Summary of Contents for WOOSIM PORTI-AP60
- Page 1 PORTI-AP60 MODEL (Panel Printer) Rev. 2.0 WOOSIM SYSTEMS Inc. #501, Daerung Technotown 3th, 448, Gasan-Dong, GeumChun-Ku, Seoul, Korea Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice http://www.woosim.com...
- Page 2 Copyright ⓒ2007 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. and may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc.
- Page 3 Porti-AP60 Rev. 2.0 ¦ Introduction The Porti-AP60 is the ideal solution for taxi receipt printer, receipt printer, Medical analyzer, industrial instrument, recorder, geological analyzer, underground analyzer, chemical analyzer, metallic analyzer, etc. The general features of Porti-AP60 printer are as follows: Ultra small size rack mount printer.
- Page 4 Porti-AP60 Rev. 2.0 ¦ Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ● Be careful not to drop or bump the printer on a hard surface. ● Do not install the printer in direct sunlight or such areas.
- Page 5 Porti-AP60 Rev. 2.0 ¦ Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 6: Table Of Contents
Porti-AP60 Rev. 2.0 CONTENTS 1. Outline ............................7 1.1. Model classifications ......................7 1.2. Product Part Number System ....................7 1.3. Specifications .........................8 2. Setting up the printer ........................9 2.1. Printer & Accessories ......................9 2.2. Printer Features........................10 2.2.1. Part name ........................10 2.2.2. -
Page 7: Outline
Porti-AP60 Rev. 2.0 PORTI–AP60 ( Model name Interface None: UART : RS-485 UART/Parallel (only 12~24V) Power 9V : DC 9V 12V : DC12~24V Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None Serial/Bluetooth Part No. ⇒ S40/A1 Example) 1. -
Page 8: Specifications
Porti-AP60 Rev. 2.0 Item Specification Direct thermal line printing Printing method 42cpl (MAX) Characters per line Eng. :9*24dots, 12*24dots Kor. : 16*24dots, [24*24dots] Character size Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish, Optional Characters Greek, Japanese, Persian, Latin9 and Others upon request. -
Page 9: Setting Up The Printer
Porti-AP60 Rev. 2.0 & & Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. PORTI-AP60 Thermal Roll Paper http://woosim.com... -
Page 10: Printer Features
Porti-AP60 Rev. 2.0 9V Version 12V Version http://woosim.com... -
Page 11: Dimensions
Porti-AP60 Rev. 2.0 http://woosim.com... -
Page 12: Installation
Porti-AP60 Rev. 2.0 1) Put the main body into the rack as shown in the following drawing. 2) Hold the main body from rear side with mounting bracket, fasten the screws to fix the main body. 3) After mounting, make sure that... -
Page 13: Replacing Paper Roll
Porti-AP60 Rev. 2.0 Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. -
Page 14: Specified Power Supply
Porti-AP60 Rev. 2.0 5. Tear the excess paper off using the edge of paper door as a tear bar. The following specifications are requested for Power supply. INPUT : DC 9V, MAX 3A ( Standard model ) DC 12~24V, MAX 3A (Serial &... -
Page 15: Interface
Porti-AP60 Rev. 2.0 The Porti-AP60 printer has UART(RS-232C) or RS-485 interface is connected by means of a 3 pin female connector. In the following table, the signals present on the connector are listed: <CN11 : Serial Pin Description> Pin No. -
Page 16: Version : Uart(Rs-232C) And Parallel
Porti-AP60 Rev. 2.0 The Porti-AP60 printer has a UART(RS232C) and Parallel interfaces and is connected by means of a 15 pin male connector. In the following table, the signals present on the connector are listed: http://woosim.com... - Page 17 Porti-AP60 Rev. 2.0 ① POWER<CN7> Pin NO Name Description INPUT DC12~24V, 3A Ground ② SERIAL<CN12> Direction Pin No. Name Description Ground Input Receive Data Output Transmit Data ③ PARALLEL<CN6> Pin No. Name Direction Description Output STROBE " DATA BIT 0 "...
-
Page 18: Set Operation Mode
Porti-AP60 Rev. 2.0 DIP SWITCH No. Density High Density Medium Density High Density Low 115200 Baud Rate 57600 Baud Rate 38400 Baud Rate 19200 Baud Rate 9600 Baud Rate 4800 Baud Rate 2400 Baud Rate 1200 Baud Rate PROTOCOL RS232... -
Page 19: Using The Printer
Porti-AP60 Rev. 2.0 Button - FEED : When the printer is on, paper can be feed manually by pressing and holding the FEED button for more than one second. Panel Lamp - POWER : Printer is ON and ready to receive data. -
Page 20: Consumable Parts
Porti-AP60 Rev. 2.0 Type : Thermal Paper Paper width : 57mm Paper thickness : 60±5 ㎛ Outer diameter : Ø60mm or less Recording side : Outside of roll Cautions 1. Do not paste the paper to the core. And the roll paper which has near end mark printing on its near end is recommended.
