  • Page 2 Introduction This manual covers the items required for maintaining the MITSUBISHI CNC C80 Series. Read this manual thoroughly and understand the product's functions and performance before starting to use. The unit names, cable names and various specifications are subject to change without notice. Please confirm these before placing an order.
  • Page 3 Manual List Manuals related to M800/M80/E80/C80 Series are listed as follows. These manuals are written on the assumption that all optional functions are added to the targeted model. Some functions or screens may not be available depending on the machine or specifications set by MTB. (Confirm the specifications before use.)
  • Page 4 Manuals for MTBs (NC) Manual IB No. Purpose and Contents  Model selection M800/M80/E80/C80 Series IB-1501505 Specifications Manual (Function)  Outline of various functions  Model selection M800/M80/E80/C80 Series IB-1501506 Specifications Manual (Hardware)  Specifications of hardware unit  Detailed specifications of hardware unit...
  • Page 5 (Monitor) GOT2000 Series Connection  Outline of connection types and connection method between Manual (Mitsubishi Electric SH-081197 GOT and Mitsubishi Electric connection devices Products) GT Designer3 (GOT2000) Screen  Outline of screen design method using screen creation SH-081220 Design Manual software GT Designer3 ■...
  • Page 6 Manual Purpose and Contents M800/M80 Series Smart safety BNP-C3072-022 observation Specification manual  Explanation for smart safety observation function C80 Series Smart safety observation BNP-C3077-022 Specification manual M800/M80 Series CC-Link (Master/ BNP-C3072-089  Explanation for CC-Link Local) Specification manual M800/M80 Series PROFIBUS-DP BNP-C3072-118 ...
  • Page 8 Precautions for Safety Always read the specifications issued by the MTB, this manual, related manuals and attached documents before installation, operation, programming, maintenance or inspection to ensure correct use. Understand this numerical controller, safety items and cautions before using the unit. This manual ranks the safety precautions into "DANGER", "WARNING"...
  • Page 9 For Safe Use MITSUBISHI CNC is designed and manufactured solely for applications to machine tools to be used for industrial purpos- Do not use this product in any applications other than those specified above, especially those which are substantially in- fluential on the public interest or which are expected to have significant influence on human lives or properties.
  • Page 10 3. Items related to prevention of bodily injury or property damage DANGER When transporting or installing a built-in IPM spindle or linear servomotor, be careful so that your hand or property is not trapped in the motors or other metal objects. Also keep the devices with low magnetic tol- erance away from the product.
  • Page 11 CAUTION Do not transport the controller or drive unit by suspending or holding the connected wires or cables. Do not hold the front cover when transporting the unit, or the front cover could come off, causing the unit to drop. Install on a non-combustible place where the unit's or motor's mass can be withstood according to the in- struction manual.
  • Page 12 CAUTION Following the UN recommendations, battery units and batteries should be transported based on the inter- national regulations such as those determined by International Civil Aviation Organization (ICAO), Interna- tional Air Transport Association (IATA), International Maritime Organization (IMO) and U.S. Department of Transportation (DOT).
  • Page 13 CAUTION Carry out wiring so that there is no possibility of short circuit between wires, nor of dangerous state. Use wires and cables whose wire diameter, heat resistance level and bending capacity are compatible with the system. Ground the device according to the requirements of the country where the device is to be used. Wire the heat radiating fins and wires so that they do not contact.
  • Page 14 (4) Set up WARNING Do not cancel the emergency stop before confirming the basic operation. Always set the stored stroke limit. Failure to set this could result in collision with the machine end. CAUTION If the battery low warning is issued, save the machining programs, tool data and parameters in an input/ output device, and then replace the battery.
  • Page 15 (6) Usage CAUTION Use C80 in an environment that meets the general specifications contained in "C80 Series Connection and Setup Manual". Using C80 in an environment outside the range of the general specifications could result in electric shock, fire, operation failure, and damage to or deterioration of the product.
  • Page 16 CAUTION Use a noise filter, etc. to reduce the effect of electromagnetic disturbances in the case where electromag- netic disturbances could adversely affect the electronic devices used near the drive unit. Use the drive unit, motor and each regenerative resistor with the designated combination. Failure to ob- serve this could result in fires or faults.
  • Page 17 (8) Maintenance, inspection and part replacement CAUTION Periodically back up the programs, tool data and parameters to avoid potential data loss. Also, back up those data before maintenance and inspections. The electrolytic capacitor’s capacity will drop due to deterioration. To prevent secondary damage due to capacitor's faults, Mitsubishi recommends the electrolytic capacitor to be replaced approx.
  • Page 18 (9) Disposal CAUTION Take the batteries, etc. off from the controller, drive unit and motor, and dispose of them as general indus- trial wastes. Do not alter or disassemble controller, drive unit, or motor. Collect and dispose the spent batteries according to local laws. Dispose the spent cooling fan according to local laws.
  • Page 20 Treatment of waste The following two laws will apply when disposing of this product. Considerations must be made to each law. The following laws are in effect in Japan. Thus, when using this product overseas, the local laws will have a priority.
  • Page 22 This symbol mark is according to the directive 2006/66/EC Article 20 Information for end- users and Annex II. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and/or reused. This symbol means that batteries and accumulators, at their end-of-life, should be disposed of separately from your household waste.
  • Page 24 MELDAS, MELSEC, EZSocket, EZMotion, iQ Platform, MELSEC iQ-R, MELSOFT, GOT, CC-Link, CC-Link/LT, CC-Link IE, CC-Link IE/field, EcoMonitorLight and SLMP are either trademarks or registered trademarks of Mitsubishi Electric Corporation in Japan and/or other countries. Ethernet is a registered trademark of Xerox Corporation in the United States and/or other countries.
  • Page 26 本製品の取扱いについて ( 日本語 /Japanese) 本製品は工業用 ( クラス A) 電磁環境適合機器です。販売者あるいは使用者はこの点に注意し、住商業環境以外で の使用をお願いいたします。 Handling of our product (English) This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. 본...
  • Page 28: Table Of Contents

    Contents 1 System Basic Configuration ........................1 1.1 System Basic Configuration Drawing ........................2 1.2 General Connection Diagram ........................... 3 1.3 How to Check the System Configuration ........................4 1.3.1 System Configuration Screen .......................... 4 1.3.2 Option Display Screen ............................. 5 1.4 Each Unit Status Display ............................
  • Page 29 4.10 Servo Diagnosis Screen ............................78 4.11 Diagnosis Data Collection Setting ........................81 4.11.1 Starting the Data Collection ......................... 83 4.11.2 Stopping the Data Collection........................83 4.11.3 Clearing the Collected Data ......................... 84 4.11.4 Referring to the Collected Data........................84 5 Troubleshooting............................
  • Page 30: System Basic Configuration

    System Basic Configuration IB-1501454-C...
  • Page 31: System Basic Configuration Drawing

    C80 Series Maintenance Manual 1 System Basic Configuration 1System Basic Configuration 1.1 System Basic Configuration Drawing GOT2000 Series (SVGA, VGA) GT Designer3 SD card Ethernet connection CNC CPU R16NCCPU PLC CPU Rotary switch GX Works3 E M G RnCPU NC Analyzer2...
  • Page 32: General Connection Diagram

    C80 Series Maintenance Manual 1 System Basic Configuration 1.2 General Connection Diagram Display module GOT2000 Series Specifications including unit names, cable names, and maximum lengths of cables are H101 cable J303 cable subject to change without notice. Always (Max:20m) (Max:20m) 24VDC confirm these details before placing an order.
  • Page 33: How To Check The System Configuration

    C80 Series Maintenance Manual 1 System Basic Configuration 1.3 How to Check the System Configuration 1.3.1 System Configuration Screen Diagn Config Select the menu [Config] on the diagnosis (Diagn) screen to display the hardware configuration (card name and sub-num- ber), software configuration (software number and sub-number), and PLC program configuration (file name, file label, and execution type).
  • Page 34: Option Display Screen

    C80 Series Maintenance Manual 1 System Basic Configuration Display items Display items Details Remarks (1) Software list This displays a list of the software being used. keys to change the pages and refer it. (2) Installed lang This displays a list of installed languages.
  • Page 35: Each Unit Status Display

    C80 Series Maintenance Manual 1 System Basic Configuration 1.4 Each Unit Status Display Each unit status can be confirmed by checking the LED mounted on each unit. 1.4.1 Power Supply 1.4.1.1 R61P/R62P/R63P/R64P Name Details POWER LED Indicates the operating status of the power supply module.
  • Page 36: Q61p/q63p/q64pn

    C80 Series Maintenance Manual 1 System Basic Configuration 1.4.1.2 Q61P/Q63P/Q64PN Q63P Q61P/Q64PN Name Details Q61P/Q64PN POWER LED ON (Green): Normal (5VDC output, instantaneous power failure within 20ms) OFF: The power supply module is out of order while AC power supply is ON. (5VDC error, in- ternal circuit failure, blown fuse) Over current protection or over voltage protection operated.
  • Page 37: Plc Cpu Module

    C80 Series Maintenance Manual 1 System Basic Configuration 1.4.2 PLC CPU Module (10) Name Details READY LED Indicates the operating status of the CPU module and the error level. ERROR LED [READY LED - ERROR LED status] On-off: Normal operation...
  • Page 38 C80 Series Maintenance Manual 1 System Basic Configuration Name Details PROGRAM RUN Indicates the operating status of the program. On: Being executed (RUN state) Flashing: Being suspended (PAUSE state) Off: Stopped (STOP state) or stop error PROGRAM RUN Indicates the operating status of the program.
  • Page 39: Cnc Cpu Module

    C80 Series Maintenance Manual 1 System Basic Configuration 1.4.3 CNC CPU Module (1) READY LED (2) ERROR LED The operating state and the error state of CNC CPU will be displayed. READY LED ERROR LED Operating state Not lit Not lit...
  • Page 40: Daily Maintenance And Periodic Maintenance

    Daily Maintenance and Periodic Maintenance IB-1501454-C...
  • Page 41: Daily Maintenance

    C80 Series Maintenance Manual 2 Daily Maintenance and Periodic Maintenance 2Daily Maintenance and Periodic Maintenance Maintenance is categorized into daily maintenance items (items to be carried at set intervals) and periodic maintenance items (replacement of parts when life is reached).
  • Page 42: Maintenance Of The Drive Unit

    Maintenance of the Drive Unit IB-1501454-C...
  • Page 43: Periodic Inspections

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3Maintenance of the Drive Unit WARNING 1. Before starting maintenance or inspections, turn the main circuit power and control power both OFF. Wait at least fifteen minutes until the CHARGE lamp turns OFF, and then confirm that the input and output voltage are zero using a tester, etc.
  • Page 44: Durable Parts

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.2 Durable Parts A guide to the part replacement cycle is shown below. Note that these will differ according to the working conditions or en- vironmental conditions, so replace the parts if any abnormality is found. Contact Mitsubishi branch or your dealer for repairs or part replacements.
  • Page 45: Adding And Replacing Units And Parts

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3 Adding and Replacing Units and Parts CAUTION 1. Correctly transport the product according to its weight. Failure to observe this could result in injury. 2. Do not stack the product above the indicated limit.
  • Page 46: Replacing The Unit Fan

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3.1.2 Replacing the Unit Fan Replacing parts <MDS-E Series> Servo drive unit Spindle drive unit Power supply unit Type Fan type Size Type Fan type Size Type Fan type Size...
  • Page 47 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit POINT When the drive unit of E/EH Series which uses two cooling fans is in an emergency stop or alarm, one of fans (upper one in the case of vertical layout, or either one in the case of horizontal layout) is stopped and power-saving oper- ation is performed.
  • Page 48: Replacing The Battery

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3.1.3 Replacing the Battery Replacing parts <Replacing a battery equipped with the spindle/servo drive unit or the battery unit, MDSBTBOX-LR2060> When the battery voltage is low (warning 9F), place an order for the same type of a battery as the one currently equipped with the unit.
  • Page 49 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit Replacement procedure Replace the battery with the following procedures. CAUTION 1. Replace the batteries with new ones immediately after the battery voltage drop alarm (9F) has been output. 2. Replace the batteries while applying the drive unit’s control power.
  • Page 50 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <Replacement procedure for the battery unit MDSBTBOX-LR2060> Possible backup period Possible backup period is at most one year. Thus, make sure to exchange the batteries in the one-year cycle. How to replace the battery (1) Remove the battery box cover (four screws).
  • Page 51: Mds-ej/ejh Series

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3.2 MDS-EJ/EJH Series 3.3.2.1 Replacing the Drive Unit Arrangement of replacing parts Contact Mitsubishi branch or your dealer for an order or a replacement of the drive unit. Place an order for the same type of a drive unit as the one to be replaced.
  • Page 52 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit Replacement procedure Replace the unit fan with the following procedures. <MDS-EJ-V1-30, MDS-EJ-SP-20> Direction of the fan wind Direction of Disconnect the connection connector the fan wind of the fan mounted Cooling fan on the unit side face.
  • Page 53 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <MDS-EJ-V1-40/80/100, MDS-EJ-SP-40/80> Direction of the fan wind Direction of Disconnect the connection connector the fan wind of the fan mounted on the unit side face. Cooling fan CON5 Remove the mounting screws.
  • Page 54 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <MDS-EJ-SP-100/120> Cooling fan lead wire Direction of the fan wind Direction of the fan wind Cooling fan Attach the harness to the position described in the figure above. Sleeve Connector Place the fan harness inside the chassis using the positioning boss for the chassis.
  • Page 55 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <MDS-EJ-SP-160> (1) Remove the mounting screws. (2) Disconnect the connection connector of the fan mounted on the unit side face. Sleeve Direction of the fan wind Direction of the fan wind...
  • Page 56 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <MDS-EJ-V2-30, MDS-EJ-SP2-20> Remove the mounting screws. Disconnect the connection connector of the fan mounted on the unit side face. Direction of the fan wind <MDS-EJ-V2-40> Remove the mounting screws. Disconnect the connection...
  • Page 57: Replacing The Battery

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3.2.3 Replacing the Battery Replacing parts <Replacing a battery equipped with the servo drive unit or the battery unit, MDSBTBOX-LR2060> When the battery voltage is low (warning 9F), place an order for the same type of a battery as the one currently equipped with the unit.
  • Page 58 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit (b) Replacing the built-in battery MR-BAT6V1SET that reached the end of the life can be reused by replacing the MR-BAT6V1 battery. Cover Open the cover while pushing the locking part.
  • Page 59 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <Replacement procedure for the battery unit MDSBTBOX-LR2060> Possible backup period Possible backup period is at most one year. Thus, make sure to exchange the batteries in the one-year cycle. How to replace the battery (1) Remove the battery box cover (four screws).
  • Page 60: Mds-em/emh Series

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3.3 MDS-EM/EMH Series 3.3.3.1 Replacing the Drive Unit Arrangement of replacing parts Contact Mitsubishi branch or your dealer for an order or a replacement of the drive unit. Place an order for the same type of a drive unit as the one to be replaced.
  • Page 61: Replacing The Fan Unit

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit 3.3.3.2 Replacing the Fan Unit Replacing parts Drive unit type Fan type MDS-EM-SPV3-16040S EM-FS-18 MDS-EM-SPV3-10040 to 200120 EM-FS-26 MDS-EMH-SPV3-8040 to 10060 MDS-EM-SPV3-320120 EM-FS-30 Replacement procedure Replace the fan unit with the following procedures.
  • Page 62: Replacing The Battery

    C80 Series Maintenance Manual 3 Maintenance of the Drive Unit (4) When installing the fan unit, insert the sheet metal of the fan unit into the fin rails. Fin rail * Sheet metal * Although MDS-EM-SPV3-16040S and 320120 do not have fin rails, the installation of fan units is not affected.
  • Page 63 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit Replacement procedure Replace the battery with the following procedures. CAUTION 1. Replace the batteries with new ones immediately after the battery voltage drop alarm (9F) has been output. 2. Replace the batteries while applying the drive unit’s control power.
  • Page 64 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit <Replacement procedure for the battery unit MDSBTBOX-LR2060> Possible backup period Possible backup period is at most one year. Thus, make sure to exchange the batteries in the one-year cycle. How to replace the battery (1) Remove the battery box cover (four screws).
  • Page 65 C80 Series Maintenance Manual 3 Maintenance of the Drive Unit IB-1501454-C...
  • Page 66: Failure Diagnosis

    Failure Diagnosis IB-1501454-C...
  • Page 67: Introduction

    C80 Series Maintenance Manual 4 Failure Diagnosis 4Failure Diagnosis 4.1 Introduction If trouble occurs during operation, the accurate cause must be found so that adequate measures can be taken. Confirm "when", "when doing what", "what kind of trouble" and "how frequently" the trouble occurred. Also check how many years the machine has been operated, and how many hours a day it is used.
  • Page 68: Diagnosis Based On The Alarm

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.3 Diagnosis Based on the Alarm Alarm information includes the "NC message", "PLC message", and "Alarm history". 4.3.1 How To Check the Alarm Information Diagn Alarm A list of currently occurring alarms or messages can be displayed on this screen.
  • Page 69 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Display items Details NC message This displays the operation alarms, program errors, MCP alarms, servo alarms, sys- tem alarms, etc. Up to 10 messages are displayed in order of priority. Stop code This displays the automatic operation status or stop status during automatic operation.
  • Page 70: Alarm History

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.3.2 Alarm History When an alarm occurs, the alarm information is recorded. When the NC power is ON, an alarm is automatically recorded in alarm history. Alarm information is recorded from the latest alarm to 512.
  • Page 71 C80 Series Maintenance Manual 4 Failure Diagnosis Menus Menus Details This displays the first page of the alarm history. Alarm The history sequentially displays 16 alarms per page from the latest alarm. If there are two or more NC history alarms of same day and time, the alarms are sequentially displayed from the alarm and warning of the 1st part system.
  • Page 72: Alarm Message Details

    Confirm details with the alarm guidance (alarm message details) displayed on the NC screen by pressing the [?] key or key. Note is displayed only on the software keyboard. To confirm by "Alarm manual" Confirm the details with "M800/M80/E80/C80 Series Alarm/Parameter Manual" (IB-1501279). IB-1501454-C...
  • Page 73: Diagnosis Based On The I/f Diagnosis Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.4 Diagnosis Based on the I/F Diagnosis Screen 4.4.1 I/F Diagnosis Screen Diagn I/F dia The various input/output signals for the PLC (Programmable Logic Controller) control can be displayed and set in this screen.
  • Page 74 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details 1-shot output This displays the data and device to carry out one-shot output. The details to be defined are set here when carrying out the one-shot type forced out- put of PLC interface signals.
  • Page 75: Displaying The Plc Device Data

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.4.1.1 Displaying the PLC Device Data The various status signals and register data used in the PLC can be monitored and displayed. When this screen is first selected, the respective 16-byte amounts of input/output data are displayed from device "X0000"...
  • Page 76: Carrying Out Modal Output

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.4.1.2 Carrying Out Modal Output Modal type forced output of PLC interface signals is carried out. Once set, this data is held until cancelled, the power is turned ON/OFF, or other data is overwritten. There are four sets of devices that modally output. If this number is exceeded, the previously existing data is overwritten.
  • Page 77: Carrying Out One-shot Output

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.4.1.3 Carrying Out One-shot Output The one-shot type PLC interface signal forced output is forcibly output only once during the screen operations. Thus, it may not be possible to confirm the PLC interface signals updated with the PLC on the screen.
  • Page 78: List Of Devices For Plc Uses

    (1) As the use of devices marked with a * mark in the device column has been determined, do not use devices even if they are undefined vacant devices. Refer to the following manuals for details on device No.: M800/M80/E80/C80 Series PLC Interface Manual Refer to the specifications issued by the MTB for machine-specific information. IB-1501454-C...
  • Page 79: Diagnosis Based On The Self Diagnosis Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.5 Diagnosis Based on the Self Diagnosis Screen 4.5.1 Self Diagnosis Screen Diagn Selfdia The hardware state and NC operation state can be confirmed by selecting the menu [Selfdia] on the diagnosis (Diagn) screen.
  • Page 80 C80 Series Maintenance Manual 4 Failure Diagnosis (*1) As for the NC unit, the contents are as follows depending on the condition: Item Details Battery vol state CPU module does not use the battery. This item is not displayed. The PLC CPU and the servo drive unit use batteries, but the states of these batter- Battery used years ies are not displayed in the screen.
  • Page 81 C80 Series Maintenance Manual 4 Failure Diagnosis (*2) The following state can be confirmed. State Details In-position This displays "1" (in-position state) when the following conditions are satisfied for even one axis. There is a control axis whose acceleration/deceleration is not zero.
  • Page 82: Diagnosis Based On The Data Sampling Screen

    The NC internal data (speed output from NC to the drive unit, or feedback data from the drive unit, etc.) can be sampled. Also, the sampling data can be output externally on the I/O screen on the maintenance (Mainte) screen. For the details, refer to "C80 Series Data Sampling Specification Manual (BNP-C3077-034)". IB-1501454-C...
  • Page 83: Diagnosis Based On The Drive Monitor Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.7 Diagnosis Based on the Drive Monitor Screen 4.7.1 Drive Monitor Screen (Servo Unit) Diagn Drv mon The various data related to the servo axis (NC axis, PLC axis) can be monitored by selecting the menus [Drv mon] -> [Servo unit] on the diagnosis (Diagn) screen.
  • Page 84 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Max current 3 (%) This displays the FB value of the motor current in terms of continuous current during stalling. An absolute value of the current FB peak value sampled in most recent 2 seconds is displayed.
  • Page 85 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Fan rev (r/min) The detected rotation speed of the unit cooling FAN is displayed by converting it into percentage format. Drive temp. (deg) This displays the drive unit temperature. Motor temp. (deg) This displays the motor temperature.
  • Page 86 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details This indicates the control signal output from servo to NC. (bit0 to bit7) Control output Bit0: Z-phase passed Bit3: In zero speed Bit7: In external emergency stop Control output This indicates the control signal output from servo to NC. (bit8 to bitF)
  • Page 87 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Machine end detector This displays the machine end detector type. The type is displayed when the control method is CLOSED or DUAL. * is displayed when the method is SEMI.
  • Page 88: Drive Monitor Screen (spindle Unit)

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.7.2 Drive Monitor Screen (Spindle Unit) Diagn Drv mon The various data related to the spindle can be monitored by selecting the menus [Drv mon] -> [Spindle unit] on the diagnosis (Diagn) screen.
  • Page 89 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Max disturb torq (%) This displays the estimated disturbance torque in terms of stall rated torque when the col- lision detection function is adjusted. An absolute value of the estimated disturbance torque peak value sampled in most recent 2 seconds is displayed.
  • Page 90 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details SP sync err -P (deg) This displays the maximum value of the angle at which the synchronous spindle lags be- hind the basic spindle during spindle synchronization I, tool spindle synchronization IA/ IB, or tool spindle synchronization II.
  • Page 91 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details This indicates the control signal input from NC to spindle. (bit8 to bitF) Control input 4H BitC: M coil selection command BitD: L coil selection command BitE: Sub-motor selection command Control input 5L This indicates the control signal input from NC to spindle.
  • Page 92 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Motor end detect No This displays the motor end detector serial No. Mach. end detect No This displays the machine end detector serial No. Motor It displays the motor type which is set for the spindle specification parameter "#3138 mo- tor_type".
  • Page 93: Drive Monitor Screen (power Supply Unit)

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.7.3 Drive Monitor Screen (Power Supply Unit) Diagn Drv mon The various data related to the power supply can be monitored by selecting the menus [Drv mon] -> [Power unit] on the diagnosis (Diagn) screen.
  • Page 94 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Consumed power (kW) The power consumption is calculated and its integrated value is displayed. (0.01 kWh) Pwr. distortion (V) The amount of power distortion (harmonic voltage value) is calculated and displayed.
  • Page 95: Drive Monitor Screen (synchronous Error)

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.7.4 Drive Monitor Screen (Synchronous Error) Diagn Drv mon The "Synchronous error" appears only when the synchronous control axis specification is valid. The various data related to the synchronous error can be monitored by selecting the menus [Drv mon] -> [Synchro error] on the diagnosis (Diagn) screen.
  • Page 96: Clearing The Alarm History On Drive Monitor Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.7.5 Clearing the Alarm History on Drive Monitor Screen Diagn Drv mon Operation method Press the menu [Servo unit], [Spindle unit] or [Power unit]. Using the menu [Next axis], tab keys select the axis (device) from which to clear the alarm history.
  • Page 97: Nc Memory Diagnosis Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.8 NC Memory Diagnosis Screen Diagn Mem dia The NC internal data can be displayed and rewritten on the NC memory diagnosis (Mem dia) screen of the diagnosis (Di- agn) screen. The custom API library's NC data read/write interface is used to display and rewrite the NC's internal data.
  • Page 98 C80 Series Maintenance Manual 4 Failure Diagnosis Menus Menus Details This erases the information in the line where the cursor is. (One entire line becomes blank.) The cursor Line does not move at this time. clear The contents of the set address data (Part system No, Section/sub-section/axis) for all the lines are con- Data stantly displayed.
  • Page 99: Safety Observation Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.9 Safety Observation Screen Diagn Safety The configuration, signal status, drive status and version in use of the smart safety observation function are displayed on the safety observation screen. 4.9.1 Safety Observation Screen (Configuration Diagnosis) The available/unavailable states of the smart safety observation function are displayed on the configuration diagnosis screen.
  • Page 100 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details NC-I/O safety communica- This displays the communication status of the safety I/O communication. tion To perform the safety I/O communication, at least one of remote I/O channels needs to be configured with the safety I/O devices (safety remote I/O unit, opera- tion panel equipped with safety I/Os) and RIO2.0 unit alone.
  • Page 101: Safety Observation Screen (signal Monitor)

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.9.2 Safety Observation Screen (Signal Monitor) The signal monitor screen displays the safety PLC signal status. The safety PLC signal displays both of the duplex PLC signals to identify the incongruous state. With the initial display, the input/output signal status from the device "X0000" is displayed on the left side and the input/output signals from the device "Y0000"...
  • Page 102 C80 Series Maintenance Manual 4 Failure Diagnosis Displaying the PLC device input/output signal To refer the arbitrary input/output signal status, enter the target device No. to the input area, and the display will be switched. (Example) For displaying the input/output signal of the arbitrary device No. "X0020"...
  • Page 103: Safety Observation Screen (drive Monitor)

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.9.3 Safety Observation Screen (Drive Monitor) The safety communication state with servo drive (NC axis, PLC axis) and spindle drive can be monitored. Only the safety drive communication parameter enabled axes are displayed on this screen.
  • Page 104 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Safety command 2L This displays the data sent to the drive. Details SBC command (0: No command, 1: With command) SBC command for SBT (1CH side) (0: No command, 1: With...
  • Page 105 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Details Safety status 2L This displays the data received from the drive. Details SBC status (0: No operation, 1: In operation) SBC status for SBT (1CH side) (0: No operation, 1: In opera-...
  • Page 106: Safety Observation Screen (version Display)

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.9.4 Safety Observation Screen (Version Display) Software version about smart safety observation is displayed on the version display screen. Display items Display items Details NC Safety This displays the smart safety observation software version of the NC system.
  • Page 107: Servo Diagnosis Screen

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.10 Servo Diagnosis Screen Mainte Mainte You can confirm the following information on the servo diagnosis screen by pressing [Mainte] -> [Servo diagn] on the diag- nosis (Diagn) screen: - The number of alarms of servo/spindle drive unit...
  • Page 108 C80 Series Maintenance Manual 4 Failure Diagnosis (2) Display of the spindle PLG diagnosis information Display items Display items Details Alarm times This displays the data for each axis or unit. There are Alarm times 1 to 32, and there are switched with the page up/down keys.
  • Page 109 C80 Series Maintenance Manual 4 Failure Diagnosis Menus Menus Details Displays the servo unit diagnosis information in the data display area. Servo unit Displays the spindle unit diagnosis information in the data display area. Spindle unit <Note> When the parameter "#1039 spinno" is set to "0", this menu is not displayed.
  • Page 110: Diagnosis Data Collection Setting

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.11 Diagnosis Data Collection Setting Mainte Mainte The following operations can be performed on the diagnosis collection setting screen: (1) Setting to perform the diagnosis data collection (2) Confirming the status of the diagnosis data collection (3) Starting/stopping the diagnosis data collection (4) Clearing the diagnosis data.
  • Page 111 C80 Series Maintenance Manual 4 Failure Diagnosis Display items Display items Details State Display the history data and sampling data collection status. Display the history data collection status. History data History collecting: History data collection is in progress. History stop: History data collection is stopped.
  • Page 112: Starting The Data Collection

    C80 Series Maintenance Manual 4 Failure Diagnosis Menus Menus Details This begins collecting sampling data and history data. Start This stops the sampling data and history data collection operation. Stop This stops the sampling data and history data collection operation, and clears the collected data.
  • Page 113: Clearing The Collected Data

    C80 Series Maintenance Manual 4 Failure Diagnosis 4.11.3 Clearing the Collected Data When the data clear menu is executed, the data collection is stopped and the collected data is cleared. (1) When the menu [Data clear] is pressed, the confirmation message appears.
  • Page 114 C80 Series Maintenance Manual 4 Failure Diagnosis Procedures to output the history data files (1) Select [Mainte]-[I/O]. (2) Set the files of device A as follows: A:Dev: Memory Directory: /LOG (Displayed as "History".) File name: ALLLOG.LOG (all history), KEYLOG.LOG (key history), TOUCHLOG.LOG (touchscreen history) <Note>...
  • Page 115 C80 Series Maintenance Manual 4 Failure Diagnosis Procedures to output the alarm detailed information history data files (1) Select [Mainte]-[I/O]. (2) Set the files of device A as follows: A:Dev: Memory Directory: /LOGEX File name: ALM-SVn.LOG, ALM-OTRn.LOG (n = 1 to 5) <Note>...
  • Page 116: Troubleshooting

    Troubleshooting IB-1501454-C...
  • Page 117: Troubleshooting

    C80 Series Maintenance Manual 5 Troubleshooting 5Troubleshooting If trouble occurs during operation, the accurate cause must be found so that adequate measures can be taken. Perform the following checks for this. 5.1 Troubleshooting Confirm "when", "when doing what", "what kind of trouble" and "how frequently" the trouble occurred. Also check how many years the machine has been operated, and how many hours a day it is used.
  • Page 118: Possible Causes Of Trouble

    C80 Series Maintenance Manual 5 Troubleshooting 5.1.1 Possible Causes of Trouble The most common cause is a cable contact defect and wire breakage defect. Is the connection correct? Are the cables bent or stepped on? Are the joints of the cables and connectors deteriorated? Was a continuity test done on the cables?
  • Page 119 C80 Series Maintenance Manual 5 Troubleshooting IB-1501454-C...
  • Page 120: Replacing Each Unit

    Replacing Each Unit IB-1501454-C...
  • Page 121: Cnc Cpu Module

    C80 Series Maintenance Manual 6 Replacing Each Unit 6Replacing Each Unit 6.1 CNC CPU Module 6.1.1 Procedure of Replacing the CPU Module Using the Backup/restoration Data (1) Backup the memory data. (a) Press [Data mng.] tab - (Backup restoration) of GOT utility main menu screen.
  • Page 122 C80 Series Maintenance Manual 6 Replacing Each Unit (d) The backup will start. <Example> PLC CPU/CNC CPU data has been backed up processing in the data name of "16062304". (e) The dialog box will be displayed when the backup is completed. Press [OK] to complete the process.
  • Page 123 C80 Series Maintenance Manual 6 Replacing Each Unit (5) Restore the memory data (a) Press [Data mng.] tab - (Backup restoration) of GOT utility main menu screen. (b) Press (Restoration function). IB-1501454-C...
  • Page 124 C80 Series Maintenance Manual 6 Replacing Each Unit (c) Select the file data to be restored from the list and then click [Execute]. (d) When a dialog box to execute the restoration is displayed, press [OK]. (e) The restoration will start.
  • Page 125: Got

    C80 Series Maintenance Manual 6 Replacing Each Unit 6.2 GOT When replacing the GOT, make sure to have the following related manuals at hand: (a) GOT2000 Series User's Manual (Utility) (SH-081195) (b) GOT2000 Series User's Manual (Hardware) (SH-081194) Replacement procedures (1) Before replacing the unit, use "GOT data package acquisition function"...
  • Page 126: Signal Splitter

    6.5 Signal Splitter When replacing the signal splitter, make sure to have the following related manuals at hand: (a) C80 Series Connection and Setup Manual (IB-1501452) Replacement procedures Make sure to turn OFF the machine before replacing the signal splitter.
  • Page 127 C80 Series Maintenance Manual 6 Replacing Each Unit IB-1501454-C...
  • Page 128: Appx.1: Types Of Backup Data

    Appx.1: Types of Backup Data IB-1501454-C...
  • Page 129: Types Of Backup Data

    C80 Series Maintenance Manual 7 Appx.1: Types of Backup Data 7Appx.1: Types of Backup Data 7.1 Types of Backup Data The table below lists the data to be backed up and the target range of the format, SRAM clear and the backup/restoration.
  • Page 130: Loss And Restoration Of Absolute Position Data

    C80 Series Maintenance Manual 7 Appx.1: Types of Backup Data 7.2 Loss and Restoration of Absolute Position Data Any of the followings may result in the loss of absolute position data. Changing a parameter related to absolute position Writing a parameter which was acquired when the zero point was in a different position SRAM clear of NC...
  • Page 131 C80 Series Maintenance Manual 7 Appx.1: Types of Backup Data Restoration by SRAM data (1) Select [Mainte] from the screen group at the top of the CNC monitor2 screen (GOT operation panel) and then select [Psswd input] from the menu.
  • Page 132 C80 Series Maintenance Manual 7 Appx.1: Types of Backup Data Correspondence between absolute position data and parameters Correspondence between absolute position data and I/O parameter #10000s is shown below. Name Details Timing of Updating When the power is turned OFF and ON af-...
  • Page 133 C80 Series Maintenance Manual 7 Appx.1: Types of Backup Data IB-1501454-C...
  • Page 134: Appx.2: Data Backup And Restoration

    Appx.2: Data Backup and Restoration IB-1501454-C...
  • Page 135 C80 Series Maintenance Manual 8 Appx.2: Data Backup and Restoration 8Appx.2: Data Backup and Restoration Using the backup/restoration function of the GOT, the data of the NC memory can be backed up in the external device. Also, the data can be restored from the external device to the NC memory.
  • Page 136 C80 Series Maintenance Manual 8 Appx.2: Data Backup and Restoration Operation method for backup Insert a USB memory in the front-side USB drive of the GOT. Press the screen at the top left to open the utility screen. Press [Data mng.] tab - (Backup restoration).
  • Page 137 C80 Series Maintenance Manual 8 Appx.2: Data Backup and Restoration Press [Data mng.] tab - (Backup restoration). The files in the USB memory are displayed in "Data list". Press (Restoration function). <Note> When the device selection screen appears, select Data name displayed in the "Date list" column indi- the restoration target device.
  • Page 138: Appx.3: Outputting The Error Code

    Appx.3: Outputting the Error Code IB-1501454-C...
  • Page 139: Plc Interface

    C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code 9Appx.3: Outputting the Error Code This function is to output the information of alarm which is occurring in the CNC CPU. The information is output in the form of 4-digit hexadecimal error code.
  • Page 140: Method And Content Of Diagnosis Using The Engineering Tool

    C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code 9.3 Method and Content of Diagnosis Using the Engineering Tool Connect "GX Works3", an engineering tool, to the PLC CPU, and go to [Diagnostics] - [Module Diagnostics (CPU Diagnos- tics)] to start CNC CPU module diagnosis.
  • Page 141: Dot Matrix Display On The Front Of The Module

    C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code 9.4 Dot Matrix Display on the Front of the Module The below shows the appearance of the CNC CPU module. LED display Dot matrix LED The dot matrix displays the state of battery alarm as priority as shown below.
  • Page 142: Led Display On The Front Of The Module

    C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code 9.5 LED Display on the Front of the Module READY LED and ERROR LED are mounted on the front of the CNC CPU module. The display is as follows: To light ERROR LED upon occurrence of a minor error, set "1" in the parameter "#6471/bit0".
  • Page 143: Error Code List

    C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code 9.6 Error Code List Error code Details Operation error (M01) 1800 Dog overrun 0001 1801 Some ax does not pass Z phase 0002 1802 R-pnt direction illegal 0003 1803 External interlock axis exists...
  • Page 144 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1876 Reverse run impossible 0119 1877 In synchronous correction mode 0120 1878 No synchronous control option 0121 187A Computer link B not possible 0123 187B X/Z axes simultaneous prohibit...
  • Page 145 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1960 Illegal command in superimpose 1003 1961 Superimpose command illegal 1004 1962 G114.n command illegal 1005 1964 Spindle in-use by synchro tap 1007 196B GB spindle synchro signal OFF...
  • Page 146 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1A31 Aux ax R ret invld at abs alm 0024 1A32 Aux ax R ret invld at ini 0025 Abs data error (Z70) 1A4A Abs posn base set incomplete...
  • Page 147 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1AC6 Drivers commu data error 2 008B 1ACE Init abs pos fluctuation 0093 1AD1 Scale feedback error 0096 1AD9 Abs pos dtc: Rev count error 009E 1ADA...
  • Page 148 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1B79 Hi-acc time const unextendable 0020 1B7B Superimpos linear G0 error 0022 1B7C Superimpos linear G1 error 0023 1B81 Primary delay G0time const err 0028 1B82 Primary delay G1time const err...
  • Page 149 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1C31 P49 Invalid restart search 1C32 P50 No spec: Inch/Metric change 1C3C P60 Compensation length over 1C3D P61 No spec: Unidirectional posit. 1C3E P62 No F command...
  • Page 150 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1CA3 P163 3D tool R comp is disabled 1CAA P170 No offset number 1CAB P171 No spec: Comp input by prog G10 1CAC P172 G10 L number error...
  • Page 151 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1D13 P275 Macro argument over 1D14 P276 Illegal G67 command 1D15 P277 Macro alarm message 1D18 P280 Brackets [,] nesting over 1D19 P281 Brackets [,] not paired...
  • Page 152 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1DC2 P450 No spec: Chuck barrier 1DC3 P451 No spec: Stroke chk bef travel 1DC4 P452 Limit before travel exists 1DCC P460 Tape I/O error 1DCD P461 File I/O error...
  • Page 153 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 1F98 P920 No spec: 3D coord conv 1F99 P921 Illegal G code at 3D coord 1F9A P922 Illegal mode at 3D coord 1F9B P923 Illegal addr in 3D coord blk...
  • Page 154 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 3053 Excessive speed error 0023 3054 Grounding 0024 3055 Absolute position data lost 0025 3056 Unused axis error 0026 3057 Machine side dtc: Error 5 0027 3058...
  • Page 155 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 3099 Pw sply: Grounding 0069 309A Pw sply: Ext contactor weld 006A 309B Pw sply: Rush circuit error 006B 309C Pw sply: Main circuit error 006C 309D...
  • Page 156 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code Error code Details 322D User safety sequence 2 error 0014 322E Output sig. cross check error 0015 Smart safety observation error (V04) 3230 Safety observation & Smart both ON 0001...
  • Page 157 C80 Series Maintenance Manual 9 Appx.3: Outputting the Error Code IB-1501454-C...
  • Page 158 - 8 Appx.2: Data Backup and Restoration Also, corrected wrong indications. Aug. 2018 IB(NA)1501454-C The descriptions were revised corresponding to S/W version B0 of MITSUBISHI CNC C80 series. Changed the contents of the following chapters. - 1.3.1 System Configuration Screen - 3.2 Durable Parts - 3.3.3.2 Replacing the Fan Unit...
  • Page 159 TEL: +420-59-5691-185 / FAX: +420-59-5691-199 BRAZIL Russia Service Center MITSUBISHI ELECTRIC RUSSIA LLC Mitsubishi Electric do Brasil Comércio e Serviços Ltda. LETNIKOVSKAYA STREET 2, BLD.1, 5TH 115114 MOSCOW, RUSSIA Votorantim Office TEL: +7-495-721-2070 / FAX: +7-495-721-2071 AV. GISELE CONSTANTINO,1578, PARQUE BELA VISTA, VOTORANTIM-SP, BRAZIL CEP:18.110-650...
  • Page 160 MITSUBISHI ELECTRIC AUTOMATION (CHINA) LTD. (CHINA FA CENTER) Singapore Service Center China Shanghai Service Center 307 ALEXANDRA ROAD #05-01/02 MITSUBISHI ELECTRIC BUILDING SINGAPORE 159943 1-3,5-10,18-23/F, NO.1386 HONG QIAO ROAD, CHANG NING QU, TEL: +65-6473-2308 / FAX: +65-6476-7439 SHANGHAI 200336, CHINA...
  • Page 161 Every effort has been made to keep up with software and hardware revisions in the contents described in this manual. However, please understand that in some unavoidable cases simultaneous revision is not possible. Please contact your Mitsubishi Electric dealer with any questions or comments regarding the use of this product. Duplication Prohibited This manual may not be reproduced in any form, in part or in whole, without written permission from Mitsubishi Electric Corporation.

Comments to this Manuals

Symbols: 0
Latest comments:
