General Information

Unit Dimensions

B
A
C
E
D
F
003440
Figure 2-2. Unit Dimensions
A B C D E F
54 in. 77.5 in. 16 ft. 31.5 in. 57 in. 74 in.
PLT240
(1.37 m) (1.96 m) (4.88 m) (0.80 m) (1.45 m) (1.88 m)
Specifications are subject to change without notice.
Owner's Manual for PLT240 Light Tower 7
