9.2.9 AC/DC Drive Object - Class 0x2A (42 dec)
Attribute ID
1
2
1
2
3
4
6
7
8
9
15
16
17
29
Service Code
0x0E
0x10
CMVETH01B
Reference
AC/DC DRIVE CLASS ATTRIBUTES
Access Rule
GET REVISION
GET NUMBER OF INSTANCES
GET NO. OF SUPPORTED ATTRIBUTES
GET ATTRIBUTE LIST
GET AT REFERENCE
GET/SET NET REFERENCE
GET DRIVE MODE
GET ACTUAL SPEED
GET/SET SPEED REFERENCE
GET MOTOR PHASE CURRENT
GET MOTOR PHASE CURRENT
GET INPUT VOLTAGE
GET OUTPUT VOLTAGE
GET STATUS OF SPEED REFERENCE
AC DRIVE CLASS SERVICES
Implemented For
Class Instance
YES YES
NO YES
Name Data Type
INSTANCE 0
UINT
UINT
INSTANCE 1
USINT
ARRAY
BOOL
BOOL
USINT
INT
INT
INT
INT
INT
IN
INT
Service Name
Get_Attribute_Single
Set_Attribute_Single
68
Value
1
1
12
Speed AtRef
0 = Local SpdRef
1 = Net SpdRef
1 = Open Loop Spd Control
2 = Vector Mode
3 = Torque Mode
4 = PID Mode
Actual Speed (RPM)
Speed Reference (RPM)
Actual Current (0.1A)
Actual Power (W)
(V)
(V)
0 = Local Spd Ref
1 = Net Spd Ref
