Intel® Server Board S1200SP Family Technical Product Specification
IFlash32.EFI
-
RML.ROM
-
######.CAP (where #### = BIOS revision number, any cap file is suitable to make the recovery)
-
STARTUP.NSH
-
2. Power OFF the system.
3. Locate the BIOS Recovery Jumper on the server board and move the jumper block from pins 1-2
(default) to pins 2-3 (recovery setting).
4. Insert the recovery media into a USB port.
5. Power ON the system.
6. The system will automatically boot into the embedded EFI Shell.
7. The STARTUP.NSH file automatically executes and initiates the flash update. When complete, the
IFlash utility will display a message.
8. Power OFF the system and return the BIOS Recovery jumper to its default position.
9. Power ON the system.
10. Do *NOT* interrupt the BIOS POST during the first boot.
11. Configure desired BIOS settings.

9.3 Password Clear Jumper (J1F4)

This jumper causes both the User password and the Administrator password to be cleared if they were set.
The operator should be aware that this creates a security gap until passwords have been installed again
through the BIOS Setup utility. This is the only method by which the Administrator and User passwords can
be cleared unconditionally. Other than this jumper, passwords can only be set or cleared by changing them
explicitly in BIOS Setup or by similar means. No method of resetting BIOS configuration settings to default
values will affect either the Administrator or User passwords.
1. Power down the server and unplug the power cords.
2. Open the chassis and remove the Riser #2 assembly.
3. Move jumper from the default (pins 1 and 2) operating position to the password clear position (pins 2
and 3).
4. Close the server chassis and reattach the power cords.
5. Power up the server and wait until POST completes.
Note: BIOS Error Manager should report a 5224 and 5221 error codes (Password clear jumper is set
and Passwords cleared by jumper).
6. Power down the server and unplug the power cords.
7. Open the chassis, remove the Riser #2 assembly, and move the jumper back to the default position
(covering pins 1 and 2).
8. Reinstall the Riser #2 assembly.
9. Close the server chassis and reattach the power cords.
10. Power up the server.
87
