4.2.7 TTL Value
P426 TTL Value
Default: 1
Access: RW
Set P426 to the required value. The default TTL value is 1. The TTL value defines the number of hops the
multicast message is allowed to propigate across routes. Consult your IT department for the proper setting
for your particular network installation.
4.2.8 Configuration Control
P427 Configuration Control
Default: 0
Access: RW
Set P427 to the required value. The default value is 0 (stored). A value of 1 = DHCP control.
4.2.9 Duplex Control
P428 Duplex Control
Default: 1
Access: RW
Set P428 to the required value. The default value is 1 (full duplex). A value of 0 = half duplex control.
4.2.10 Interface Speed Control
P429 - Interface Speed Control
Default: 1
Access: RW
The SMV EtherNet/IP module automatically detects and synchronises to the speed of the network to which
it has been connected. The P429 value represents the detected speed: 1 = 100Mbps, 0 = 10Mbps speed.
4.2.11 Non-Module Parameter Settings
In addition to configuring the EtherNet/IP option module there are several drive based parameters that may
need to be set. Such as:
• P100 - Start Control Source; network control is possible in any of the modes except mode 2 - "Remote
Keypad Only".
• P112 - Rotation; Used to enable either uni or bi direction rotation of the motor.
• P121, 122 or 123 = 9. One of the digital inputs MUST be assigned to mode 9 - "Network Control" and
have the corresponding input closed to enable write access to the drive parameters and to perform any
network control of the unit.
CMVETH01B
Commissioning
Range: 1 - 255
Type: Integer
Range: 0, 1
Type: Integer
Range: 0 - 1
Type: Integer
Range: 0 or 1
Type: Integer
18
