5. Once the Extended Battery Cabinet is in the
desired location, adjust the leveling feet to
secure its position.
Stationary Mounting
Additional stability can be added by bolting the
mounting brackets (used in shipping) to the floor.
Optional Stationary Mounting
For greater stability, use a higher-grade bolt. Refer
to the dimensions below when drilling holes for
stationary mounting.
1/2"
(13 mm)
(711 mm)
6
4.75"
(120 mm)
28"
4.75"
(120 mm)
5/16" diameter
(7.94 mm)
6 places
