Table Of Contents - Beijer Electronics BoX2 extreme Installation Manual

Contents
1 Safety Precautions ....................................................... 7
1.1 General ........................................................... 7
1.2 Hazardous Materials ............................................. 7
1.3 Disposal Requirements Under WEEE Regulations ........... 8
1.4 UL and cUL Installation ......................................... 8
1.5 IECEx/ATEX Certificate and Dust Rating .................... 9
1.6 Conditions of Safe Use for Zone 2/22 ATEX/IECEx .......... 9
1.7 During Installation .............................................. 9
1.8 During Use ....................................................... 10
1.9 Service and Maintenance ........................................ 10
1.10 Dismantling and Scrapping ..................................... 10
2 Installation ............................................................... 11
2.1 Installation Process .............................................. 11
2.1.1
2.1.2
2.1.3
3 Technical Data ........................................................... 15
4 Chemical Resistance .................................................... 17
4.1 Metal Casing ..................................................... 17
5 Operator Panel Drawings .............................................. 19
5.1 Connectors ....................................................... 19
5.1.1
5.1.2
5.1.3
5.1.4
5.1.5
5.2 BoX2 extreme Outline .......................................... 21
6 Additional Installation Tips ............................................ 23
6.1 Grounding the operator panel .................................. 23
6.2 To Achieve Better EMC Protection ............................. 23
6.3 Safety ............................................................. 25
6.4 Galvanic Isolation ................................................ 26
6.5 Cable and Bus Termination RS-485 ............................ 27
Beijer Electronics, MAEN276
Protective Connector Shield Installation Process . . . . . . . . . . . . . . .13
Connections to the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Other Connections and Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
COM A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
USB 1/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LAN A / LAN B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
COM B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Contents
