Table Of Contents - Jandy CJ200 Installation And Operation Manual

Cartridge Filters - CJ Series Filter
Section 1. Safety Information ........................... 4
1.1 Important Safety Warning ........... 4
1.2 General Safety Instructions ......... 4
Section 2. General Information......................... 5
2.1 Introduction ................................. 5
2.2 Description .................................. 5
2.3 General Requirements ............. ... 5
Section 3. Installation Instructions.................... 6
3.1 Filter Location ............................. 6
3.2 Filter Preparation......................... 6
3.3 Filter Installation ......................... 7
3.4 Locking Ring Installation............ 8
Section 4. Start-Up and Operation .................... 8
4.1 New Pool and Seasonal Start-up . 8
Section 5. Filter Disassembly and Assembly.... 9
5.1 Filter Element Removal .............. 9
5.2 Changing the Outlet Port............. 10
DATE OF INSTALLATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL
FILTER MODEL
NOTES:

TABLE OF CONTENTS

EQUIPMENT INFORMATION RECORD
Section 6. Maintenance..................................... 11
6.1 General Maintenance................... 11
6.2 Pressure Gauge............................ 11
6.3 Cleaning the Filter Cartridge....... 11
Section 7. Winterizing....................................... 11
Section 8. Troubleshooting ............................... 12
Section 9. Parts List and Exploded View.......... 13
®
9.1 Jandy Cartridge Filter, CJ Series 13
®
9.2 Jandy CJ Cartridge Filter Exploded
View ........................................... 13
Section 10. Head Loss Curves........................... 14
®
10.1 Jandy Cartridge Filter, CJ Series 14
HORSEPOWER
SERIAL NUMBER
Page 3
