5

Operator Panel Drawings

5.1

Connectors

1
Pos Connector
1

Power supply

2 COM B
3 USB 1 + USB 2
4 LAN A
5 LAN B
6

COM A

5.1.1
Pin Description
1 V +
in
2 V -
in
3 V -
in
4 V +
in
5.1.2
Pin COM 1
1
2 RS232_RxD
3 RS232_TxD
4
5 GND
6
7 RS232_RTS
8
Beijer Electronics, MAEN276
2 3
Description
+24 V DC
Serial communication port
USB Host 2.0, max output current 500 mA
1 × 10/100 Base-T
1 × 10/100 Base-T
Serial communication port
Power Supply
COM A
COM 2
RS422 Tx+
RS485 Tx+/Rx+
-
-
RS422_Rx+
GND
RS422 Tx-
RS485 Tx-/Rx-
-
RS422_Rx-
Operator Panel Drawings
4 5 6
M12. 4 pin male
COM 3 M12, 8 pin male
CAN-H
-
-
-
-
CAN-L
-
-
19
