G series, IP address, Subnet and Gateway Setting

1 Function and area of use

In this document we show how to set IP address, Subnet Mask and Gateway for
G-Series network modules GN-9372 and GN-9289.

2 About this Start Up document

Copyright © Beijer Electronics, 2019
This documentation (below referred to as 'the material') is the property of Beijer Electronics. The holder or
user has a non-exclusive right to use the material.
The holder is not allowed to distribute the material to anyone outside his/her organization except in cases
where the material is part of a system that is supplied by the holder to his/her customer.
The material may only be used with products or software supplied by Beijer Electronics.
Beijer Electronics assumes no responsibility for any defects in the material, or for any consequences that
might arise from the use of the material.
It is the responsibility of the holder to ensure that any systems, for whatever applications, which is based on
or includes the material (whether in its entirety or in parts), meets the expected properties or functional
requirements.
Beijer Electronics has no obligation to supply the holder with updated versions.
This Start Up document should not be considered as a complete manual. It is an aid to be
able to start up a normal application quickly and easily.
Use the following software and drivers in order to obtain a stable application:
In this document we have used following hardware and software
• GN-9372 and GN-9289
• BootpServerVer1000_Beijer
• Windows 7 64 bit
For further information we refer to
• GN-9372 Manual
• GN-9289 Manual
This document and other Start Up documents can be obtained from our homepage.
Please use the address manual@beijer.se for feedback on our Start Up documents.
Beijer Electronics AB − a Beijer Group company
Head Office
Beijer Electronics AB
P.O. Box 426, Stora Varvsgatan 13a
SE-201 24 Malmö, SWEDEN
Telephone +46 40 35 86 00
www.beijerelectronics.se  info@beijerelectronics.se
Link to BootP
Link
Link
Subsidiaries
Norway, Drammen: Beijer Electronics AS,  +47 32 24 30 00
Denmark, Roskilde: Beijer Electronics A/S,  +45 75 76 66
KI00389 2019-04
1 (9)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G Series and is the answer not in the manual?

Questions and answers

Related Manuals for Beijer Electronics G Series

Summary of Contents for Beijer Electronics G Series

  • Page 1: Function And Area Of Use

    2 About this Start Up document Copyright © Beijer Electronics, 2019 This documentation (below referred to as ‘the material’) is the property of Beijer Electronics. The holder or user has a non-exclusive right to use the material. The holder is not allowed to distribute the material to anyone outside his/her organization except in cases where the material is part of a system that is supplied by the holder to his/her customer.

  • Page 2: Table Of Contents

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 3 Table of Contents 1 Function and area of use ............................1 2 About this Start Up document ..........................1 3 Table of Contents ..............................2 4 Setup Network address in PIO (GN-9372) ......................3 Network setting (default) ..........................

  • Page 3: Setup Network Address In Pio (Gn-9372)

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 4 Setup Network address in PIO (GN-9372) Network addresses can be set with Bootp, Web or DHCP server. Network setting (default) Default Setting IP Address 192.168.1.50 Subnet Mask 255.255.255.0 Gateway 0.0.0.0...

  • Page 4: Set The Ip (Network Addresses) With The Built-In Web Server

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 Set the IP (network addresses) with the built-in Web Server Easiest way to configure the PIO is to use the built-in Web Server. Default IP address as seen below.

  • Page 5: Set The Ip-Address With Bootp Server (Alternative Method)

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 Set the IP-address with BootP server (alternative method) For best results, be sure to disable all other network connections, including wifi on your computer! see chapter “Trouble Shooting” • Download BootP software Link to BootP •...

  • Page 6: Setup Network Address In Gn-9289

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 5 Setup Network address in GN-9289 Network addresses can be set with Bootp or DHCP server. Network setting (default) Default Setting IP Address 192.168.1.100 Subnet Mask 255.255.255.0 Gateway 0.0.0.0 Set the IP (network) to default setting Default setting can be done with Modbus command “Diagnostics (FNC 8)”.
  • Page 7 G series - IP address, Subnet and Gateway Setting KI00389 2019-04 5.3.1 Add New Device (IP address, Subnet Mask and Gateway) with BootP • Click “Start Bootp” and Power ON to GN-9289 The MAC address is shown 20 times (in 40 seconds).

  • Page 8: Troubleshooting And Tips

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 6 Troubleshooting and Tips! Network Connections • Enable the Network connection that should be used for communication to the unit´s • Disable all other network connection • Make sure the PC are on the same IP segment as the PIO.

  • Page 9: Windows Firewall

    G series - IP address, Subnet and Gateway Setting KI00389 2019-04 Windows Firewall • Control panel \ System and security \Windows Firewall • Allow communication with “bootpserver” Antivirus Software • There is antivirus software that blocks such as IP setting and firmware update.
