- Page 1 BASE UNIT 972 L Corner Assembly Guide For Internal Use: FI.WR.INS.024_WKIN00106_BASE_972_LCorner_Rev2.indd...
-
Page 2: Assembly Guide
BASE UNIT BEFORE YOU START 972 L Corner INSTALLATION SHOULD BE PERFORMED BY A Assembly Guide COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel C Panel B Panel S Panel T Panel E Loose Shelf... - Page 3 BASE UNIT Step 1. 972 L Corner Seat dowel (F) into holes in Assembly Guide both end panels (B) as shown. Seat (G) cam dowel into hole as Step 2. shown. Seat cam dowel (G) into holes in both end panels (B) as shown.
- Page 4 BASE UNIT 972 L Corner Step 5. Assembly Guide Slide back panel (A) into groove of panels (B). Once back panel (A) is in position, ensure the panel is flush & square with the bottom of the end panels (B) Step 6.
- Page 5 BASE UNIT Step 8. 972 L Corner Seat dowel (F) into holes in Assembly Guide both end panels (B) as shown. Seat (G) cam dowel Step 9. into hole as shown. Seat cam dowel (G) into holes in both end panels (B) as shown.
- Page 6 BASE UNIT Step 12. 972 L Corner Secure panel (S) with 4x 45mm screws (J) at the top and 4x 45mm screws (J) in the Assembly Guide bottom, in the holes provided as shown. Step 13. Secure both carcasses together using fixing plates (P) with 4x 15mm screws (L) to each plate (P).
- Page 7 BASE UNIT 972 L Corner Assembly Guide Step 14. Secure each of the legs into place with 2x 15mm screws (L) Front Ensure legs are rotated as shown so that part of it is supporting the end panels (B). Front legs should have flat edge to the front.
- Page 8 BASE UNIT 972 L Corner Carcass 2 Assembly Guide 126 94 Carcass 1 Step 17. Attach Hinge Mounting Plate onto both End Panels (B) as shown, using Screws which are already positioned within the Hinge Plates. Hinge side to be mounted in accordance to customer kitchen plan.
- Page 9 BASE UNIT Step 18. Align corner post to frontal. Equally space 972 L Corner 2 fixing plates (P) to the back of frontal & corner post. Assembly Guide Ensure a 3mm gap is maintained between frontal & post once fixed together.
- Page 10 BASE UNIT 972 L Corner Assembly Guide For Internal Use: FI.WR.INS.024_WKIN00106_BASE_972_LCorner_Rev2.indd...
- Page 11 BASE UNIT 972 L Corner Assembly Guide For Internal Use: FI.WR.INS.024_WKIN00106_BASE_972_LCorner_Rev2.indd...
