SPALDING M5800041 Owner's Manual

Portable system
Hide thumbs

Advertisement

Quick Links

Download this manual
REQUIRED
MATERIALS:
• Two (2) Capable
Adults
• Wood Board
(scrap)
• Sawhorse or
Support Table
• Garden Hose or Sand
• (2 each) Wrenches
and/or Socket
Wrenches and Sockets.
1/2"
9/16"
AND/OR
1/2"
9/16"
OPTIONAL TOOLS
AND MATERIALS:
• Large and Small
Adjustable Wrenches
© COPYRIGHT 2005 by SPALDING
WARNING!
NOT SUITABLE FOR CHILDREN
UNDER THREE YEARS OF AGE
DUE TO SMALL
PARTS/CHOKING HAZARD.
This manual, accompanied by sales receipt, should be saved and kept on hand as a
convenient reference, as it contains important information about your model.
Portable System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
Internet Address: http://www.huffysports.com
European Technical File:
De Ruyumbeke
20 Bd Bourre
13008 Marseille, France
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO
PROPERTY.
For Canada: 1-800-284-8339,
For Australia: 1-800-632 7921
1
88 / 378-UK-003
Tech File at
De Ruyumbeke,
France
Write Model Number
From Box Here:
01/06
ID# M5800041
