Summary of Contents for Beijer Electronics X2 extreme 15 SL HP

  • Page 1 X2 extreme 15 SL HP English MAEN263, 2020-01...
  • Page 2 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, including all its group companies, assumes no responsibility for any errors that may appear in this document.
  • Page 3: Table Of Contents

    COM B ............21 Connectors ............21 X2 extreme 15 SL HP Outline ........22 7 Additional Installation Tips ..........23 Grounding the operator panel ........
  • Page 4: Safety Precautions

    Toxic and hazardous materials or elements 零件描述 有毒和有害的材料或元素 Cr6+ PBDE PCB and electronic components PCB 和电子元件 O: Indicates that this toxic or hazardous substance contained in all of the homogenous materials for this part is below the limit requirement in SJ/T 11363–2014. Beijer Electronics, MAEN263...
  • Page 5: Disposal Requirements Under Weee Regulations

    CE PRODUIT CONTIENT UNE PILE QUI NE PEUT PAS ÊTRE REMPLACÉE PAR L'UTILISATEUR. Warning: Explosion hazard! Substitution of components may impair suitability for Class I, Division 2. RISQUE D'EXPLOSION! LA SUBSTITUTION DE COMPOSANTS PEUT NUIRE À LA CONFORMITÉ DE CLASSE I, DIVISION 2. Beijer Electronics, MAEN263...
  • Page 6: Iecex/Atex Certificate And Dust Rating

    During Use • Keep the operator panel clean. • Emergency stop and other safety functions may not be controlled from the operator panel. • Do not use excessive force or sharp objects when operating the touch screen. Beijer Electronics, MAEN263...
  • Page 7: Service And Maintenance

    • Clean the display and surrounding front cover with a soft cloth and mild detergent. • The battery must be replaced by an authorized Beijer Electronics service center. 1.10 Dismantling and Scrapping • The operator panel or parts thereof shall be recycled according to local regulations.
  • Page 8: Naming Convention

    X2 extreme 7 SL HP* • X2 extreme 12 SL HP SC* • X2 extreme 7 CO* • X2 extreme 12 SL HP RO Note: Not all combinations are available. Note: * indicates variants including IECEx\ATEX and C1D2 accreditation. Beijer Electronics, MAEN263...
  • Page 9: Installation

    Installation Installation Installation Process Measurement X2 extreme 15 SL HP 100 × 100 mm Hole size 5.5 ± 0.5 mm Thread type M5 × 0.8 mm Max thread depth 8 mm Min required engagement 5 mm Torque (max) 3.5 Nm The following is needed: •...
  • Page 10 3. Drill the correct hole pattern in panel outlined above or install unit on VESA compliant mounting bracket. Connect cable A to the terminal, using 14-20 AWG (2.08–0.52 mm – 180–220 N-cm torque. Note: Use minimum 85°C copper conductors only. Beijer Electronics, MAEN263...
  • Page 11: Protective Connector Shield Installation Process

    X2 extreme mm OD, -30° 992-04 Connector, C to 70° C M12 SS 4p female 5.5-7.5 mm Gland (Power) Type 4X, C1D2 Environments (M12 connector with cable gland) 3.1.1 Protective Connector Shield Installation Process Do the following: Beijer Electronics, MAEN263...
  • Page 12 Installation 1. Install the protective connector shield as shown. 2. Secure the cables to the protective connector shield using the included cable ties Note: The protective connector shield is required to be used on all applications. Beijer Electronics, MAEN263...
  • Page 13: Connections To The Controller

    file for the driver in question. 3.1.3 Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Beijer Electronics, MAEN263...
  • Page 14: Technical Data

    Technical Data Technical Data Parameter X2 extreme 15 SL HP Dimensions, W × H × D 411 × 286 × 65 mm Sealing IP66 (IP65 for IECEx \ ATEX) Touch screen Polyester on glass, ITO film, resistive material Frame overlay Autoflex EBA 180L...
  • Page 15 Technical Data Parameter X2 extreme 15 SL HP Power supply +24 V DC CE: The power supply must conform with the requirements according to EN/IEC 60950 and EN/IEC 61558-2-4. UL and cUL: The power supply must conform with the requirements for class 2 power supplies.
  • Page 16: Chemical Resistance

    Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octane unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octane leaded petrol Touch Screen and Overlay Material 5.2.1 Protective Film Autoflex EBA 180L covers the overlay surrounding the screen. Beijer Electronics, MAEN263...
  • Page 17 The Autoflex protective film is not resistant to high pressure steam at over 100 °C or the following chemicals: Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Methylene chloride Beijer Electronics, MAEN263...
  • Page 18: Touch Screen Surface

    5.2.3 Touch Screen Protector For harsh environments and exposure to outdoor conditions, it is recommended to use a protective film to guard the touch screen from damage. This optional part can be ordered from Beijer Electronics. Beijer Electronics, MAEN263...
  • Page 19: Operator Panel Drawings

    RS-232, and RS-422 or 2×RS-485 or 2×CAN. The connector supports up to two independent serial communication channels and can be configured for RS-232, and RS-422 or RS-485 or CAN. COM B D-sub-9, female COM 3 RS-485 Tx+/Rx+ CAN-H TERM+ TERM+ Beijer Electronics, MAEN263...
  • Page 20: Power Supply

    RS422 Tx+ CAN-H RS485 Tx+/Rx+ RS232_RxD RS232_TxD RS422_Rx+ RS422 Tx- CAN-L RS485 Tx-/Rx- RS232_RTS RS422_Rx- Note: The connector supports up to two independent serial communication channels and can be configured for RS232, and RS422 or RS485 or CAN. Beijer Electronics, MAEN263...
  • Page 21: Usb 1/2

    LAN A / LAN B LAN A LAN B M12, 4pin female 6.1.6 COM B COM 3 M12, 8 pin female RS-485 Tx+/Rx+ CAN-H TERM+ TERM+ RS-485 Tx-/Rx- CAN-L TERM- TERM- Note: The connector supports galvanic isolated RS485 or CAN. Connectors Beijer Electronics, MAEN263...
  • Page 22: X2 Extreme 15 Sl Hp Outline

    Operator Panel Drawings X2 extreme 15 SL HP Outline Note: A Step CAD file is available on the web site www.beijerelectronics.com Beijer Electronics, MAEN263...
  • Page 23: Additional Installation Tips

    A braided conductor wire with the same area is even better. The best is a short, thick grounding braid. To Achieve Better EMC Protection • Initially, use the original cabling from Beijer Electronics primarily. • Use shielded M12 cables Beijer Electronics, MAEN263...
  • Page 24 230/380 V AC in another. If the cables need to be crossed, cross them at 90° only. Avoid combining the cabling for stronger 24 V DC outputs with the communication cabling. • Initially, use the original cabling from Beijer Electronics primarily. • Use shielded cables for RS-232 communication. •...
  • Page 25 Non-energized after 80 cm 60 cm magnetization Energized and operating 80 cm 55 cm Condition Standard Compass Steering Compass Non-energized 75 cm 55 cm Non-energized after 80 cm 55 cm magnetization Energized and operating 75 cm 55 cm Beijer Electronics, MAEN263...
  • Page 26 Non-energized after 70 cm 45 cm magnetization Energized and operating 60 cm 40 cm Condition Standard Compass Steering Compass Non-energized 80 cm 60 cm Non-energized after 100 cm 70 cm magnetization Energized and operating 85 cm 65 cm Beijer Electronics, MAEN263...
  • Page 27: Safety

    Transients on the 24 V feed are connected to the ground. • No risk that the 24 V feed is at a high level in relationship to the ground. This is not unusual since there is high static electricity. Beijer Electronics, MAEN263...
  • Page 28: Galvanic Isolation

    RS-422/RS-485 and USB. Only the Ethernet connection has galvanic isolation. The operator panel has galvanic isolation against the 24 V DC power supply but no galvanic isolation between the communication ports for RS-232, RS-422/RS-485 and USB. Only the Ethernet- and RS-485 connection have galvanic isolation. Beijer Electronics, MAEN263...
  • Page 29 24 V feed, disturbances and grounding currents from the 0 V on the 24 V side disrupt the communication. Using this type of unit solves one problem but creates a larger problem! A substandard installation may work now, but problems may arise when other devices are connected. Beijer Electronics, MAEN263...
  • Page 30: Cable And Bus Termination Rs-485

    Depending on the recipients’ design, the bus wires may be on the same level or require pull-up or pull-down to ensure that no faulty signals are detected when the bus is in resting mode (all transmitters are disconnected). Beijer Electronics, MAEN263...
  • Page 31 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
