CODELOCKS CL1200 Programming & Operating Instructions

Master Code Commands
CHANGE THE MASTER CODE
Master Code 01 New Master Code New Master
Code
Example: 11335577 01 12345678 12345678
Result: Note:
Master Code has been changed to 12345678.
prefix not required when in Mode B) single use (locker) mode.
SET OR CHANGE THE USER CODE
Master Code 02 User Code
Example: 11335577 02 1455
Result:
New User Code 1455 now operative.
DELETE USER CODE
Master Code 03
Example: 11335577 03
Result:
User Code deleted.
SET OR CHANGE THE SUB-MASTER CODE
Master Code 04 Sub-Master Code
Sub-Master Code
Example: 11335577 04 22446688 22446688
Result: Sub-Master Code 22446688 now operative. Note:
prefix not required when in Mode B) single use (locker) mode.
DELETE THE SUB-MASTER CODE
Master Code 05 05
Example: 11335577 05 05
Result: Sub-Master Code deleted. Note: prefix not
required when in Mode B) single use (locker) mode.
Sub-Master Code Commands
CHANGE THE SUB-MASTER CODE
Sub-Master Code 06 New Sub-Master Code
New Sub-Master Code
Example: 22446688 06 11335500 11335500
Result: Note:
Sub-Master Code has been changed to 11335500.
prefix not required when in Mode B) single use (locker) mode.
SET OR CHANGE THE USER CODE
Sub-Master Code 07 User Code
Example: 11335500 07 9999
Result:
New User Code 9999 now operative.
DELETE USER CODE
Sub-Master Code 08
Example: 11335500 08
Result: User Code deleted.
User Code Commands
A) REPEATED USE MODE: CHANGING THE USER CODE
User Code New User Code New User Code
Example: 2244 5541 5541
Result: User Code now 5541.
B) SINGLE USE MODE: SET THE USER CODE
Enter Single Use Code to lock
Re enter same Single Use Code to open
Note:
1. When the lock is opened single use code will be erased and will be
ready for new single use code to be entered.
2. When locked in single use mode the LED will flash every two
seconds indicating locked status.
3. Keypad in this mode is only active when lever is in closed position.
Special Master Code Commands
CHANGING FROM REPEATED USE A) TO SINGLE USE B)
(LOCKER MODE) WITH TECHNICIAN CODE ENABLED
Master Code 12 Technician Code Technician
Code
Example: 11335577 12 555555 555555
Result
The lock is automatically set into function B) single use locker
mode AND allows the programmed technician code to open the lock
WITHOUT the entered single use code being erased.
Note: If lock is opened with a Master Code the User Code will be erased.
CHANGING FROM REPEATED USE A) TO SINGLE USE B)
(LOCKER MODE) WITHOUT A TECHNICIAN CODE
Master Code 09
Example: 11335577 09
Result: The lock will now work in B) single use (locker) mode.
Note:
1. The locking pin is now programmed to be withdrawn when using the above
code string and is waiting and ready to accept a single use code. Please note
that the keypad is now inactive when the lever is in the open position.
2. Only the Master Code and Sub-Master Code will be retained from repeated
use mode A).
N.B. When in locker mode B) the Codelocks.com button is not
required for programming. The following programs are available
RESTRICT THE LOCKED TIME
Master Code 10 (number of hours lock to remain locked)
Example: 11335577 10 04
Result: The lock will auto open after 4 hours. If a new User Code is
entered it will once again relock for 4 hours.
If the lock is opened during the 4 hour period then the lock remains open
until a new User Code is entered as normal.
Note: This program will only work when the lock has been set into single use B)
(Locker) mode. The two digits number of hours lock to remain locked is 02, 04,
06, 08, 10 or 12.
CHANGING FROM SINGLE USE MODE B) (LOCKER MODE)
TO REPEATED USE MODE A)
Master Code 11
Example: 11335577 11
Result: Lock will revert to Repeated use mode A) with the default user code
2244 active until reprogrammed.
Note: When the program is changed from single use B) (Locker) mode above
to repeated use. Use A) mode the locking pin should now move to the locked
position and previous single use code erased. The button will now be
required for programming.
SET THE LOCK IN TECHNICIAN MODE
Master Code 12 Technician Code Technician Code
Example: 11335577 12 555555 555555
Result: The lock set into Technician mode with Technician Code 555555
Note:
1. Technician Code only available when lock is set in single use B
(locker mode).
2. The Technician Code is able to open the lock without the entered
single use code being erased.
3. Opening the lock with the Master Code will erase the User Code.
DELETE THE TECHNICIAN MODE
Master Code 13 13
Result Technician Code deleted.
DISABLE/ENABLE SOUNDER
The default is for the sounder to activate at every button press.
To disable the sounder enter the following toggle code string:
Master Code 14 14
Result:
No sound when buttons pressed.
To enable the sounder repeat above code sequence.
CL1200
Programming
& Operating
Instructions
