ORDERING INFORMATION

BILL OF MATERIALS

Table 4. EVAL-MBnanoDAC-SDZ
Qty Reference Designator
4 C1, C6, C7, C9
7 C2, C5, C8, C10, C15, C16, C17
2 C3, C4
1 C11
4 EXT_REF_1 to EXT_REF_4
1 J1
1 J2
3 J3, J7, J8
1 J4
1 J5
1 J6
1 J9
1 J10
1 L1
1 LK5
2 LK6, LK7
4 REF1 to REF4
1 R1
2 R2, R3
11 R5 to R15
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U10
2 U11, U12
FEC refers to Farnell Electronic Component Distributors.
1
2 GRM refers to Murata Manufacturing Company.
Table 5. EVAL-AD5678DBZ
Qty Reference Designator
8 A to H
8 C1 to C8
1 C9
1 C10
1 J1
1 J2
1 J3
1 J4
8 R1 to R8
1 U1
FEC refers to Farnell Electronic Component Distributors.
1
Motherboard
Description
6.3 V, tantalum capacitor (Case A), 10 µF, ±20%
50 V, X7R ceramic capacitor, 0.1 µF, ±10%
10 V, X5R, ceramic capacitor, 1 μF, ±10%
6.3 V, tantalum capacitor (Case A), 4.7 µF, ±20%
Straight printed circuit board (PCB) mount SMB jack, 50 Ω
Header, 2.54 mm, 2 × 8-way
Header, 2.54 mm, 2 × 5-way
Header, 2.54 mm, 1 × 6-way
Header, 2.54 mm, 1 × 8-way
3-pin terminal block
2-pin terminal block
Header, 2.54 mm, 2 × 4-way
120-way connector
Inductor, SMD, 600 Ω
6-pin (3 × 2) 0.1", header and shorting block
4-pin (2 × 2) 0.1", header and shorting block
10-pin (5 × 2) 0.1", header and shorting block
Resistor, surge, 1.6 Ω, 1%, 0603
SMD resistor, 100 kΩ, 1%, 0603
SMD resistor, 100 Ω, 1%, 0603
3.3 V linear regulator
32 kb I 2 C serial EEPROM
5 V reference, MSOP
Ultralow noise XFET voltage reference
4.096 V reference
Dual op amp
Quad op amp
Op amp
Daughter Board
Description
Red test point
Not applicable
50 V, X7R, ceramic capacitor
6.3 V, tantalum capacitor (Case A)
16-pin (2 × 8) header
10-pin (2 × 5) straight header, 2.54 mm pitch
6-pin (1 × 6) straight header, 2.54 mm pitch
Header, 2.54 mm, PCB, 1 × 8-way
Not applicable
Octal DAC, 4 × 12-bit DACs, 4 × 16-bit DACs
Rev. A | Page 12 of 13
EVAL-AD5678DBZ User Guide
Supplier/Part Number
FEC/1190107
FEC/1759122
GRM188R61A105KA61D
FEC/1432350
FEC/1206013
FEC/2308428
FEC/9689583
FEC/9689508
FEC/1766172
FEC/1667472
FEC/151789
FEC/1667509
FEC/1324660
FEC/9526862
FEC/148-535 and 150-411 (36-pin strip)
FEC/148-535 and 150-411 (36-pin strip)
FEC/1022227 and 150-411
FEC/1627674
FEC/9330402
FEC/9330364
Analog Devices/ADP121-AUJZ33R7
FEC/1331330
Analog Devices/ADR445ARMZ
Analog Devices/ADR431BRZ
Analog Devices/REF198ESZ
Analog Devices/AD8616ARZ
Analog Devices/AD8608ARMZ
Analog Devices/AD8655ARMZ
Supplier/Part Number 1
Do not insert
Not inserted
FEC/1759122
FEC/1190107
FEC/2308428 inserted from solder side
FEC/9689583 inserted from solder side
FEC/9689508 inserted from solder side
FEC/1766172 inserted from solder side
Not inserted
Analog Devices/AD5678ARUZ-2
1, 2
