RuggedCom RuggedSwitch M2200 Specification Sheet page 2

Modularity:
5 available slots
Dual and single port modules
Up to 9 Gigabit ports
Operating Temperature
-40 o C to +85 o C
No Fans
www.RuggedCom.com
Modular HMI:
Front or Rear Mount
Gigabit Port Types:
10/100/1000 TX Micro-D
1000SX Multimode LC
1000LX Singlemode LC
RuggedSwitch
MIL-STD 9-Port Managed Gigabit Ethernet Switch
RuggedSwitch
Ethernet Modules
Critical Alarm Relay
Mounting Options
Panel Rail
Integrated Power Supply
Universal high-voltage range:
88-300VDC or 85-264VAC
Popular low voltage DC ranges: 24VDC
(9-36VDC), 48VDC (36-59VDC)
True Dual Redundant Parallel
Load Sharing (Optional)
Screw terminal available
®
M2200
® M2200
Form-C contact ratings:
Max Voltage 250VAC,125VDC
Max Current 2A@250VAC,
2A@30VDC
RuggedSwitch ® M2200 2
