Order Codes - RuggedCom RuggedSwitch RSG2200 Specification Sheet

RSG2200 -______ -______ -____ -____ -____ -____ -____ -____ -____
Main Mount
Slot 1 Slot 3
Slot 2 Slot 4
Main: Ethernet and Power Connectors
.
R = Ethernet on rear; LED panel on front; power connector on rear
.
F = Ethernet on front; LED panel on front; power connector on rear
.
B = Ethernet on rear; LED panel on top; power connector on rear
.
T = Ethernet on front; LED panel on top; power connector on rear
Mount: Mounting Options
.
RM = 19" Rack Mount Kit
.
DP = DIN and Panel Mount Kit
.
RD = 19" Rack, DIN, and Panel Mount Kit
.
00 = No Mounting Option
PS1 and PS2: Power Supply 1 and 2
.
24 = 24VDC (9-36VDC), screw terminal block
.
48 = 48VDC (36-72VDC), screw terminal block
.
HI = 88-300VDC or 85-264VAC, screw terminal block
.
24P = 24VDC (9-36VDC), pluggable terminal block
.
48P = 48VDC (36-72VDC), pluggable terminal block
.
HIP = 88-300VDC or 85-264VAC, pluggable terminal block
.
XX = No Power Supply (PS2 Only)
S1, S2, S3, S4: Gigabit Ethernet Modules
for Slots 1, 2, 3, and 4
.
XXXX = Empty
.
CG01 = 2 x 10/100/1000Tx RJ45
.
FG01 = 2 x 1000SX - Multimode, 850nm, LC, 500m
.
FG02 = 2 x 1000LX - Singlemode, 1310nm, SC connectors, 10km
.
FG03 = 2 x 1000LX - Singlemode, 1310nm, LC connectors, 10km
.
FG04 = 2 x 1000LX - Singlemode, 1310nm, SC connectors, 25km
.
FG05 = 2 x 1000LX - Singlemode, 1310nm, LC connectors, 25km
.
FG50 = 2 x 1000LX SFP - Blank (no optical transceiver)
.
FG51 = 2 x 1000SX SFP - Multimode, 850nm, LC, 500m
.
FG52 = 2 x 1000LX SFP - Singlemode, 1310nm, LC, 10km
.
FG53 = 2 x 1000LX SFP - Singlemode, 1310nm, LC, 25km
.
FG54 = 2 x 1000LX SFP - Singlemode, 1550nm, LC, 70km
.
FG70 = 2 x 1000LX GBIC - Blank (no optical transceiver)
.
FG71 = 2 x 1000LX GBIC - Singlemode, 1310nm, SC, 10km
.
FG72 = 2 x 1000LX GBIC - Singlemode, 1310nm, SC, 25km
.
FG73 = 2 x 1000LX GBIC - Singlemode, 1550nm, SC, 70km
.
FXA01 = 2 x 100FX - Multimode, 1300nm, ST
.
FXA02 = 2 x 100FX - Multimode, 1300nm, SC
.
FXA11 = 2 x 100FX – Multimode, 1300nm, LC
.
FXA03 = 2 x 100FX - Multimode, 1300nm, MTRJ
.
FXA04 = 2 x 100FX - Singlemode, 1310nm, ST, 20km
.
FXA05 = 2 x 100FX - Singlemode, 1310nm, SC, 20km
.
FXA06 = 2 x 100FX - Singlemode, 1310nm, LC, 20km
.
FXA07 = 2 x 100FX - Singlemode, 1310nm, SC, 50km
.
FXA08 = 2 x 100FX - Singlemode, 1310nm, LC, 50km
.
FXA09 = 2 x 100FX - Singlemode, 1310nm, SC, 90km
.
FXA10 = 2 x 100FX - Singlemode, 1310nm, LC, 90km
www.RuggedCom.com
PS1 PS2 S1 S2
Slot 5
Slot 6
(2)
(2)
RuggedSwitch
9-Port Managed Gigabit Ethernet Switch
S3 S4 S5
S5: Gigabit Ethernet Modules for Slot 5
.
XXXXX = Empty
.
1CG01 = 1 x 10/100/1000Tx RJ45
.
1FG01 = 1 x 1000SX - Multimode, 850nm, LC, 500m
.
1FG02 = 1 x 1000LX - Singlemode, 1310nm, SC connectors, 10km
.
1FG03 = 1 x 1000LX - Singlemode, 1310nm, LC connectors, 10km
.
1FG04 = 1 x 1000LX - Singlemode, 1310nm, SC connectors, 25km
.
1FG05 = 1 x 1000LX - Singlemode, 1310nm, LC connectors, 25km
.
1FG50 = 1 x 1000LX SFP - Blank (no optical transceiver)
.
1FG51 = 1 x 1000SX SFP - Multimode, 850nm, LC, 500m
.
1FG52 = 1 x 1000LX SFP - Singlemode, 1310nm, LC,10km
.
1FG53 = 1 x 1000LX SFP - Singlemode, 1310nm, LC, 25km
.
1FG54 = 1 x 1000LX SFP - Singlemode, 1550nm, LC, 70km
.
1FG70 = 1 x 1000LX GBIC - Blank (no optical transceiver)
.
1FG71 = 1 x 1000LX GBIC - Singlemode, 1310nm, SC, 10km
.
1FG72 = 1 x 1000LX GBIC - Singlemode, 1310nm, SC, 25km
.
1FG73 = 1 x 1000LX GBIC - Singlemode, 1550nm, SC, 70km
1 FXA01 = 1 x 100FX - Multimode, 1300nm, ST
1FXA02 = 1 x 100FX - Multimode, 1300nm, SC
1FXA11 = 1 x 100FX – Multimode, 1300nm, LC
1FXA03 = 1 x 100FX - Multimode, 1300nm, MTRJ
1FXA04 = 1 x 100FX - Singlemode, 1310nm, ST, 20km
1FXA05 = 1 x 100FX - Singlemode, 1310nm, SC, 20km
1FXA06 = 1 x 100FX - Singlemode, 1310nm, LC, 20km
1FXA07 = 1 x 100FX - Singlemode, 1310nm, SC, 50km
1FXA08 = 1 x 100FX - Singlemode, 1310nm, LC, 50km
1FXA09 = 1 x 100FX - Singlemode, 1310nm, SC, 90km
1FXA10 = 1 x 100FX - Singlemode, 1310nm, LC, 90km
Accessories/Options
82-01-0002 - Conformal Coating
41-11-0011 - Cable support bracket (one)
43-10-0007 - Power cable (North America three
prong connector -> beau)
NOTES:
1 Distance ratings are typical but will depend on type of cabling, number of connectors and splices.
2 These transceivers have an operating temperature range of -20 °C to +85°C.
All other transceivers have an operating temperature range of -40°C to +85°C
3 SFP plugable optics that consist of a blank cage (FG50 for dual, 1FG50 for single)
plus specified fiber optic interface(s) installed
4 GBIC plugable optics that consist of a blank cage (FG70 for dual, 1FG70 for single)
plus specified fiber optic interface(s) installed
® RSG2200

Order Codes

RuggedSwitch ® RSG2200
(3)
(3)
(3)
(2) (3)
(4)
(4)
(2) (4)
9
