Page 56 · SumoBot – Mini Sumo Robotics
of IR light), 1 cm wide and 10cm long.
3. The Ring shall be marked by a white circular line of 2.5 cm thickness. The
Ring is within the outside of this circular line.
Article 4
Space
There should be the space of more than 50 cm wide outside the outer side of the
Ring. This space can be of any color except white, and can be of any materials
or shape, as long as the basic concepts of these rules are observed. This area,
with the ring in the middle, is to be called the: "Ring Area". If there are
markings or part of the ring platform outside these dimensions, this area will
also be considered in the Ring Area.
Section 3: Requirements for Robots
Article 5
Specifications
1. A robot must be in such a size that it can be put in a square tube of 10 cm
wide and 10 cm deep. A robot can be of any height. A robot must not be in
such a design that its body will be physically separated into pieces when a
match starts. The robot with such a design shall lose the match. The design
to stretch a robot's body or its parts shall be allowed, but must remain a single
centralized robot. Screws or nuts or other robot parts, with a mass of less
than 5 grams total, falling off from a robot's body shall not cause the loss of
the match.
2. The mass of a robot must be less than 500 grams including the attachments
and parts, but excluding the weight of a proportional system (the transmitter
or control box held by the operator, hereafter called "Prop") for remote-
controlled models.
3. The radio frequencies for radio-controlled robots must be either 27 MHZ (1-6
bands) or 40 MHZ (61, 63, 65, 67, and 69 bands). 40 MHZ (71-83 bands)
cannot be used.
4. Only one Prop can be used for one robot. Radio control Prop must be one of
