REQUIRED
MATERIALS:
• Two (2)
capable adults
• Wood Board
(scrap)
• Sawhorse or
Support Table
• Garden Hose or Sand
• (2 each) Wrenches
and/or Socket
Wrenches and Sockets.
1/2"
9/16"
AND/OR
1/2"
9/16"
OPTIONAL TOOLS
AND MATERIALS:
• Large and Small
Adjustable Wrenches
© COPYRIGHT 2007 by Spalding
Write Model Number
From Box Here:
This manual, accompanied by sales receipt, should be saved and kept on hand as a
convenient reference, as it contains important information about your model.
Portable System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO
PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
Internet Address: www.huffysports.com
Adult Assembly Required.
WARNING!
For Canada: 1-800-284-8339,
For Australia: 1800 632 792
1
WARNING!
NOT SUITABLE FOR CHILDREN
UNDER THREE YEARS OF AGE
DUE TO SMALL
PARTS/CHOKING HAZARD.
www.spalding.com
01/07
ID# M5800142
Advertisement
Table of Contents
Related Manuals for SPALDING M5800142
Summary of Contents for SPALDING M5800142
-
Page 1: Owners Manual
• Large and Small Toll-Free Customer Service Number for U.S: 1-800-558-5234, Adjustable Wrenches For Canada: 1-800-284-8339, For Europe: 00 800 555 85234 (Sweden: 009 555 85234), For Australia: 1800 632 792 Internet Address: www.huffysports.com www.spalding.com 01/07 ID# M5800142 © COPYRIGHT 2007 by Spalding... -
Page 2: Height Adjustment
System may tip over more easily. • See instruction manual for proper installation and maintenance. In the U.S.: 1-800-334-9111 In the U.S.: 1-800-558-5234 In Canada: 1-800-284-8339 In the U.S.: 1-800-558-5234 In the U.S.: 1-888-713-5488 In Canada: 1-800-284-8339 ID#: 558200 05/05 ID# M5800142 01/07... -
Page 3: Safety Instructions
IMPORTANT! Remove all contents from boxes. Be sure to check inside pole sections; hardware and additional parts are packed inside. PRODUCT REGISTRATION: Please remember to complete your product registration form on- line at: www.huffysports.com/customer_support/product_registration. 01/07 ID# M5800142... - Page 4 Get to know the basic parts of your basketball system... FRONT BACK TOP POLE BACKBOARD ELEVATOR ASSEMBLY MIDDLE POLE STRUTS BOTTOM POLE BASE ID# M5800142 01/07...
-
Page 5: Parts List
Washer, Flat, 5/16 203309 Washer, Flat, 1.0" O.D. 203679 Bolt, Hex, 3/8-16 x 2" Long 203100 Nut, Flange, 5/16-18 900454 Strut, Left 900255 Strut, Right 558170 Label, Height Adjustment * You may have extra parts with this model. 01/07 ID# M5800142... - Page 6 #16 (2) #19 (1) #17 (4*) #18 (1) #10 (1) PARTS IDENTIFIER - Not Actual Size #1 (1) #21 (1) #22 (1) #6 (1) #11 (2) #9 (1) #15 (1) #7 (1) #12 (1) #14 (1) #13 (1) ID# M5800142 01/07...
- Page 7 SECTION A: ASSEMBLE THE POLES Correctly identify each pole section. Poles have an identification sticker that will be used as a reference point in the next step. Reference Stickers MIDDLE BOTTOM 01/07 ID# M5800142...
- Page 8 SECTIONS SHOULD HAVE A 2-1/2" MINIMUM OVERLAP, LEAVING 1-1/4" BETWEEN THE OVERLAPPING POLE AND THE IDENTIFICATION STICKER. alignment mark MIDDLE FIG A. 3-1/2” IDENTIFICATION STICKER middle pole scrap wood alignment mark (Not Supplied) BOTTOM IDENTIFICATION STICKER 1-1/4" middle pole ID# M5800142 01/07...
- Page 9 CAREFULLY TIPPING THE SYSTEM FORWARD WILL ALLOW EASIER ACCESS TO UNDERSIDE OF BASE WARNING! IMPORTANT! NOTE ORIENTATION. TWO CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 01/07 ID# M5800142...
- Page 10 Rotate struts down and bend struts outward to line up with holes on base as shown. Secure free ends of tank struts to tank with carriage bolt (8), and nut (20) as shown. Repeat for other side. ID# M5800142 01/07...
- Page 11 Attach rim to backboard and pole bracket (14) with nut (20), reinforcement bracket (15), and carriage bolt (8) as shown. Tighten nut completely. Press bracket (14) into place here. Carefully tip unit forward and slide backboard assembly onto pole as shown. SAWHORSE OR SUPPORT TABLE 01/07 ID# M5800142...
- Page 12 (approx. 170 lb./77 kg) and snap tank cap (9) in place. CAUTION! ADD ONE GALLON (3.78 LITERS) OF NON-TOXIC ANTIFREEZE IN SUB- FREEZING CLIMATES. NOTE: IF USING SAND: 1 GALLON OF ANTI-FREEZE IS NOT REQUIRED ID# M5800142 01/07...
- Page 13 System may tip over more easily. • See instruction manual for proper installation and maintenance. In the U.S.: 1-800-558-5234 In the U.S.: 1-800-334-9111 In Canada: 1-800-284-8339 In the U.S.: 1-800-558-5234 In the U.S.: 1-888-713-5488 In Canada: 1-800-284-8339 ID#: 558200 05/05 01/07 ID# M5800142...
- Page 14 Número telefónico sin costo del Departamento de Servicio al Cliente en EE.UU.: 1-800-558-5234, Para Canadá: 1-800-284-8339, Para Europa: 00 800 555 85234 (Suecia: 009 555 85234), Para Australia: 1800 632 792 Dirección en Internet: www.huffysports.com www.spalding.com ID# M5800142 01/07...
- Page 15 • Llaves de tuercas ajustables Schraubenschlüssel grandes y pequeñas Inscrivez ici le numéro Die Modellnummer vom Escriba aquí el número de modèle qui apparaît Verpackungskarton hier de modelo que viene en sur la boîte: eintragen: la caja: 01/07 ID# M5800142...
- Page 16 ID# M5800142 01/07...
-
Page 17: Réglage De La Hauteur
El sistema debe estar en posición horizontal para ajustarlo. La mayoría de las lesiones son causadas por el uso inadecuado y/o por el incumplimiento de las instrucciones. Tenga cuidado cuando use esta unidad. SP558170 07/05 01/07 ID# M5800142... - Page 18 Den Hohlraum in den Stangenteilen inspizieren. Dort sind Befestigungs-und andere Kleinteile verpackt. ¡IMPORTANTE! Saque todo el contenido de las cajas. Asegúrese de revisar el interior de las secciones del poste. Ahí se han empacado herraje y piezas adicionales. ID# M5800142 01/07...
-
Page 19: Enregistrement Du Produit
Perno, cabeza hexagonal, 3/8-16 x 2" de su producto en: longitud www.huffysports.com/customer_support/product_registration. 203100 Contratuerca, 5/16-18 900454 Puntal del tanque 900255 Puntal del tanque 558170 Etiqueta, Adjusta De La Altura * Puede haber piezas adicionales en este modelo. 01/07 ID# M5800142... - Page 20 CONJUNTO DEL ELEVADOR SECTION DE POTEAU SUPÉRIEURE OBERES STANGENTEIL SECCIÓN SUPERIOR DEL POSTE SECTION DE POTEAU CENTRALE CONTREFICHES MITTLERES STANGENTEIL STREBEN SECCIÓN MEDIA DEL POSTE SECTION DE POTEAU INFÉRIEURE PUNTALES UNTERES STANGENTEIL SECCIÓN INFERIOR DEL POSTE SOCLE BASE BASE ID# M5800142 01/07...
- Page 21 Identifique correctamente cada sección del poste. Los postes tienen una calcomanía de identificación que se usará como punto de referencia en el paso siguiente. Etiquettes de référence Markierungsaufkleber Calcomanías de referencia Section supérieure Section inférieure Section centrale Unten Oben Mitte Parte superior Parte inferior Parte media 01/07 ID# M5800142...
- Page 22 IDENTIFICACIÓN. Parte inferior figure A siehe Abb. A ÉTIQUETTE FIG. A D'IDENTIFICATION MARKIERUNGSAUFKLEBER CALCOMANÍAS DE IDENTIFICACIÓN Bout de bois 3,18 cm (non fourni) (1-1/4") middle pole Holzstück (nicht im Lieferumfang enthalten) Trozo de madera (No se suministra) ID# M5800142 01/07...
- Page 23 DURCH VORSICHTIGES KIPPEN DES SYSTEMS NACH VORNE WIRD DIE SOCKELUNTERSEITE LEICHTER ZUGÄNGLICH. SI SE INCLINA CUIDADOSAMENTE EL SISTEMA HACIA ADELANTE SE FACILITARÁ EL ACCESO A LA PARTE INFERIOR DE LA BASE IMPORTANT! WICHTIG! ¡IMPORTANTE! NOTEZ L'ORIENTATION. DIE KORREKTE AUSRICHTUNG BEACHTEN. NOTE LA ORIENTACIÓN. 01/07 ID# M5800142...
- Page 24 Asegure los extremos libres de los puntales del tanque el en tanque con el perno cabeza de carro (8), arandela (17) y perilla (20) como se muestra. Repita el procedimiento en el otro lado. ID# M5800142 01/07...
- Page 25 Die Vorrichtung vorsichtig nach vorne kippen und die Korbwandbaugruppe wie gezeigt auf die Stange schieben. Incline cuidadosamente la unidad hacia adelante y deslice el conjunto del respaldo en el poste como se muestra. CHEVALET DE SCIAGE OU TABLE SÄGEBOCK ODER STÜTZTISCH CABALLETE O MESA DE APOYO 01/07 ID# M5800142...
- Page 26 DESSOUS DE 0. DEN TANK MIT 3,78 L (1 GAL) EINES UNGIFTIGEN GEFRIERSCHUTZMITTELS FÜLLEN, UM IN KLIMAZONEN MIT FROSTTEMPERATUREN EIN GEFRIEREN ZU VERHINDERN. AÑADA 3.78 LITROS (UNO GALONES) DE ANTICONGELANTE NO TÓXICO SI EL CLIMA ALCANZA TEMPERATURAS DE CONGELAMIENTO. ID# M5800142 01/07...
- Page 27 System may tip over more easily. • See instruction manual for proper installation and maintenance. In the U.S.: 1-800-334-9111 In the U.S.: 1-800-558-5234 In Canada: 1-800-284-8339 In the U.S.: 1-800-558-5234 In the U.S.: 1-888-713-5488 In Canada: 1-800-284-8339 ID#: 558200 05/05 01/07 ID# M5800142...
