E-DIO24-OEM User's Guide
Pin Signal name Pin description
1 P0D0
3 P0D2
5 GND
7 P0D5
9 P0D7
11 GND
13 P2D1
15 P2D3
Pin Signal name Pin description
1 P1D0
3 P1D2
5 GND
7 P1D5
9 P1D7
11 GND
13 P2D5
15 P2D7
The signal location of each pinout is shown in Figure 3.

LED status indicators

The E-DIO24-OEM has two LED indicators that indicate the status of power and host communications. The
LEDs are stacked one above the other:

The LED (top) is on when external power between 4.2 V to 5.6 V is supplied.
Power
This LED is off when the external power supply is not connected, or the input power is outside of the 4.2 V
to 5.6 V voltage range of the external supply, causing a power fault.
The E-DIO24-OEM has an onboard voltage supervisory circuit that monitors the 5 V external power
supply.

The Activity LED (bottom) is on when a valid host connection is detected.
This LED blinks when a command is received.
Both Power and Activity LEDs blink once when factory default settings are restored. Refer to
default network settings

Ethernet connector

The E-DIO24-OEM has one 10/100 BASE-T, auto-negotiation, high-speed communication port. The port
connector is an RJ-45, eight-position type that accepts CAT-5 shielded or unshielded twisted pair cable. The
maximum communication distance without using a repeater is 100 meters (328 feet). You can send your data
100 meters at data speeds of up to 100 Mbps using only one Ethernet cable connected to the network.
Ethernet connector LEDS
The green
established, and blinks when network activity is detected.
The yellow
100 Mbps, and off when the transmission speed is 10 Mbps or no Ethernet link is established.
Port 0 bit 0
Port 0 bit 2
Ground
Port 0 bit 5
Port 0 bit 7
Ground
Port 2 bit 1
Port 2 bit 3
Port 1 bit 0
Port 1 bit 2
Ground
Port 1 bit 5
Port 1 bit 7
Ground
Port 2 bit 5
Port 2 bit 7 / Counter
Figure 3. Header connector pinout, typical
on page 9 for more information.
LED on the left of the connector is on when a valid Ethernet link is
Link/activity
LED on the right of the connector is on when the transmission speed is
Speed
W6 pinout
Pin Signal name
2 P0D1
4 P0D3
6 P0D4
8 P0D6
10 GND
12 P2D0
14 P2D2
16 GND
W2 pinout
Pin Signal name
2 P1D1
4 P1D3
6 P1D4
8 P1D6
10 +VO
12 P2D4
14 P2D6
16 GND
11
Functional Details
Pin description
Port 0 bit 1
Port 0 bit 3
Port 0 bit 4
Port 0 bit 6
Ground
Port 2 bit 0
Port 2 bit 2
Ground
Pin description
Port 1 bit 1
Port 1 bit 3
Port 1 bit 4
Port 1 bit 6
User voltage output
Port 2 bit 4
Port 2 bit 6
Ground
Restoring factory
