Start-Up Checklist - Copley Controls Xenus Plus Compact Manual

Xenus Plus Compact STO Manual
7.2.2

Start-Up Checklist

Chk Requirement
Ensure that the drive can be run and stopped freely during the
commissioning.
Stop the drive (if running), and safely remove AC power from the drive.
Check the STO-IN1 and STO-IN2 circuits and connections against a
wiring diagram.
Apply AC mains power to the drive. Energize both the STO-IN1 and
STO-IN2 circuits.
Test the operation of the STO-IN1 function when the motor is stopped.
Give a stop command for the drive (if running) and wait for the motor to
come to a standstill.
While keeping STO-IN2 energized, de-energize the STO-IN1 circuit and
give a start command for the drive. Ensure that the motor remains at a
standstill.
Energize the STO-IN1 circuit.
Test the operation of the STO-IN2 function when the motor is stopped.
Give a stop command for the drive (if running) and wait for the motor to
come to a standstill.
While keeping STO-IN1 energized, de-energize the STO-IN2 circuit and
give a start command for the drive. Ensure that the motor remains at a
standstill.
Energize the STO-IN2 circuit.
Restart the drive and check that the motor runs normally
Test the operation of the STO-IN1 function when the motor is running:
Start the drive and ensure that the motor is running. While keeping
STO-IN2 energized, de-energize the STO-IN1 circuit. Ensure that the
motor stops. Reset any latching fault that may have occurred (these
depend on the drive's control mode settings). Try to start the drive.
Ensure that the motor stays at a standstill. Energize the STO-IN1 circuit
Test the operation of the STO-IN2 function when the motor is running:
Start the drive and ensure that the motor is running. While keeping
STO-IN1 energized, de-energize the STO-IN2 circuit. Ensure that the
motor stops. Reset any latching fault that may have occurred (these
depend on the drive's control mode settings). Try to start the drive.
Ensure that the motor stays at a standstill. Energize the STO-IN2 circuit
Restart the drive and ensure that the drive and motor operate normally.
Page 23 of 31
Table 10
16-01553 Rev 00
Comments Initials
Copley Controls
