Technical Data

Parameter
Dimensions, W × H × D
Sealing
Frame material
Weight
CPU
Serial port COM A
Serial port COM B
Ethernet LAN A
Ethernet LAN B
USB
External storage
media
Flash memory
(application
memory)
Memory RAM
NVRAM
Real time clock
Battery
Power consumption
at rated voltage
Fuse
Power supply
Operating
temperature
Storage temperature
Relative humidity in
operation
Vibration
Mechanical shock
Beijer Electronics, MAEN276
BoX2 extreme
234 × 183 × 62 mm
IP65
Powder-coated aluminum
1.5 kg
i.MX 6Quad
Quad ARM Cortex-A9 Core
1.0 GHz
1 MB L2 cache
M12 (8 pin, male)
1×RS-232 Rx/Tx with RTS (no CTS) and 1×RS-422, or
2×RS-485 or 1×CAN 2.0B
M12 (8 pin, female)
1×RS-485 with isolated +5V/5mA out for bias resistor
network, or 1×CAN 2.0B with termination
M12 (4 Pin, female, D-coded according to EN/IEC
61076-2-101) 10/100 Mbit via RMII
M12 (4 Pin, female, D-coded according to EN/IEC
61076-2-101) 10/100 Mbit via RMII
Supports up to USB 2.0 High Speed
1 × SD card
3.5 GB SSD (eMMC)
2 GB DDR3
64 kB
Yes
BR 2477A/GAN lithium battery,
non replaceable
8 W
Internal DC fuse, 4 AT SMT
+24 V DC
CE: The power supply must conform with the requirements
according to EN/IEC 60950 and EN/IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class 2 power supplies.
-30°C to +70°C
-40°C to +80°C
5% – 95% non-condensation
4g, according to EN/IEC 60068-2-6, Test Fc
40g, half-sine, 11ms according to EN/IEC60068-2-27
