- Page 1 E-DIO24-OEM Ethernet-based Digital I/O User's Guide Document Revision 1A October 2015 © Copyright 2015...
- Page 2 Other product and company names mentioned herein are trademarks or trade names of their respective companies. © 2015 Measurement Computing Corporation. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measurement Computing Corporation.
-
Page 3: Table Of Contents
What you will learn from this user's guide ......................5 Conventions in this user's guide ......................... 5 Where to find more information ......................... 5 Chapter 1 Introducing the E-DIO24-OEM ......................6 Ethernet interface ..............................6 Functional block diagram ........................... 6 Chapter 2 Installing the E-DIO24-OEM ........................ - Page 4 E-DIO24-OEM User's Guide Environmental ..............................18 Mechanical ............................... 18 Header connector .............................. 18 Screw terminal connector (not populated) ......................19...
-
Page 5: Preface
Preface About this User's Guide What you will learn from this user's guide This user's guide describes the Measurement Computing E-DIO24-OEM data acquisition device and lists device specifications. Conventions in this user's guide For more information Text presented in a box signifies additional information and helpful hints related to the subject matter you are reading. -
Page 6: Introducing The E-Dio24-Oem
Chapter 1 Introducing the E-DIO24-OEM The E-DIO24-OEM is an Ethernet based digital I/O data acquisition device that is compatible with TCP (IPv4 only) and UDP network protocols. The E-DIO24-OEM provides the following features: 24 individually-configurable digital I/O bits ... -
Page 7: Installing The E-Dio24-Oem
Once the E-DIO24-OEM is physically connected to the local network or PC, you can run the software (InstaCal for example) to establish a connection. If a connection cannot be established, make sure the device is using the... -
Page 8: Configuring Network Settings
OEM. If the connected network does not have a DHCP server, the address stored in the default IP address is assigned. If the E-DIO24-OEM is directly connected to a Windows PC or other host that supports link-local addressing, a link-local address is assigned. A link-local address is valid only for communications between the E-DIO24- OEM and the PC to which it is connected. -
Page 9: Configuring The Network Router For Communication Across Networks
Installing the E-DIO24-OEM Configuring the network router for communication across networks To communicate with the E-DIO24-OEM from a computer connected to a different network – such as over the Internet – you must change the network configuration of the network router. -
Page 10: Functional Details
Chapter 3 Functional Details Components The E-DIO24-OEM has the following components, as shown in Figure 2: Header connectors LED status indicators Ethernet connector External power connectors Factory reset button Header connector W6 Factory reset button... -
Page 11: Led Status Indicators
The signal location of each pinout is shown in Figure 3. Figure 3. Header connector pinout, typical LED status indicators The E-DIO24-OEM has two LED indicators that indicate the status of power and host communications. The LEDs are stacked one above the other: ... -
Page 12: External Power Connectors
Digital I/O The E-DIO24-OEM has 24 DIO lines configured as three 8-bit ports – port 0, port 1, and port 2. Each bit is individually configurable for input or output. The digital I/O transfer rate is 5 kHz, maximum for software- paced operation on a local network. -
Page 13: Counter Input
E-DIO24-OEM User's Guide Functional Details Pull-up/down configuration All DIO lines are pulled high by default to 5 V through 47 kΩ resistors via jumpers W3, W4, and W5 (see Figure 5 below). Each jumper configures a digital port for pull-up or pull-down. -
Page 14: Ground
E-DIO24-OEM User's Guide Functional Details Ground The ground ( ) terminals provide a common ground for the digital I/O, counter input, and power output terminal. Mechanical drawings Figure 7. E-DIO24-OEM device circuit board dimensions... -
Page 15: Chapter 4 Specifications
Chapter 4 Specifications All specifications are subject to change without notice. Typical for 25 °C unless otherwise specified. Specifications in italic text are guaranteed by design. Digital input/output Table 1. Digital input/output specifications Parameter Specification Digital type 5 V TTL input / CMOS output Number of I/O 24, configured as 3 ports of 8 bits each (Port 0, Port 1, Port 2) Configuration... -
Page 16: Counter
E-DIO24-OEM User's Guide Specifications Counter Table 2. Counter specifications Parameter Specification Pin name P2D7 (shared with digital I/O) Counter type Event counter Number of channels Input type Schmitt trigger; uses port 2 digital I/O pull-up/down selection. Resolution 32 bits Schmitt trigger hysteresis 1.01 V typ... -
Page 17: Network
E-DIO24-OEM User's Guide Specifications Network Ethernet connection Table 5. Ethernet connection specifications Parameter Specification 100 Base-TX Ethernet type 10 Base-T Communication rates 10/100 Mbps, auto-negotiated Connector RJ-45, 8 position Cable length 100 meters (328 feet) max Additional parameters HP Auto-MDIX support Network interface Table 6. -
Page 18: Led Displays And The Factory Reset Button
E-DIO24-OEM User's Guide Specifications LED displays and the factory reset button Table 9. LED and button configurations Parameter Specification 4.2 V < V < 5.6 V: On Power LED (top) < 4.2 V > 5.6 V: Off (power fault) Both LEDs blinking continuously: In firmware update mode On when there is a valid host connection. -
Page 19: Screw Terminal Connector (Not Populated)
E-DIO24-OEM User's Guide Specifications Table 13. W6 pinout Signal name Pin description Signal name Pin description P0D0 Port 0 bit 0 P0D1 Port 0 bit 1 P0D2 Port 0 bit 2 P0D3 Port 0 bit 3 Ground P0D4 Port 0 bit 4... - Page 20 E-DIO24-OEM User's Guide Specifications...
- Page 21 Measurement Computing Corporation NI Hungary Kft 10 Commerce Way H-4031 Debrecen, Hátar út 1/A, Hungary Norton, Massachusetts 02766 Phone: +36 (52) 515400 (508) 946-5100 Fax: +36 (52) 515414 Fax: (508) 946-9500 http://hungary.ni.com/debrecen E-mail: info@mccdaq.com www.mccdaq.com...
