Write Model Number WARNING! From Box Here: READ AND UNDERSTAND OPERATOR'S MANUAL BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. Toll-Free Customer Service Number for U.S: 1-800-334-9111 Internet Address: http://www.spalding.com 08/06 ID# M867SF12...
213641 Bolt, Hex Head, 1/2”-13 x 6” 214046 Washer, Flat, 5/8, Black Zinc 214057 Nut, Hex, 5/8-11, Black Zinc 204670A Bushing, Plastic 204670C Bushing, Plastic 205794 Foam Pad * You May Have Extra Parts With This Model. 08/06 ID# M867SF12...
Page 5
Install threaded ends of J-bolts (19) through holes in mounting plate (2) and secure as shown. NOTE: Make sure J-bolts (19) are in the illustrated position. Nuts on the top of plate are used for leveling the pole after system is fully assembled. 08/06 ID# M867SF12...
Front of mounting plate (2) must be parallel with PLAYING SURFACE playing surface. IMPORTANT!: WAIT A MINIMUM OF 72 HOURS BEFORE GOING ON TO NEXT STEP. CONCRETE MUST CURE. ALLOW ADDITIONAL TIME FOR COLD, WET OR HUMID WEATHER. ID# M867SF12 08/06...
Page 7
Insert bushings (26 and 27) into areas shown. IMPORTANT! Bushing types are identified with a letter. 08/06 ID# M867SF12...
Page 8
SCRAP WOOD REQUIRED FOR THIS (NOT INCLUDED) PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. PLAYING SURFACE Insert bolt (23) through holes in plate and pole and secure with nut (22). ID# M867SF12 08/06...
Slide barrel washer (9) onto other end of DAMAGE. rod (14) and secure with washer (24) and nut (18). Tighten nut (18) until it is positioned 3-3/4” from the end of the rod (14) as shown (Figure A). Completed Assembly Fig. A 08/06 ID# M867SF12...
Page 10
From the top of the pole to the top of the upper yoke’s bracket should be approximately 3.2”. 18" From the bottom of the upper yoke’s bracket to the top of the lower yoke’s bracket should be approximately 18”. SEE FIGURE B ID# M867SF12 08/06...
Page 11
ONE person to attach hardware (FIG. A). Use hardware as shown in FIG. B. WARNING! THREE PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. FIG. A FIG. C FIG. D FIG. B 08/06 ID# M867SF12...
Page 12
GLASS BOARDS: DO NOT cut and peel protective film away from back of board prior to attaching rim! FIGURE Rim Assembly Refer To Instructions Included With Rim Hardware For Rim Assembly. ID# M867SF12 08/06...
Page 13
Install net (4) to rim as shown. Apply name plate stickers (15) to lower yoke as shown. 08/06 ID# M867SF12...
Page 14
Once pole is in its final position, install washers (24) FAILURE TO FOLLOW THIS WARNING COULD and nuts (25) onto J-bolts (19) and fully tighten to RESULT IN SERIOUS INJURY AND/OR secure pole to base plate PROPERTY DAMAGE. ID# M867SF12 08/06...
Page 15
WARNING! WARNING: ONLY AFTER NUTS (25) HAVE BEEN FULLY TIGHTENED: Remove cotter pin (8) and pin (13) to remove assembly bolt (14) from bottom plate (2). 08/06 ID# M867SF12...
Page 16
(2) and pole flange. Regulation height is 10 feet. WARNING! 10 feet (3.05 m) READ AND UNDERSTAND WARNINGS LABELS BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. ID# M867SF12 08/06...
HANGING ON THE RIM WILL VOID YOUR WARRANTY. RIms are not warranted for any defects other than workmanship. Torn back plates, damaged springs, bent rings, damaged eye bolts, and torn or distorted rim supports result from hanging on the rim and are not warranted. 08/06 ID# M867SF12...
