3.2.2

Alarms

Alarms are provided visually by flashing
symbols, letters or figures. In addition, an
audible sequence in one frequency can be
heard during the whole duration of the alarm.
An alarm occurs in the following situations:
• Oxygen toxicity reaches 100%.
• Ignored decompression.
• Exceeding the prescribed ascent rate.
• Altitude alarm.
• Low battery alarm (without audible
alarm): battery icon appears if battery
has to be replaced.
F
NOTE: Audible attention messages
can be switched off in the watch
settings mode (by pressing the right
button 5x to the sounds screen) or
in LogTRAK. With LogTRAK sounds
can be switched off selectively or
completely.
If you turn off all sound you will have no
audible warnings. Without audible warnings
you could inadvertently find yourself in
potentially hazardous situations which could
result in death or serious injury.
Serious injury or death may result from failing
to immediately respond to alarms provided by
the Aladin One.
3.3

Preparation for the dive

It's important to check the settings of the
Aladin One, especially before the first dive.
All settings can be checked and changed
directly on the Aladin One or by using
LogTRAK and a PC.
3.3.1

Function check

To test the display, turn on your Aladin One
with a press-and-hold of the left button. Are
all elements of the display activated? Do
not use your Aladin One if the display does
not show all elements. (When switching on
the Aladin One with the right button the test
display will not appear.)
ALADIN ONE USER MANUAL
WARNING
WARNING
WARNING
Always check the battery capacity before each
dive. See chapter: System and Operation,
section: Check the battery.
3.3.2 Setting the gas mixture and
ppO max
2
To set the gas mixture, the Aladin One must
be in the dive display (showing time of day,
temperature and gas percentage):
1. Press-and-hold the right button to get
to the GAS screen, then press-and-
hold the right button again to get to the
GAS 1 O menu.
2
2. Confirm that you wish to change the
oxygen fraction of gas 1 with a press-
and-hold of the right button.
3. By pressing either the left or right button
you can change the oxygen fraction in
increments of 1%. The Aladin One will
display the current fraction of oxygen,
the maximum partial pressure limit (ppO
max) and the MOD.
4. Confirm your selected percentage with
a press-and-hold of the right button.
5. Next, by pushing the left or right button
you can change the ppO
chosen fraction of oxygen down to
1.0bar. The Aladin One will now display
the corresponding MOD for the new
ppO max.
2
6. Confirm your ppO max setting with a
2
press-and-hold of the right button.
F
NOTE: Without confirmation via a
press-and-hold of the right button the
display will disappear after 3 minutes
and your entries will not be accepted.
Automatic reset of the O
21% can be set between 1 and 48
hours or to "no reset" (default).
2
max for your
2
% mix to
2
