Stryker InTouch FL27 series Maintenance Manual page 174

Standard Siderail Assembly, Head End, Left
Standard SIderail Assembly, Head End, Left - Common Components - 27-2288 Rev-04 (Reference only)
Item
1
3
4
5
6
7
8
9
12
14
15
16
17
18
19
20
22
23
24
25
26
27
28
29
30
31
32
34
35*
36*
37*
39*
40
41*
42*
43*
44
45
46*
47*
Return To Table of Contents
174
Part No. Part Name
QPA28-0493 Siderail Sleeve
QDF27-1099 Siderail Nurse Control Board
QDF27-2574Z Siderail Lock
27-2575Z Switch Support
27-2060W Siderail Mechanics S.A.
QDF2049 Spacer ID 1.25 OD 1.406 WI 3/8
QDF27-1097 Brake Control Board
QDF27-2238 Left Head Nurse Control Fascia
QDF28-0491 Machining Spacer QDF9191
QDF9183 Electronic Board Button
27-2293Z Switch Guide 1
QP27-1109-10 Brake Board Support
QP27-1111 Nurse Control Board Support
QP27-2226-05 Left Head Siderail
QP27-1266 -05 Left Head Siderail Cover
QP27-1274-08 Left Siderail Handle
QP27-1496-05 Head Siderail Cap
QP28-0039-10 Siderail Rotation Lever Cover
QPA27-2296 Left Head Siderail Structure
QPA28-0015 Siderail Sleeve
QPA28-0016 Sleeve with Lock
QRE27-1736 Spring Balance
VV10A0G16-S Hexagon Socket Hd. Screw, #10-32 x 1/2" 2
VV10B0G40-S Hexagon Socket Hd. Screw,#10-32 x 1-1-2" 4
VV10A1P20-S Hexagon Socket Hd. Screw 3/8-16 x 5/8"
VV23A9C12HL Pan Hd. Screw Type Hi-Lo #6 x 3/8
VV31A0G16 Flat Hd. Machine Screw #10 x 1/2"
VVB3A9N24PF Bosscrew Screw 1/4" x 3/4"
QDF27-1156 Brake Board Cable
QDF27-2212 Head Siderail Wire
QDF9518 Cable Tie
QDF27-1521 Siderail Limit Switch S.A.
27-1839 Side Ring
QDF2088 Polarized 6-Position Connector
QDF9028 3-Position Connector
QDF2087 2-Position Connector
VV23A9C20HL Pan Head hi-Low Screw #6 x 5/8
VV87A9A20 Truss Head Tapping Screw #4 x 5/8"
M0019 OG2 Grade Grease
QDF2127 2 Pins Connector
2131-409-002 REV C
Qty.
1
1
1
1
1
4
1
1
1
20
1
1
1
1
1
1
1
2
1
1
1
1
1
22
2
5
1
1
1
1
1
1
1
1
8
1
1
1
www.stryker.com
