000 Series Multi Point Lock 6B Inside Mounting Plate and Wire Connections (ELR) Install the upper left mounting screw, #8 - 32 x 5/8 Fillister for metal door or #8 x 5/8 self-drilling Fillister for wood doors (Figure 6F).
- Page 15 SE LP10 7000 Series Multi Point Lock 7 Fire Plate Installation and Earth Ground Connection 1. Remove lower left screw from mounting plate. Feed screw through green/yellow ground wire ring terminal. Reinstall screw. Ensure that green/yellow wire points toward top of door in order to avoid interference with escutcheon.
-
Page 16: Concealed Door Position Switch Instructions (3287)
1. Concealed Door Position Switch Model 3287 is included with this product. System integrator shall determine use and installation location. 2. If Sargent 3287 Concealed Door Position Switch installation is specified, use SARGENT template A7448B to prepare door and frame at desired 3287 Door location. -
Page 17: Mechanical Operational Check
SE LP10 7000 Series Multi Point Lock Mechanical Operational Check For devices without cylinders, go to step 3. 1. For devices with cylinders, insert key into cylinder and rotate. 2. The key will retract the latch and rods, the key should rotate freely. - Page 20 New Haven, CT 06511 USA 800-727-5477 • www.sargentlock.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications. The company’s customer base includes commercial construction, institutional, and industrial markets.
