Summary of Contents for Uwatec Aladin SPORT

  • Page 1 ® Aladin SPORT User manual...

  • Page 2: I Safety Considerations

    Safety considerations ! WARNING You must carefully read and understand this entire manual before using your Scubapro Aladin SPORT. Diving has many inherent risks. Even if you follow the instructions of this manual in a careful manner, it is still possible that you may be seriously injured or die from decompression sickness, oxygen toxicity or some other inherent risk of scuba with Nitrox or compressed air.
  • Page 3 Aladin SPORT dive instrument is compliant with the European Union directive 2004/108/EC. Standard EN 13319: 2000 Aladin SPORT dive instrument is also compliant with the European standard EN 13319: 2000 (EN 13319: 2000 – Depth gauges and combined depth and time measuring devices – Functional and...

  • Page 4: Introduction

    We thank you for choosing SPORT and we hope you will enjoy safe dives in the future! Further information on Scubapro and Scubapro products can be found on our web page at www.scubapro.com. To make this manual easier to read we will use the term "SPORT" as an abbreviation for "Aladin SPORT diving computer" throughout this booklet.

  • Page 5: Quick Reference / Operating Scheme

    Quick reference Quick reference Time of day / Date Decompression depth / Level stop depth Setting icon Desaturation time (DESAT) Service icon No-dive warning Duration of no-dive warning Duration of surface interval Current depth SOS duration Altitude sections Repetitive dive number Logbook icon Battery icon Decompression stop...
  • Page 6 Operating scheme Display switched off Logbook Diveplanner (PLn) Page 1 Dive time Surface Oxygen Max depth interval concentration Battery performance No-stop dive Date of the dive mix. No-stop time Dive number (MOD) Page 2 Repetitive Confirmation dive number Altitude range Depth (if >0) Starting time...

  • Page 7: Table Of Contents

    List of chapters Safety considerations ........................2 Introduction ..........................4 Important remarks concerning signal words and symbols ...........4 Quick reference / Operating scheme ..................5 List of chapters ..........................7 System and operation .......................9 System description ........................9 Operation ............................. 9 Push buttons ........................9 Water contacts ......................
  • Page 8 List of chapters IV Dive planner ..........................29 Planning a no-stop dive ......................29 Leaving the dive planner ......................29 Logbook ........................... 30 Survey ............................30 Operation ........................... 30 VI Settings ............................ 32 Menu "set 1" ..........................32 Menu "set 2" ..........................34 VII Safety Stop Time / Gauge Mode / Apnea Mode ..............

  • Page 9: System And Operation

    II System and operation System and operation 1 System description SPORT displays all important dive and decompression data and has a memory which stores the full dive data. The data can be transmitted with an infrared interface (IrDA) and LogTRAK software to a ®...

  • Page 10: Water Contacts

    Make sure that the computer is on before starting the dive. 2.3 Introduction to Scubapro LogTRAK LogTRAK is the software that allows Aladin SPORT to communicate with a Windows-based PC or Mac In order to take advantage of any of these features, you need to establish a communication between your PC and Aladin SPORT with a dongle.
  • Page 11 Operation...
  • Page 12 Operation Change warnings/settings of the SPORT and reading the computer information By selecting Extras -> Read Dive Computer settings you can enable/disable warnings that cannot be enabled or disabled by using the menus on the SPORT unit. Read the chapter Warnings and alarms about the possible selections that you can modify on your SPORT.

  • Page 13: Switching On The Display

    Operation 2.4 Switching on the display • automatically, on submerging in water* or when adaptation to atmospheric pressure is necessary; • manually, by pushing . If switched on with all segments light up for 5 seconds. Afterwards the display shows the time of the day, the O mix and the temperature.

  • Page 14: Checking The Desaturation Time

    Operation 2.6 Checking the desaturation time No-fly time From the time of day display you can check the desaturation Do not fly icon time* by pushing . Desaturation time is determined either by oxygen toxicity, nitrogen saturation or the regression of No-dive microbubbles, depending on which requires the longer time.

  • Page 15: Active Backlight

    Operation ! WARNING • If the bar graph shows 2 segments, the battery symbol will blink, on the surface and in dive mode, to alert the diver of a dangerous situation: the battery may not have enough energy to finish a dive. •...

  • Page 16: Switching Off The Display

    Operation / SOS 2.11 Switching off the display From the time of day display you can switch off SPORT by pushing On the surface SPORT switches off automatically after 3 minutes without operation. 2.12 Alarm clock The alarm clock goes off only at the surface. If the alarm clock is "on", the time of day display shows When alarm is triggered: flashes and special attention beeps are played for 30 seconds or until...

  • Page 17: Diving With Sport

    III Diving with SPORT Diving with SPORT 1 Terminology / Symbols The information on the display of SPORT varies depending on the kind of dive and the dive phase. 1.1 General terminology / Display during no-stop phase Decompression phase No-stop phase Current depth In metres (feet) Dive phase during which...

  • Page 18: Nitrox Information (O Information)

    Terminology / Symbols 1.3 Nitrox information (O information) For dives with compressed air in normal recreational diving, nitrogen is the decisive gas for the decompression calculations. When diving with Nitrox, the risk of oxygen toxicity rises with the increase of the fraction of oxygen and the increase of depth and can limit dive time and the maximum depth. SPORT includes this in the calculations and displays the necessary information: % mix Fraction of oxygen: The fraction of oxygen in the Nitrox mixture can be set between...

  • Page 19: Attention Messages And Alarms

    Attention messages and alarms 2 Attention messages and alarms SPORT draws the diver’s attention to certain situations and warns the diver of unsafe diving practices. Attention messages and alarms are visual and / or audible. • The audible attention messages can be switched off in "set 1" ->33 or LogTRAK. With LogTRAK they can be switched off selectively.

  • Page 20: Preparation For The Dive

    Preparation for the dive 3 Preparation for the dive You have to check the settings of SPORT especially before the first dive. All settings can be checked and changed directly at SPORT or via LogTRAK. 3.1 Setting the gas mixture and ppO ! WARNING Before every dive and after changing the tank, make sure that the settings for the gas mixture correspond with the current mixture used.

  • Page 21: Functions During The Dive

    Functions during the dive 4 Functions during the dive 4.1 Immersion If the water contacts are deactivated (->33), switch on SPORT before immersion. ! WARNING If you have chosen the option "Water contacts off" ("set 1" or LogTRAK), SPORT will turn on with a delay of up to 1 minute into the dive.

  • Page 22: Ascent Rate

    Functions during the dive 4.5 Ascent rate Optimal ascent rate varies depending on depth between 7 and 20m/min DEPTH DIVE TIME (23 and 67ft/min). It is displayed as a percent of the reference variable ascent rate. If the ascent rate is greater than 100% of the set value, the black arrow NO STOP "SLOW"...

  • Page 23: Partial Pressure Of Oxygen

    Functions during the dive 4.6 Partial pressure of oxygen (ppO max) / Maximum Operating Depth (MOD) The maximum partial pressure of oxygen ppO max (default 1.4bar) determines the Maximum Operating Depth (MOD). Diving deeper than the DEPTH DIVE TIME MOD will expose the diver to oxygen partial pressures higher than the set maximum level.

  • Page 24: Nitrogen Loading Bar Graph

    Functions during the dive • During an ascent and if the CNS O % value does not increase anymore (due to a lower partial pressure of oxygen), the audible warning is suppressed. • During the ascent, the display of the oxygen toxicity is replaced by the ascent rate. If the ascent is stopped, the display changes back to the indication of the CNS value.
  • Page 25 Functions during the dive Decompression values Decompression obligation DECO On entering the decompression phase, "NO STOP" disappears, the STOP symbol appears and an attention beep goes off. The nitrogen loading DEPTH DIVE TIME bar stops flashing and the 6th segment lights up (red area). The deepest decompression stage in metres (feet) is displayed and the decompression DECO stop duration of the displayed stage appears in minutes.

  • Page 26: Safety Stop Timer

    Functions during the dive / Functions at the surface 4.10 Safety stop timer DEPTH DIVE TIME The safety stop timer displays the time span a diver should spend at the safety stop depth at the end of the dive. The timer is activated by the diver and counts back from 3 minutes to zero.

  • Page 27: Diving In Mountain Lakes

    Functions at the surface / Diving in mountain lakes ! WARNING If the "no-dive" warning is visible during the surface interval, the diver should not undertake another dive. To check the remaining desaturation time and oxygen toxicity press DESAT To check the elapsed surface interval CNS O press Desaturation time...

  • Page 28: Prohibited Altitude

    Diving in mountain lakes Switching at approx. No deco data gauge mode 4000m 610mbar 13120ft 8.85psi 3000m 725mbar 9840ft 10.51psi 2000m 815mbar 6560ft 11.82psi 1000m 905mbar Altitude ranges 3280ft 13.12psi 6.2 Prohibited altitude ! WARNING Flying while SPORT displays "do not fly" may lead to serious injury or Ascent to altitude range death from decompression sickness.

  • Page 29: Dive Planner

    Dive planner IV Dive planner PLn: SPORT has a dive planner which allows the planning of no-stop dives. Basis of the planning: • selected fraction of oxygen and MOD • water temperature of the most recent dive • altitude range (if any) •...

  • Page 30: Logbook

    V Logbook Logbook 1 Survey A dive is entered in the logbook if the dive time is longer than 2 minutes. SPORT records the profiles of about 25 hours of diving. This information can be transferred to a PC with the standard infrared ®...
  • Page 31 Operation Page 2 Altitude range (if >0) Repetitive dive number Starting time CNS O CNS value at the end of the dive Minimum temperature Push to get more information about the dive. Page 3 SOS if applicable If a dive is started within adaptation time (after a change of altitude), the adaptation time is displayed instead of the surface interval.

  • Page 32: Settings

    VI Settings Settings 1 Menu "set 1" With menu "set 1" or LogTRAK you can configure the following items (dive functions): Setting Range Default Page • Maximum partial pressure of oxygen (ppO max) 1.2-1.6bar 1.4bar • Time limit to reset the O % mix to air no reset / 1 - 48hrs no reset...
  • Page 33 Settings Switching the audible attention signals on and off With this option you can switch off the audible attention signals only (the audible alarms remain active). Refer to page 19 to see this distinction. 1. Confirm that you wish to change the setting of the audible attention signals by pushing .

  • Page 34: Menu "Set 2

    Settings 2 Menu "set 2" With menu "set 2" or LogTRAK you can configure the following items: Setting Range Default Page • Alarm clock 0 - 23h 59min, on/off 12:00, off • UTC zone ±13hrs, increments: 15min • Time of day hours:minutes •...
  • Page 35 Settings Selecting 24 hours or AM/PM setting 1. Confirm that you wish to change the setting by pushing "On" or "off" starts to flash. 2. Switch with between "on" (AM/PM) and "off" (24h). 3. Confirm the setting with The 24h - AM/PM setting influences the display of the date (see below). Adjusting the date Date (24h setting) 1.
  • Page 36 Settings 4. Set the first digit by pushing . Confirm with Repeat point 4 for the next 2 digits. If you entered the right code the sound will be turned off. Code: 313 Setting the "sound" to "off" applies also to surface functions (mountain alarm, wake-up alarm, change of altitude range).

  • Page 37: Safety Stop Time / Gauge Mode / Apnea Mode

    Safety Stop Time / Gauge Mode / Apnea Mode VII Safety Stop Time / Gauge Mode / Apnea Mode Quick reference Time of day / Date Decompression depth / Level stop depth Setting icon Desaturation time (DESAT) Service icon No-dive warning Duration of no-dive warning Duration of surface interval Current depth...

  • Page 38: Safety Stop Timer

    Safety Stop Time / Gauge Mode / Apnea Mode 1 Safety stop timer ! WARNING On all dives with Scubapro SPORT, make a safety stop for at least three minutes at a depth of 5m (15ft). DEPTH DIVE TIME STOP CNS O Safety Stop Remaining time span...

  • Page 39: Gauge Mode

    Supervision of ppO 2 max and CNS O 2 % will also be switched off. Aladin SPORT will display no information about microbubble development. The settings for the gas mixture, MOD and microbubble level cannot be set and the dive planner cannot be selected.
  • Page 40 Minutes Seconds In gauge mode, after immersion, Aladin SPORT will automatically monitor the dive time and at the same time activate the stopwatch. The stopwatch will run for a maximum of 24 hours. Resets time and starts stopwatch from zero.

  • Page 41: Apnea Mode

    “ALGO” is displayed. (If Aladin SPORT shows “ – – – ” the gauge mode cannot be switched “on” or “off”. Aladin SPORT shows “ – – – ” for 48 hours after a dive in gauge mode and as long as there is remaining desaturation after a dive in computer mode.)

  • Page 42: Diving In Apnea Mode

    2. Make only apnea dives which your education and physical condition allow. In apnea diving fast descents and ascents are allowed. Therefore Aladin SPORT uses faster sampling of the depth for higher accuracy. Aladin SPORT updates display and maximum depth every 15 seconds, logbook is updated every second.

  • Page 43: Menu "Set 3" (Apnea)

    Surface mode can be stopped with long press Aladin SPORT Apnea mode has special alarms and functions tailored to Apnea diving and Apnea training. You can select multiple alarm functions at the same time. The alarm functions setup is explained in page ->...
  • Page 44 Safety Stop Time / Gauge Mode / Apnea Mode Setting the incremental depth alarm With this alarm you can set repetitive depth alarms at given depth increments. 1. Confirm that you wish to change the settings of the incremental depth alarm by pushing Increment value starts to flash.
  • Page 45 Safety Stop Time / Gauge Mode / Apnea Mode Setting the Ascent Speed alarm With this alarm you can set ascent speed alarm. 1. Confirm that you wish to change the settings of the Ascent Speed alarm by pushing Time value starts to flash. 2.

  • Page 46: Appendix

    Appendix VIII Appendix 1 Technical information Operating altitude: With decompression information: sea level up to approx. 4000m (13 000ft); without decompression, above approx. 4000m (13000ft): automatic gauge mode (unlimited) Max displayed depth: 120m (395ft), resolution between 0.8m and 99.9m: 0.1m, >99.9m: 1m. The resolution in feet is always 1 foot.

  • Page 47: Replacing The Battery (Battery Kit Includes Battery And Teflon Coated O-Ring)

    Appendix 2.1 Replacing the battery (Battery kit includes battery and Teflon coated o-ring) ! WARNING Removing the battery clears all physiological data including saturation. This means that for a repetitive dive the computer will not compute correctly. Diving after replacing the battery when there is desaturation time left on the computer can lead to serious injury or death from decompression sickness.
  • Page 48 Appendix are free of dust and dirt. If necessary, clean the parts with a soft cloth. Fit the o-ring in the o-ring groove of the battery cap. ! WARNING 7. Use only an original Scubapro o-ring. This o-ring is Teflon coated and does not require additional lubrication.

  • Page 49: Warranty

    Appendix 3 Warranty The warranty only covers dive computers which have been bought from an authorized Scubapro retailer. The warranty is given for a period of two years. Repairs or replacements during the warranty period do not increase the warranty period. In order to put forward a warranty claim: send the dive computer together with a dated receipt of the purchase to your authorized retailer or an authorized servicing point.

  • Page 50: Index

    Appendix 4 Index Surface interval ___________________ 14, 29, 30 System __________________________________9 Active backlight __________________________15 Technical information _____________________36 Alarm clock _________________________ 16, 34 Time of day (display) __________________ 13, 34 AM/PM _________________________________35 Unit system _____________________________32 Ascent rate __________________________ 19, 22 UTC ____________________________________34 Audible attention signals_______________ 19, 33 Warnings _______________________________19 Backlight ________________________________15...
