RuggedCom RuggedSwitch RSG2200 Specification Sheet page 2

Modularity:
5 available slots
Dual and single port modules
Up to 9 Gigabit ports
Mounting Options
Panel/Din Rail
19" Rack Mount
Front or Rear Mount
Integrated Power Supply
Universal high-voltage range:
88-300VDC or 85-264VAC
Popular low voltage DC ranges: 24VDC
(9-36VDC), 48VDC (36-59VDC)
True Dual Redundant Parallel
Load Sharing (Optional)
Screw or pluggable terminal
blocks available
www.RuggedCom.com
RuggedSwitch
Ethernet Modules
Ethernet Port Types:
10/100/1000 TX RJ45
1000SX Multimode
1000LX Singlemode
100FX Multimode
100FX Singlemode
Pluggable Optics (SFP and GBIC)
SC and LC connectors
Operating Temperature
-40 o C to +85 o C
No Fans
RuggedSwitch ®
9-Port Managed Gigabit Ethernet Switch
® RSG2200
Modular HMI:
Front or Rear Mount
Critical Alarm Relay
Form-C contact ratings:
Max Voltage 250VAC,125VDC
Max Current 2A@250VAC,
2A@30VDC
RuggedSwitch ® RSG2200
RSG2200
2
