Bottom
WaveAlert
Key Points
Vertical and Horizontal Preview.
functions let you change the vertical and horizontal controls while the
acquisition is stopped or while it is waiting for the next trigger. The
oscilloscope rescales and repositions the current acquisition in response
to the new control settings, and then uses the new settings for the next
acquisition.
TDS3000C Series Oscilloscope User Manual
Side
Wfm Anomaly
Detection
On Off
Sensitivity nn.n%
Beep On Anomaly
On Off
Stop On Anomaly
On Off
Hard Copy On
Anomaly
On Off
Wfms To Disk On
Anomaly
On Off
Highlight Entire Wfm
Highlight Anomalies
Description
Enables or disables the WaveAlert
function. (See page 68, WaveAlert
Waveform Anomaly Detection.)
Sets the WaveAlert sensitivity. Use
the general purpose knob to set
sensitivity from 0% (least sensitive)
to 100% (most sensitive).
When On, the oscilloscope beeps
when it detects a waveform anomaly
on any active channel.
When On, the oscilloscope stops
waveform acquisition when there is a
waveform anomaly on any channel.
The input waveforms and anomalies
remain displayed on the screen.
When On, the oscilloscope sends an
image of the screen to the hard copy
device or USB flash drive file when
there is a waveform anomaly on any
channel.
When On, the oscilloscope saves
the anomalous waveform(s) data to
a file on a USB flash drive.
Highlights the entire anomalous
waveform.
Highlights just the anomalous data
in a waveform.
The vertical and horizontal preview
Reference
63
