Summary of Contents for WOOSIM porti-pc40
- Page 1 PORTI-PC40 MODEL (Desk Top Printer) Rev. 2.0 WOOSIM SYSTEMS Inc. #501, Daerung Technotown 3th, 448, Gasan-Dong, GeumChun-Ku, Seoul, Korea Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice http://www.woosim.com...
- Page 2 Copyright ⓒ2007 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim System Inc. and may not be reproduced in whole or in part without the prior written permission of Woosim System Inc.
- Page 3 Porti-PC40 Rev. 2.0 ¦ Introduction The Porti-PC40 is the ideal solution for Mobile banking system , Retail, point of sales, Credit card Transaction, other traveling and mobile computing etc. The general features of Porti-PC40 printer are as follows: Pocket size(105 x 80.4 x 45.7mm) Light weight(286g) for true mobility.
-
Page 4: Operating Precautions
Porti-PC40 Rev. 2.0 ¦ Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ● Be careful not to drop or bump the printer on a hard surface. ● Do not install the printer in direct sunlight or such areas. - Page 5 Porti-PC40 Rev. 2.0 ¦ Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 6: Table Of Contents
Porti-PC40 Rev. 2.0 CONTENTS 1. Outline .............................7 1.1. Model classifications ......................7 1.2. Product Part Number System ....................7 1.3. Specifications ........................8 2. Setting up the printer ........................9 2.1. Printer & Accessories ......................9 2.2. Printer Features ........................10 2.3. Dimensions ......................... 11 2.4. -
Page 7: Outline
Porti-PC40 Rev. 2.0 1. Outline PORTI–PC40 Model name Interface None: UART Power None : DC 12~24V Model n ame Interface S pec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-482 Parallel None Serial/Bluetooth Part No. ⇒ S40/A1 Example) 1. Porti-S40 2. -
Page 8: Specifications
Porti-PC40 Rev. 2.0 Item Description Direct thermal line printing Printing method 42cpl (MAX) Characters per line Eng. : 9*24dots, 12*24dots Kor. : 16*24dots, [24*24dots] Character size Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish, Optional Characters Greek, Japanese, Persian, Latin9 and Others upon request. -
Page 9: Setting Up The Printer
Porti-PC40 Rev. 2.0 2. Setting up the printer & & When unpacking your printer box make sure it contains the printer and all accessories. If any accessories are missing or damage, please contact your dealer for assistance. Thermal roll paper PORTI-PC40 http://www.woosim.com... -
Page 10: Printer Features
Porti-PC40 Rev. 2.0 http://www.woosim.com... -
Page 11: Dimensions
Porti-PC40 Rev. 2.0 http://www.woosim.com... -
Page 12: Replacing The Paper Roll
Porti-PC40 Rev. 2.0 Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. -
Page 13: Power Supply
Porti-PC40 Rev. 2.0 The following specifications are requested for Power supply. Input: DC 12-24V / Max 3A Avoid using power supply which its power capacity of power current is extremely high http://www.woosim.com... -
Page 14: Interface
Porti-PC40 Rev. 2.0 3. Interface The Porti-PC40 printer has an UART(RS-232C or TTL) interface is connected by means of a 9p D-sub. In the following table, the signals present on the connector are listed: Pin No. Name Direction Function Output... - Page 15 Porti-PC40 Rev. 2.0 ※ RS-232C Technical Specifications DATA TRANSFER RATE : 9600 Baud WORD LENGTH : 8 Data Bits 1 Stop Bit SIGNAL LEVELS : Mark or Logical 1 = -3 to -15 VDC Space or Logical 0 = +3 to +15VDC...
-
Page 16: Using The Printer
Porti-PC40 Rev. 2.0 4. Using the printer Button - FEED Button : When the printer is on, paper can be feed manually by pressing and holding the FEED button for more than one second. Panel Lamp Printer is ON and ready to receive data. -
Page 17: Consumable Parts
Porti-PC40 Rev. 2.0 5. Consumable Parts Type : Thermal Paper Paper width : 57mm : 60±5 ㎛ Paper thickness Outer diameter : Ø40mm or less Recording side : Outside of roll Cautions 1. Do not paste the paper to the core. And the roll paper which has Near end mark printing on its near end is recommended. -
Page 18: Printing Position
Porti-PC40 Rev. 2.0 http://www.woosim.com...
