- Page 1 PORTI-S30/40 MODEL (2inch Mobile Printer) Rev. 3.0 WOOSIM SYSTEMS Inc. #501, Daerung Technotown 3th, 448, Gasan-Dong, GeumChun-Ku, Seoul, Korea Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice http://www.woosim.com...
- Page 2 PORTI-S30/40 2inch mobile printer operator’s manual. Copyright ⓒ2010 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc.
- Page 3 Porti-S Rev. 3.0 Introduction The PORTI-S30/40 is suitable designed for use with a growing variety of mobile devices. IrDA/Serial or Bluetooth/Serial interfaces make the PORTI-S30/40 the perfect comrade for applications such as point of transaction warehousing, distribution, point of sales, hospitality, gaming and healthcare.
-
Page 4: Operating Precautions
Do not allow plastic film, erasers, or adhesive tape to touch the paper for long periods. ● Do not stack the thermal paper with diazo copies immediately after copying or wet-type copies. ● Do not use chemical glue. ● Always use the clean thermal paper. http://www.woosim.com... - Page 5 --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. http://www.woosim.com...
-
Page 6: Table Of Contents
3.2. Infrared data communication ..................23 3.3. Bluetooth ..........................24 4. Using the printer ........................25 4.1. Control panel ........................25 4.2. The self test ........................26 5. Consumable Parts ........................27 5.1. Recommended paper....................... 27 5.2. Printing position ....................... 27 http://www.woosim.com... -
Page 7: Outline
2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 Note) The above table is the interface format which is supported. But some of the interfaces are not supported according to the product and please contact us, if you have any questions regarding the interface. http://www.woosim.com... -
Page 8: Specifications
MCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes Receive buffer size 1M bytes Battery Rechargeable 7.4V DC , 1200mAh (Li-ion) Battery duration 1 hour continuous printing Input (100~250V AC 50~60Hz) Battery Charger Output(8.4VDC/0.8A), 4hours full charge time (Continue…) http://www.woosim.com... - Page 9 Porti-S Rev. 3.0 Item Specification -10°C ~ 50°C (operating) Temperature -10°C ~ 70°C (storage) Environment Conditions 30% - 80% (operating) Humidity 10% - 90% (storage) Mechanical 37,000,000 lines MCBF (Mean Cycle Between failure) Head Approximately 50 Km < Table 1 > http://www.woosim.com...
-
Page 10: Setting Up The Printer
Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Battery pack Communication cable PORTI-S Battery charger adaptor Thermal roll paper ▼ OPTIONAL External Battery Cradle Car charger Leatherette case http://www.woosim.com... -
Page 11: Printer Features
Porti-S Rev. 3.0 ▶ Part Name ▶ Dimensions http://www.woosim.com... -
Page 12: Replacing The Paper Roll
2. Open the paper cover using finger on both side of printer, and remove the remaining paper. 3. Insert the paper roll as shown. 4. Tear the excess paper off using the edge of paper door as a tear bar. http://www.woosim.com... -
Page 13: Power Supply
- Insert the Battery pack in the direction of the arrow. ② To remove battery pack, proceed the above order reverse. ③ The battery pack install into External Battery Cradle. - Insert the Battery pack in the direction of the arrow. http://www.woosim.com... -
Page 14: Recharging The Battery
The recharging time depends on the voltage level and ambient temperature of the battery. Normally, if takes about 4 to 5 hours to recharge a battery pack. ● You must use only the supplied adapter. ● Red Lamp : charging the battery. Green Lamp: charging is finished. http://www.woosim.com... -
Page 15: Set Operation Mode
And then the Parity bit has set to Odd parity bit. When you press FEED Button once again, Power Lamp flickers 5 times Error Lamp flickers once. → → → → Press MODE Button twice, Error Lamp flickers 3 times. And then the density has set to Density high. http://www.woosim.com... - Page 16 The printer will print out the mode status which has modified. ( Bluetooth / 57,600 baud / 7 data bit / Odd parity / Density high / Mark no use/ Sensor Medium1 ) If the status is not correct, please try it again according to the procedure. http://www.woosim.com...
- Page 17 7 Data bit Data Bit 8 Data bit No Parity Parity Bit Even Parity Odd Parity Density Low Density Density Medium Density High Default Protocol Protocol Lotte Protocol No use Mark Medium1 Sensor Medium2 High < Table 2 > http://www.woosim.com...
- Page 18 And then the Parity bit has set to Odd parity bit. When you press FEED Button once again, Power Lamp flickers 5 times Error Lamp flickers once. → → → → Press MODE Button once, Error Lamp flickers twice. And then the density has set to 2 stop bit. http://www.woosim.com...
- Page 19 (Bluetooth / 57600 bps / 7 data bit / Odd parity / 2 stop bit / Density high / Mark no use / Sensor medium1 / Power down no use) If the status is not correct, please try it again according to the procedure. http://www.woosim.com...
- Page 20 115200 bps 7 Data bit Data Bit 8 Data bit No Parity Parity Odd Parity Even Parity 1 stop bit Stop bit 2 stop bit Density Low Density Density Medium Density High No use Mark Medium1 Sensor Medium2 High (Continue…) http://www.woosim.com...
- Page 21 Porti-S Rev. 3.0 ERROR Lamp POWER Lamp MODE Option (Green) (Red) No use 1 minute 2 minute Power Down 3 minute 4 minute 5 minute < Table 3 > http://www.woosim.com...
-
Page 22: Interface
① UART(RS-232C) ② USB Pin no Signal Name Direction Function Pin no Signal Name Direction Function Ground Ground Input Receive data Output Transmit data NOTE : ● When data receiving, when it removes the communication cable, it loses a data. http://www.woosim.com... -
Page 23: Infrared Data Communication
15° on the four sides (see fig.3.3) (Fig.3.3) NOTE : ● When infrared ray communication doing, directness it does not see the IrDA window roll up. Eye damage there is a danger. http://www.woosim.com... -
Page 24: Bluetooth
Porti-S Rev. 3.0 Category Specification Bluetooth Spec. Bluetooth Ver2.1 +EDR / Class2 (10m) Frequency Range 2.4GHz ISM BAND Data Transmission Rate 57600bps Fixed. Data bit 8 Data bit Fixed. Parity bit No parity Fixed. Stop bit 1 Stop bit Fixed. http://www.woosim.com... -
Page 25: Using The Printer
The status indicator will flash continuously to show the batteries are nearly exhausted and in need of re-charging. -Error : Indicates a fault condition or a printer error. (i.e : no paper, paper cover opened. etc.) -Data : The Data lamp is on whenever the printer receives data. http://www.woosim.com... -
Page 26: The Self Test
ROM version and the communication method setting. 3) After printing the current printer status, Self-Test will print a pattern using the built-in character set. 4) The Self-Test automatically ends. The printer is ready to receive data as soon as it complete the Self-Test. http://www.woosim.com... -
Page 27: Consumable Parts
2. Chemicals or oil may change the color of paper, or printed characters may fade. 3. Change of paper color starts from approx. 70 ℃. Pay attention to heat, humidity and sun light. 4. Color of paper may be changed by being scratched by nail or hard metal, etc. http://www.woosim.com...
