Jandy CS150 Installation And Operation Manual
Single element cartridge pool & spa cs filters
Hide thumbs
Also See for CS150:
- Installation and operation manual (16 pages) ,
- Installation and operation manual (48 pages) ,
- Installation and operation manual (36 pages)
Table of Contents
Advertisement
Models:
CS100
CS150
CS200
CS250
Single Element Cartridge Pool & Spa
FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state
or local requirements exist. The maintainer must be a professional with sufficient experience in pool
equipment installation and maintenance so that all of the instructions in this manual can be followed
exactly. Before installing this product, read and follow all warning notices and instructions that accompany
this product. Failure to follow warning notices and instructions may result in property damage, personal
injury, or death. Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTENTION INSTALLER - This manual contains important information about the
installation, operation and safe use of this product. This information should be given to
the owner/operator of this equipment.
INSTALLATION AND
OPERATION MANUAL
ENGLISH
Jandy
WARNING
|
|
FRANÇAIS
Pro Series
®
CS Filters
ESPAÑOL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jandy CS150
Summary of Contents for Jandy CS150
- Page 1 INSTALLATION AND OPERATION MANUAL ENGLISH FRANÇAIS ESPAÑOL Models: CS100 CS150 CS200 CS250 Jandy Pro Series ® Single Element Cartridge Pool & Spa CS Filters WARNING FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist.
-
Page 3: Table Of Contents
Filter Installation ..........6 Jandy Cartridge Filter, CS Series ..... 12 Locking Ring/Tank Top Assembly Installation ..7 Jandy CS Cartridge Filter Exploded View ..12 Section 4. Start-Up and Operation ....8 Section 10. Performance and Specifications . 13 New Pool and Seasonal Start-up ....... -
Page 4: Section 1. Important Safety Instructions
• Water temperature for test must NOT EXCEED 100°F (38°C). • Limit test to 24 hours. After test, visually check system to be sure it is ready for operation. Notice: These parameters apply to Jandy Pro Series equipment only. For non-Jandy equipment, consult equipment manufacturer. General Safety Instructions... -
Page 5: Section 2. General Information
This manual contains information for the proper exceeding 50 psi. Operating pressures above 50 psi installation and operation of the Jandy Pro Series CS can cause product failure or also cause the lid to be Cartridge Filters. Procedures in this manual must be blown off, which can result in death, serious personal followed exactly. -
Page 6: Filter Installation
Page 6 ENGLISH Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ® Clean/Dirty Snap Ring Pressure Gauge 6" Minimum Clearance Air Release Valve Filter Pressure Gauge Drain Adapter 12" Minimum Clearance Figure 1. -
Page 7: Locking Ring/Tank Top Assembly Installation
Page 7 Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ENGLISH ® Drain Outlet Inlet Port Port Inlet Port Spa Make Up Filter Pump From Pool Drain Heater Check Waterfall Valve Spa Suction... -
Page 8: Section 4. Start-Up And Operation
Page 8 ENGLISH Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ® Section 4. Start-Up and Operation After the pressure gauge has stabilized, turn the bezel ring so that the arrow next to the word WARNING "CLEAN"... -
Page 9: Section 6. Maintenance
Page 9 Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ENGLISH ® Section 6. Maintenance Remove the top of the filter. Inspect the tank o-ring for damage. Clean or replace the o-ring as necessary. -
Page 10: Breather Tube Maintenance
Page 10 ENGLISH Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ® Open the air release valve on top of the filter and WARNING wait for all air pressure to be released. Open the filter tank drain. When the filter tank has If the breather tube is not fully seated drained, close the drain. -
Page 11: Section 8. Troubleshooting
Page 11 Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ENGLISH ® Section 8. Troubleshooting For a list of common problems and solutions see the Troubleshooting Guide below. Zodiac recommends that you call a qualified service technician to do any work on the filter/pump system. For technical assistance, contact our Technical Support Department at 1.800.822.7933. -
Page 12: Section 9. Parts List And Exploded View
O-Ring, Tank Top R0462700 Inlet Diffuser with Locking Tab R0462100 Cartridge Element, 100 Sq. Ft., CS100 R0462200 Cartridge Element, 150 Sq. Ft., CS150 R0462300 Cartridge Element, 200 Sq. Ft., CS200 R0462400 Cartridge Element, 250 Sq. Ft., CS250 R0462500 Tailpiece, Cap and Union Nut Set R0461800 (Set of 3), 2"... -
Page 13: Section 10. Performance And Specifications
10.1 Headloss Curve, CS Series 3.00 2.50 2.00 1.50 1.00 0.50 0.00 Flow Rate (gpm) 10.2 Performance Specifications CS100 CS150 CS200 CS250 Filter Area (sq ft) Normal Start Up PSI 6-15 6-15 6-15 6-15 Max Working PSI Residential Specifications Maximum Flow (gpm) -
Page 14: 10.3 Dimensions
Dimensions, CS Cartridge Series Filter - Top View 3 1/4” Figure 7. Dimensions, CS Cartridge Series Filter Dimension “A”: ⅜ • CS100 - 32 ” ⅜ • CS150 - 32 ” ½ • CS200 - 42 ” ½ • CS250 - 42 ”... - Page 15 Page 15 Jandy Pro Series, CS Single Element Cartridge Pool & Spa Filter Installation & Operation Manual ENGLISH ® NOTES...
- Page 16 Zodiac Pool Systems Canada, Inc. 2-3365 Mainway, Burlington, Ontario L7M 1A6 1-888-647-4004 | www.ZodiacPoolSystems.ca Zodiac Pool Systems LLC 2620 Commerce Way, Vista, CA 92081 1.800.822.7933 | www.ZodiacPoolSystems.com ©2018 Zodiac Pool Systems LLC. ZODIAC ® is a registered trademark of Zodiac International, Certified to S.A.S.U., used under license.
