Page 1 TDS3000 & TDS3000B Digital Phosphor Oscilloscopes Operator Training Kit Manual *P071105101* 071-1051-01...
Page 3 TDS3000 & TDS3000B Operator Training Kit Manual 071-1051-01 www.tektronix.com...
Page 4 This product training document file is protected by Copyright © Tektronix, Inc. All rights reserved. End users of this Tektronix product training document file are permitted to print any portion of this file or copy the electronic file for personal use. Print or electronic reproduction of this product training document file for resale is strictly prohibited.
Page 5 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
Page 7: General Safety Summary
If you suspect there is damage to this product, have it inspected by qualified service personnel. Do Not Operate in Wet/Damp Conditions. Do Not Operate in an Explosive Atmosphere. Keep Product Surfaces Clean and Dry. TDS3000 & TDS3000B Operator Training Kit Manual...
Page 8: Safety Terms And Symbols
WARNING indicates an injury hazard not immediately accessible as you read the marking. CAUTION indicates a hazard to property including the product. Symbols on the Product. These symbols may appear on the product: CAUTION Standby Refer to Manual TDS3000 & TDS3000B Operator Training Kit Manual...
Page 9 This phone number is toll free in North America. After office hours, please leave a voice mail message. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix web site for a list of offices. TDS3000 & TDS3000B Operator Training Kit Manual...
Page 10 Contacting Tektronix TDS3000 & TDS3000B Operator Training Kit Manual...
Page 11 Table of Contents Getting Started With TDS3000 Oscilloscopes ......1-1 Introduction to TDS3000 Oscilloscopes....... 1-3 Features of the TDS3000 Models ........1-3 Differences Between the TDS3000 Models ....1-5 Primary Front Panel Control Sections ......... 1-9 VERTICAL Section Controls.......... 1-10 HORIZONTAL Section Controls ........1-20 TRIGGER Section Controls...........
Page 12 Operating VERTICAL Controls ..........2-5 Using VERTICAL Controls to Modify Acquisition and Display ................2-5 Working with Channel Displays ........2-9 Switching the Input Coupling ......... 2-12 Using Vertical Offset Controls ........2-15 Using the MATH Menu ..........2-20 Summary .................2-24 Using HORIZONTAL Controls ..........3-1 Setting Up HORIZONTAL Controls ........
Page 13 Using Menu Function Controls ..........6-1 Setting Up Menu Function Controls........6-2 Operating the Menu Function Controls........ 6-4 MEASURE Menu Function Controls ....... 6-4 SAVE/RECALL Menu Function Controls....... 6-16 QUICKMENU Function Control ........6-22 CURSOR Menu Function Controls........ 6-25 DISPLAY Menu Function Controls ........ 6-28 UTILITY Menu Function Controls ........
Page 14 TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 15: Getting Started With Tds3000 Oscilloscopes
TDS3000 oscilloscope. Note: All references to TDS3000 oscilloscopes also apply to TDS3000B oscilloscopes, except as specified. At the end of this module, you will be able to: • Identify the primary front panel and the menu-based controls of a TDS3000 oscilloscope.
Page 16 This module includes the following sections: • Introduction to TDS3000 Oscilloscopes • Primary Front Panel Control Sections • Menu Function Controls • Setting Up a TDS3000 Oscilloscope Figure 1.1 shows a TDS3000 oscilloscope. Figure 1.1: A TDS3054 digital phosphor oscilloscope TDS 3000 Series Oscilloscopes –...
Page 17: Introduction To Tds3000 Oscilloscopes
Getting Started With TDS3000 Oscilloscopes Introduction to TDS3000 Oscilloscopes A TDS3000 oscilloscope is an advanced DPO (Digital Phosphor Oscilloscope) that you can use for various applications, such as servicing, repairing, manufacturing, testing, and designing systems that include embedded, computing, and communication systems. Features of the TDS3000 Models The following are the basic features of the TDS3000 series of oscilloscopes:...
Page 18 Getting Started With TDS3000 Oscilloscopes Waveform and instrument setup storage The TDS3000 series of oscilloscope models have a built-in floppy drive. The floppy drive can be used to store waveforms, screen images, and instrument setups on a 1.44 MB IBM PC-compatible floppy disk. Flexibility You can install a variety of application and communication modules to expand the capabilities of a...
Page 19: Differences Between The Tds3000 Models
Getting Started With TDS3000 Oscilloscopes Differences Between the TDS3000 Models The TDS3000 series of oscilloscopes consists of six base models. The following table lists the primary differences between them (these models include the TDS3000B models as well): Models Number of Bandwidth Maximum...
Page 20 Getting Started With TDS3000 Oscilloscopes Preliminary Functional Check Perform the following functional check procedure on a TDS3000 oscilloscope to verify that it is functioning properly. 1. Connect your TDS3000 oscilloscope to an AC supply using the appropriate power cord and adapters.
Page 21 Getting Started With TDS3000 Oscilloscopes 5. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 6. In the VERTICAL section, push the MENU button to activate the menu for Channel 1. 7. Connect a P6139A passive voltage attenuation probe to the CH1 input connector.
Page 22 Getting Started With TDS3000 Oscilloscopes You should see a waveform similar to that shown in Figure 1.2. Figure 1.2: Square waveform Your oscilloscope has passed the preliminary functional check if you observe a square wave similar to the waveform shown in Figure 1.2 for channel 1. TDS 3000 Series Oscilloscopes –...
Page 23: Primary Front Panel Control Sections
Getting Started With TDS3000 Oscilloscopes Primary Front Panel Control Sections This section describes the primary front panel controls. You can use these controls to setup signal acquisition and display. In this section, you will learn about the following: • VERTICAL Section Controls •...
Page 24: Vertical Section Controls
Getting Started With TDS3000 Oscilloscopes You control each menu option by pushing the associated bottom-screen menu button. You control the submenu for each menu option by pushing the associated side- screen button. VERTICAL Section Controls This topic describes the VERTICAL section controls. You can use the VERTICAL controls to set or modify the waveform vertical scale, position, input coupling, bandwidth, and other signal conditioning.
Page 25 Getting Started With TDS3000 Oscilloscopes Figure 1.3 shows the VERTICAL section controls of a TDS3000 oscilloscope. Figure 1.3: TDS3000 VERTICAL section controls Note: The two-channel TDS3000 oscilloscopes do not have the CH3 and CH4 buttons. TDS 3000 Series Oscilloscope – Operator Training Kit 1-11...
Page 26 Getting Started With TDS3000 Oscilloscopes The VERTICAL controls are divided into the following three subsections: • Dedicated controls • Menu-based controls • MATH menu controls Dedicated Controls The dedicated controls in the VERTICAL section include the following: • VERTICAL POSITION knob •...
Page 27 Getting Started With TDS3000 Oscilloscopes In addition, if that channel is selected as the trigger, then the trigger level arrow at the right of the screen also follows the change in position of the waveform. OFF button The OFF button removes a selected waveform from the oscilloscope display.
Page 28 Getting Started With TDS3000 Oscilloscopes Channel selection and reference waveform selection buttons The channel selection (CH1, CH2, CH3, and CH4) buttons allow you to select and display a waveform. The reference waveform selection (REF) button allows you to select a waveform reference location to which you can save or recall waveform data.
Page 29 Getting Started With TDS3000 Oscilloscopes To activate the VERTICAL menu-based functions for a channel, follow these steps: 1. In the VERTICAL section, push the CH1 button. 2. In the VERTICAL section, push the MENU button. Figure 1.4 shows the channel 1 menu at the bottom of the display.
Page 30 Getting Started With TDS3000 Oscilloscopes Menu Option Description Coupling You use this option to select DC, AC, or Ground coupling. You can also select an input resistance for DC or AC coupling. Invert You use this option to invert the polarity of the displayed waveform.
Page 31 You can also perform FFT operations on the displayed waveforms if the TDS3FFT FFT application module is installed on your TDS3000 oscilloscope. Note: All TDS3000B oscilloscopes include the TDS3FFT application module. TDS 3000 Series Oscilloscope – Operator Training Kit 1-17...
Page 32 Getting Started With TDS3000 Oscilloscopes To activate the MATH menu controls, perform the following step: • In the VERTICAL section, push the MATH button. The MATH menu is activated at the bottom of the display. Figure 1.5 shows the TDS3000 oscilloscope MATH menu-based controls.
Page 33 Getting Started With TDS3000 Oscilloscopes The MATH menu provides the following options on the bottom-screen and associated side-screen menus: Dual Wfm Math You use this option to select the source waveforms and the math operation to be performed. For procedures using the VERTICAL controls, see Using VERTICAL Controls starting on page 2-1.
Page 34: Horizontal Section Controls
Getting Started With TDS3000 Oscilloscopes HORIZONTAL Section Controls This topic describes the HORIZONTAL section controls. You use the HORIZONTAL controls to modify the horizontal scale of the display, which represents the time base of a displayed waveform. You can also use the HORIZONTAL controls to adjust the trigger position and examine a waveform in detail.
Page 35 Getting Started With TDS3000 Oscilloscopes The HORIZONTAL section on the front panel includes the following controls: • HORIZONTAL POSITION knob • DELAY button • HORIZONTAL SCALE knob • Zoom button HORIZONTAL POSITION knob The HORIZONTAL POSITION knob allows you to adjust the waveform horizontal position.
Page 36 Getting Started With TDS3000 Oscilloscopes Note: A full pre-trigger setting sets the trigger position of a waveform near 100% of a record, while a full post- trigger setting sets the trigger position near 0% of a record. This trigger position selection is possible only when the default HORIZONTAL DELAY function is turned off, as explained in the next paragraph.
Page 37 Getting Started With TDS3000 Oscilloscopes HORIZONTAL SCALE knob The HORIZONTAL SCALE knob allows you to adjust the time base of the displayed waveform. When delay is off, you adjust the scale to expand or contract around the trigger point. When delay is on, you adjust the scale to expand or contract around the center of the screen.
Page 38: Trigger Section Controls
Getting Started With TDS3000 Oscilloscopes TRIGGER Section Controls This topic describes the TRIGGER section controls. You use the TRIGGER controls to set the trigger threshold conditions for a signal and assign a holdoff time to the trigger. Figure 1.7 shows the TRIGGER section controls of a TDS3000 oscilloscope.
Page 39 Getting Started With TDS3000 Oscilloscopes The TRIGGER section on the front panel includes the following controls: • TRIGGER LEVEL knob • SET TO 50% button • FORCE TRIG button • B TRIG button • TRIGGER MENU button TRIGGER LEVEL knob The TRIGGER LEVEL knob allows you to adjust the trigger level of a displayed waveform.
Page 40 Getting Started With TDS3000 Oscilloscopes FORCE TRIG button The FORCE TRIG button forces a trigger event. You can use this button to force a trigger even in the absence of an input signal. This function is useful when using Normal (selectable in TRIGGER MENU, Mode & Holdoff) or SINGLE SEQ (selectable on the front panel) trigger modes.
Page 41 Getting Started With TDS3000 Oscilloscopes The B TRIG menu is activated at the bottom of the display, as shown in Figure 1.8. Figure 1.8: Menu-based controls for the B TRIG button Menu Option Description B Trigger After A You use this option to set the B- trigger conditions for after the A-trigger has triggered the input signal.
Page 42 Getting Started With TDS3000 Oscilloscopes You use these options to set Source, the B-trigger source, coupling, Coupling, Slope, slope, and level. These settings and Level are independent of similar settings for the A-trigger. TRIGGER MENU button You use the TRIGGER MENU button to choose Edge or Video triggering for an input signal.
Page 43 Getting Started With TDS3000 Oscilloscopes 3. Push the appropriate bottom-screen menu button to select Source. Figure 1.9 shows the menu-based controls for the TRIGGER section. Figure 1.9: TRIGGER Section menu-based controls TDS 3000 Series Oscilloscope – Operator Training Kit 1-29...
Page 44 Getting Started With TDS3000 Oscilloscopes Depending on the options and base configuration of your TDS3000 or TDS3000B oscilloscope, you may have additional trigger selections for advanced functions, such as Logic, Pulse, Comm and/or Extended Video triggering. This Operator Training Kit does not cover the operation of these advanced triggering functions.
Page 45 TDS3000B oscilloscopes, and all two channel TDS3000 models), the lowest numbered active channel in the display, or alternating on all active channels (available only on TDS3000B oscilloscopes). You use this option to select DC, Coupling HF Reject, LF Reject, or Noise Reject coupling for a trigger.
Page 46 Getting Started With TDS3000 Oscilloscopes You use this option to change the Level trigger threshold voltage level. You use this option to control the Mode & Holdoff trigger mode and holdoff settings. Video Triggering Video type triggering is used to trigger on odd fields, even fields, or all the lines of a NTSC, PAL, or SECAM video signal.
Page 47: Acquire Section Controls
Getting Started With TDS3000 Oscilloscopes Video triggering uses the same Source source selection as Edge triggering. You use this option to select Trigger On triggering on all video lines or fields. Video triggering provides the same Mode & Holdoff mode and holdoff menu options as Edge triggering.
Page 48 Getting Started With TDS3000 Oscilloscopes Figure 1.10 shows the ACQUIRE section controls. Figure 1.10: TDS3000 ACQUIRE section controls The ACQUIRE section consists of the following controls: • RUN/STOP button • SINGLE SEQ button 1-34 TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 49 Getting Started With TDS3000 Oscilloscopes • AUTOSET button • WAVEFORM INTENSITY knob • The ACQUIRE MENU button RUN/STOP The RUN/STOP button allows you to stop and start waveform acquisitions by the oscilloscope. SINGLE SEQ The SINGLE SEQ button enables a single-sequence acquisition of a signal.
Page 50 Getting Started With TDS3000 Oscilloscopes AUTOSET The AUTOSET button automatically adjusts the VERTICAL, HORIZONTAL, and TRIGGER controls of the oscilloscope for a usable display. You can also manually adjust these controls to optimize the display. An indicator light next to the AUTOSET button temporarily indicates when autoset is initialized.
Page 51 Getting Started With TDS3000 Oscilloscopes WAVEFORM INTENSITY The WAVEFORM INTENSITY knob allows you to adjust the intensity of a displayed waveform. This feature allows you to get both an analog oscilloscope and a digital oscilloscope view of waveforms. You use medium waveform intensity to get an analog-oscilloscope view of time-varying signals and those containing modulation.
Page 52 Getting Started With TDS3000 Oscilloscopes ACQUIRE MENU To activate the menu-based functions for the ACQUIRE section, perform the following step: • In the ACQUIRE section, push the MENU button. The ACQUIRE menu is activated at the bottom of the display, as shown in Figure 1.11. Figure 1.11: Menu-based functions for the ACQUIRE section 1-38...
Page 53 You use this option to execute and Autoset reverse the autoset function. You use this option (available only WaveAlert on a TDS3000B oscilloscope) to detect anomalies on a repeating waveform, and act on the capture of each anomaly. These actions include Beep, Stop, Hard Copy, and Save Wfms To Disk.
Page 54: Other Controls
Getting Started With TDS3000 Oscilloscopes For procedures using the ACQUIRE controls, see Using ACQUIRE Controls starting on page 5-1. Other Controls A TDS3000 oscilloscope has various other controls that you can use to select and modify a displayed waveform. This topic covers the following controls on the front panel: •...
Page 55 Getting Started With TDS3000 Oscilloscopes SELECT The SELECT button allows you to toggle between two cursors on the display. General purpose knob The general purpose knob allows you to perform different functions, such as positioning cursors on the oscilloscope display and setting numerical values for some menu items.
Page 56: Menu Function Controls
Getting Started With TDS3000 Oscilloscopes Menu Function Controls You can use the menu function controls to perform various functions. These functions may include taking automatic measurements, saving and recalling waveforms, modifying the oscilloscope display characteristics, and accessing oscilloscope setup utilities. To access the menus for each function, push a menu function button at the top of the front panel.
Page 57: Measure Menu Function Controls
Getting Started With TDS3000 Oscilloscopes Figure 1.12 shows the front panel menu function controls of a TDS3000 oscilloscope. Figure 1.12: TDS3000 front panel menu function controls MEASURE Menu Function Controls The MEASURE menu function controls allow you to take pre-defined automated measurements of waveforms. TDS 3000 Series Oscilloscope –...
Page 58 Getting Started With TDS3000 Oscilloscopes To activate selections for the MEASURE menu function, perform the following step: • On the top of the front panel, push the MEASURE menu button. The MEASURE menu is activated at the bottom of the display, as shown in Figure 1.13. Figure 1.13: MEASURE menu 1-44 TDS 3000 Series Oscilloscopes –...
Page 59 Getting Started With TDS3000 Oscilloscopes Menu Option Description Select Measurement You use this option to select the automatic measurement that you want to perform, such as amplitude, frequency, negative width, or rise time measurement. You can display up to four measurements on the screen.
Page 60: Save/Recall Menu Function Controls
Getting Started With TDS3000 Oscilloscopes Reference Levels You use this option to specify custom or default reference levels. For procedures using the MEASURE menu function controls, see MEASURE Menu Function Controls starting on page 6-4. SAVE/RECALL Menu Function Controls You use the SAVE/RECALL menu function to save and recall oscilloscope setups or waveforms to nonvolatile memory locations or to a floppy disk.
Page 61 Getting Started With TDS3000 Oscilloscopes The SAVE/RECALL menu is activated at the bottom of the display, as shown in Figure 1.14. Figure 1.14: SAVE/RECALL menu TDS 3000 Series Oscilloscope – Operator Training Kit 1-47...
Page 62 Getting Started With TDS3000 Oscilloscopes Menu Option Description Save Current You use this option to save a setup Setup to a floppy disk or to a nonvolatile memory location. Recall Saved You use this option to recall a Setup saved setup from a floppy disk or from a nonvolatile memory location.
Page 63 Getting Started With TDS3000 Oscilloscopes You use this option to access file File Utilities utilities, such as Delete, Rename, Copy, and Create Directory. You use this option to assign Labels unique labels to reference waveforms and instrument setups stored in nonvolatile memory locations or on a floppy disk.
Page 64: Quickmenu Function Controls
Getting Started With TDS3000 Oscilloscopes QUICKMENU Function Controls You use the QUICKMENU control to access special menus that provide key functions in a single menu. Scope is a standard QuickMenu that you can use to control the basic functions of a TDS3000 oscilloscope. You can perform the most frequently used functions for each section with the Scope QuickMenu.
Page 65 Getting Started With TDS3000 Oscilloscopes To activate the menu-based functions for the CURSOR menu function controls, perform the following step: • On the top of the front panel, push the CURSOR menu button. The CURSOR menu is activated at the bottom of the display, as shown in Figure 1.15.
Page 66: Display Menu Function Controls
Getting Started With TDS3000 Oscilloscopes Menu Option Description You use this option to activate Function cursors and select between horizontal and vertical cursors. You use this option to set Mode cursors to move together or independently of each other. You use this option to set V Bar V Bar Units and horizontal measurement units.
Page 67 Getting Started With TDS3000 Oscilloscopes To activate the menu-based functions for the DISPLAY menu function controls, perform the following step: • On the top of the front panel, push the DISPLAY menu button. The DISPLAY menu is activated at the bottom of the display, as shown in Figure 1.16.
Page 68 Getting Started With TDS3000 Oscilloscopes Menu Option Description You use this option to set the Waveform Display display type to dots or vectors and control waveform persistence settings. You use this option to set the Backlight Intensity backlight intensity for the oscilloscope display.
Page 69: Utility Menu Function Controls
Getting Started With TDS3000 Oscilloscopes UTILITY Menu Function Controls You use the UTILITY menu function controls to access the oscilloscope setup utility functions, such as selecting a display language, setting the system date and time, setting up hard copy and communication ports, and running internal diagnostic routines.
Page 70 Getting Started With TDS3000 Oscilloscopes The UTILITY menu is activated at the bottom of the display, as shown in Figure 1.17. Figure 1.17: UTILITY menu Menu Option Description System Config You use this option to set the display language and date and time, control battery timeouts, and erase the memory locations of an oscilloscope.
Page 71 Getting Started With TDS3000 Oscilloscopes You use this option to control the System Apps utilities on an installed optional application module. You use this option to set up the System I/O communication ports of an oscilloscope, such as GPIB and RS-232.
Page 72 Getting Started With TDS3000 Oscilloscopes System Diags You use this option to execute and control internal diagnostic routines for an oscilloscope, such as executing and looping diagnostic routines and viewing the error log. For a procedure using the UTILITY menu function controls, see UTILITY Menu Function Controls starting on page 6-41.
Page 73: Setting Up A Tds3000 Oscilloscope
Getting Started With TDS3000 Oscilloscopes Setting Up a TDS3000 Oscilloscope In this section, you will learn how to set up a TDS3000 oscilloscope and compensate a passive voltage probe. Grounding an Oscilloscope Proper grounding is essential for your own safety, the safety of the oscilloscope, and for taking accurate measurements.
Page 74 Getting Started With TDS3000 Oscilloscopes Grounding protects the circuits of your oscilloscope. If your oscilloscope is not grounded, a high voltage spike in the input current can damage the circuits of the oscilloscope. Such a spike can also pass through the case of the oscilloscope and injure you.
Page 75: Safety Precautions
Getting Started With TDS3000 Oscilloscopes Safety Precautions You must observe certain safety precautions while setting up a TDS3000 oscilloscope in order to avoid injury to yourself and damage to the oscilloscope. The following safety precautions are to be adhered to while operating the TDS3000 oscilloscope: •...
Page 76 Getting Started With TDS3000 Oscilloscopes • Ensure that the oscilloscope is properly grounded before you connect the various accessories, such as probes, to the input or output terminals of the oscilloscope. • Connect the probe ground lead only to the ground potential.
Page 77: Introduction To The Training 1 Signal Board
Getting Started With TDS3000 Oscilloscopes Introduction to the Training 1 Signal Board You will use the Training 1 signal board for most procedures in this Operator Training Kit. Figure 1.18 shows the Training 1 signal board. Figure 1.18: The Training 1 signal board TDS 3000 Series Oscilloscope –...
Page 78 9-volts, 1A, to power the Training 1 signal board. A 9-volt battery is supplied with your Training 1 signal board. However, for long-term use you can also order the appropriate wall transformer with the recommended output for your country from Tektronix. Part Numbers Wall Transformer Accessories 119-4238-00...
Page 79 Getting Started With TDS3000 Oscilloscopes Note: When using a wall transformer for power, you should remove the 9-volt battery from the Training 1 signal board. You should also disconnect the wall transformer from the Training 1 signal board when the signal board is not in use.
Page 80 Getting Started With TDS3000 Oscilloscopes Pins 1 to 6 of the Training 1 signal board provide digital signals, while pins 9 to 16 provide analog signals. All pins labeled GND provide the common signal reference. For a description of the signal from each pin of the Training 1 signal board, see Appendix A, Training 1 Signal Board: Signal Definitions, starting on page A-1.
Page 81: Probe Compensation
Getting Started With TDS3000 Oscilloscopes Probe Compensation When you attach a passive voltage attenuation probe to an oscilloscope, the capacitances of both the probe cable and the oscilloscope’s input combine. This combined capacitance must match the capacitance of the probe’s input attenuation circuit. You must balance these capacitive effects with respect to the probe and oscilloscope combination.
Page 82 Getting Started With TDS3000 Oscilloscopes The following procedure enables you to balance the capacitive elements of the CH1 and CH2 probes with an oscilloscope by compensating the probes. Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To compensate the CH1 and CH2 probes, follow these steps: 1.
Page 83 Getting Started With TDS3000 Oscilloscopes 7. Turn the VERTICAL POSITION knob to position the CH1 waveform in the top half of the display. 8. In the VERTICAL section, push the CH2 button to re-activate the controls for Channel 2. 9. Turn the VERTICAL SCALE knob to set CH2 to 2.00V on the oscilloscope display.
Page 84 Getting Started With TDS3000 Oscilloscopes However, the waveforms could also have distorted corners. Such waveforms could be similar to the waveforms shown in Figure 1.20 or Figure 1.21. Figure 1.20: Undercompensated probe Figure 1.21: Overcompensated probe 1-70 TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 85 Getting Started With TDS3000 Oscilloscopes An undercompensated or overcompensated probe can cause errors in measurement, especially with respect to pulse rise or fall times. To compensate the probes correctly, you must use the probe adjustment tool provided with the probes. The probe adjustment tool resembles a small screwdriver.
Page 86: Summary
Getting Started With TDS3000 Oscilloscopes Summary In this module, you learned about the following: • The basic features of a TDS3000 oscilloscope. • The differences between the various models of the TDS3000 series of oscilloscopes. • The layout of the various controls on the front panel of a TDS3000 oscilloscope.
Page 87: Using Vertical Controls
Using VERTICAL Controls This module focuses on using the VERTICAL controls of a TDS3000 oscilloscope to modify the displayed waveform. This module includes the following sections: • Setting Up a TDS3000 Oscilloscope for VERTICAL Controls • Operating VERTICAL Controls TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 88: Setting Up Vertical Controls
Using VERTICAL Controls Setting Up VERTICAL Controls Figure 2.1 shows the VERTICAL controls of a TDS3000 oscilloscope. Figure 2.1: TDS3000 VERTICAL controls Before you begin using the VERTICAL controls of a TDS3000 oscilloscope, you must set up the oscilloscope for operation exercises with the VERTICAL controls. TDS 3000 Series Oscilloscopes –...
Page 89 Using VERTICAL Controls The following procedure sets up a TDS3000 oscilloscope for use with the VERTICAL controls. To set up a TDS3000 oscilloscope for the VERTICAL controls, follow these steps: 1. Connect a P6139A 10X passive voltage attenuation probe to the CH1 connector on the TDS3000 front panel.
Page 90 Using VERTICAL Controls 6. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 7. In the ACQUIRE section, push the AUTOSET button. You should see a waveform similar to that shown in Figure 2.2. Figure 2.2: CLOCK signal TDS 3000 Series Oscilloscopes –...
Page 91: Operating Vertical Controls
Using VERTICAL Controls Operating VERTICAL Controls In this section, you will perform various procedures to modify a displayed waveform by using the VERTICAL section controls. Using VERTICAL Controls to Modify Acquisition and Display The waveform shown in Figure 2.2 appears to be a single waveform.
Page 92 Using VERTICAL Controls The following procedure enables you to use the VERTICAL controls to modify the acquisition and display of a waveform. Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To affect the acquisition and display of a displayed waveform by using the VERTICAL controls, follow these steps: 1.
Page 93 Using VERTICAL Controls 3. In the ACQUIRE section, push the RUN/STOP button twice. This reacquires the signal and stops the acquisition again. 4. In the VERTICAL section, turn the POSITION knob to move the waveform one division below its current position.
Page 94 Using VERTICAL Controls You will see a waveform similar to that shown in Figure 2.3. Figure 2.3: Dimmed waveform display with stopped signal acquisition and shifted waveform 5. In the ACQUIRE section, push the RUN/STOP button to resume signal acquisition. The waveform appears dim because the oscilloscope display shows only the last sampled acquisition after the signal acquisition is stopped.
Page 95: Working With Channel Displays
Using VERTICAL Controls When you change the vertical position of the waveform, the oscilloscope displays the last waveform saved by the intensity graded display. Working with Channel Displays You can simultaneously view multiple waveforms on a TDS3000 oscilloscope. These include up to four waveforms from the input channels, four saved reference waveforms, and a math waveform.
Page 96 Using VERTICAL Controls Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To activate all input channels, follow these steps: 1. In the VERTICAL section, push the MENU button. 2. In the VERTICAL section, push the CH2 button to display the blue CH2 waveform.
Page 97 Using VERTICAL Controls You will see a display similar to that shown in Figure 2.4. Figure 2.4: 4 Channel display You can select any waveform by pushing the appropriate channel button in the VERTICAL section. You can also remove the waveform from the display by selecting a waveform and then pushing the OFF button in the VERTICAL section.
Page 98: Switching The Input Coupling
Using VERTICAL Controls Switching the Input Coupling Coupling is used to connect an electrical signal from one device to another. An example of coupling is connecting the Training 1 signal board to a TDS3000 oscilloscope. A TDS3000 oscilloscope allows you to select AC, DC, or ground coupling.
Page 99 Using VERTICAL Controls 4. Push the appropriate side-screen menu button to select AC. Note that the triggering for the signal stops and the waveform shifts down. The waveform shifts down because AC coupling blocks the DC component of the signal. However, the auto baseline trigger causes an untriggered waveform to appear on the oscilloscope display.
Page 100 Using VERTICAL Controls You will see a waveform similar to that shown in Figure 2.5. Figure 2.5: Modified input coupling Notice that the general purpose knob adjusts the volts/div scale with a very fine resolution. In addition, when you vary the size of the waveform on the oscilloscope display, the trigger level moves up and down with the waveform.
Page 101: Using Vertical Offset Controls
Using VERTICAL Controls Using Vertical Offset Controls At times, you may need to look at high amplitude signals or small signal details at very high resolutions. You can view such signal details by using the vertical Offset control. The following procedure enables you to change the vertical expansion reference with respect to the waveform by using the vertical Offset control.
Page 102 Using VERTICAL Controls 2. At the top of the front panel, push the SAVE/RECALL menu button. 3. Push the appropriate bottom-screen menu button to select Recall Factory Setup. 4. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 5.
Page 103 Using VERTICAL Controls You will see a waveform similar to that shown in Figure 2.6. Figure 2.6: Vertically expanded waveform around the center graticule line 7. Turn the VERTICAL SCALE knob counter-clockwise to set CH1 for 2.00 V on the oscilloscope display. When you change the volts/division setting back from 100 mV to 2.00 V, the waveform moves back from 40 divisions to 2.0 divisions.
Page 104 Using VERTICAL Controls 8. In the VERTICAL section, push the MENU button. 9. Push the appropriate bottom-screen menu button to select Offset. 10. At the top of the front panel, turn the general purpose knob to vertically align the top of the waveform with the yellow arrow, labeled 1, at the left of the oscilloscope display.
Page 105 Using VERTICAL Controls You will see a waveform similar to that shown in Figure 2.7. Figure 2.7:Changed vertical waveform expansion reference with respect to a waveform In this procedure, you learned how to change the vertical waveform expansion reference with respect to a waveform by using the vertical Offset control.
Page 106: Using The Math Menu
In addition, you can perform Fast Fourier Transform (FFT) operations on a waveform. Note: All TDS3000B models have FFT as a standard MATH function. All other TDS3000 models require an option for FFT.
Page 107 Using VERTICAL Controls 2. On the front panel, connect a P6139A passive voltage attenuation probe to the CH2 input connector. 3. Connect the CH 2 probe tip to the DIFF – signal on pin 13 and the CH2 ground lead to GND on pin14 of the Training 1 signal board.
Page 108 Using VERTICAL Controls 8. In the VERTICAL section, turn the SCALE knob to set CH1 for 500mV on the oscilloscope display. 9. In the VERTICAL section, push the CH 2 button. 10. Turn the VERTICAL SCALE knob to set CH2 for 500mV on the oscilloscope display.
Page 109 Using VERTICAL Controls You will see a waveform similar to that shown in Figure 2.8. Figure 2.8: CH1-CH2 As you can see in Figure 2.8, the MATH function is able to extract a small differential heart beat signal from the large common mode sine wave that is on both Channel 1 and Channel 2 signal inputs.
Page 110: Summary
Using VERTICAL Controls Summary In this module, you learned how to perform the following tasks: • Set up a TDS3000 oscilloscope for VERTICAL controls. • Modify the vertical scale calibration by using the VERTICAL SCALE knob. • Position a waveform on the vertical scale by using the VERTICAL POSITION knob.
Page 111: Using Horizontal Controls
Using HORIZONTAL Controls This module focuses on the HORIZONTAL controls of a TDS3000 oscilloscope. In this module, you will use various procedures to modify a displayed waveform by using the HORIZONTAL controls. This module includes the following sections: • Setting Up a TDS3000 Oscilloscope for HORIZONTAL Controls •...
Page 112: Setting Up Horizontal Controls
Using HORIZONTAL Controls Setting Up HORIZONTAL Controls Figure 3.1 shows the HORIZONTAL controls of a TDS3000 oscilloscope. Figure 3.1: TDS3000 HORIZONTAL controls Before you begin using the HORIZONTAL controls, you must set up the oscilloscope for operation exercises with the HORIZONTAL controls. TDS 3000 Series Oscilloscopes –...
Page 113 Using HORIZONTAL Controls The following procedure sets up a TDS3000 oscilloscope for use with the HORIZONTAL controls. This procedure will enable you to set the oscilloscope to its default settings for use with HORIZONTAL controls. To set up a TDS3000 oscilloscope for the HORIZONTAL controls, follow these steps: 1.
Page 114 Using HORIZONTAL Controls 4. On the Training 1 signal board, push the POWER button until the Digital PWR light is on. 5. On the top of the front panel, push the SAVE/RECALL menu button. 6. Push the appropriate bottom-screen menu button to select Recall Factory Setup.
Page 115 Using HORIZONTAL Controls You will see a waveform similar to that shown in Figure 3.2. Figure 3.2: CLOCK Signal Notice that Figure 3.2 shows a bar graph with brackets on the top of the screen. The bar is of the same color as the selected channel, MATH, or REF, and represents the total record length of the waveform(s) on screen.
Page 116: Operating Horizontal Controls
Using HORIZONTAL Controls Operating HORIZONTAL Controls The HORIZONTAL control section has two knobs, the SCALE knob and the POSITION knob. SCALE knob The HORIZONTAL SCALE knob is used to adjust the horizontal scale factor of a selected waveform. The horizontal scale of a waveform is measured in seconds/division.
Page 117: Affecting The Acquisition And Display Of A Waveform
Using HORIZONTAL Controls When you push the COARSE button on the top of the front panel, you can make adjustments with larger increments using the POSITION knob. After setting up a TDS3000 oscilloscope for HORIZONTAL controls, you can begin the procedures to modify a displayed waveform and take measurements.
Page 118 Using HORIZONTAL Controls The following procedure demonstrates the steps to select a portion of a displayed waveform by using the HORIZONTAL POSITION knob. Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To change the horizontal position of a waveform, follow these steps: 1.
Page 119 Using HORIZONTAL Controls You will see a display similar to that shown in Figure 3.3. Figure 3.3: Zoom mode waveform display 2. Turn the HORIZONTAL SCALE knob clockwise to set the bottom waveform display for Z 40.0ns. This magnifies the displayed waveform centered around the trigger point.
Page 120 Using HORIZONTAL Controls 3. Turn the HORIZONTAL POSITION knob clockwise to align the closest rising edge of the lower displayed waveform before the trigger point to the center vertical graticule line of the lower waveform window. 4. Turn the HORIZONTAL SCALE knob to further magnify the selected rising edge to Z 4.00ns on the display, where Z denotes the zoom mode.
Page 121 Using HORIZONTAL Controls You will see a waveform similar to that shown in Figure 3.4. Figure 3.4: Magnified waveform display In this procedure, you used the HORIZONTAL POSITION knob to select a portion of a displayed waveform. Then, you magnified the selected portion by using the zoom button and the HORIZONTAL SCALE knob.
Page 122: Changing The Zoom Mode Limits
Using HORIZONTAL Controls Finally, you verified the horizontal resolution to be Normal such that the oscilloscope acquired a 10,000- point waveform. The zoom limit is 200X magnification. If you set the horizontal resolution to Fast Trigger, the oscilloscope acquires 500-point waveforms at a high repetition rate.
Page 123 Using HORIZONTAL Controls The following procedure enables you to change the zoom limit. Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To change the zoom limit, follow these steps: 1. Push the appropriate side-screen menu button to select Fast Trigger (500 points).
Page 124 Using HORIZONTAL Controls 3. Push the appropriate side-screen menu button to select Normal (10k points). 4. Push the appropriate side-screen menu button to select Fast Trigger (500 points). The zoom limit changes from 10X in the Fast Trigger mode to 50X in the Normal mode. The zoom limit for the Normal mode is 200X.
Page 125: Delaying The Acquisition Of A Waveform
Using HORIZONTAL Controls When you switch between Fast Trigger (500 points) and Normal (10k points), the oscilloscope maintains the main waveform at the same time per division setting to ensure a constant view. This means that the sample rate, on the bottom of the oscilloscope display, changes by as much as 20 to 1.
Page 126 Using HORIZONTAL Controls The following procedure enables you to use a second trigger to stabilize a displayed signal that is enabled after a specified delay from the first trigger. To delay the signal acquisition to the B TRIG, follow these steps: 1.
Page 127 Using HORIZONTAL Controls 7. In the TRIGGER section, turn the LEVEL knob to set the trigger level for 3.00 V on the oscilloscope display. 8. In the ACQUIRE section, turn the WAVEFORM INTENSITY knob to increase the intensity of the displayed waveform to maximum.
Page 128 Using HORIZONTAL Controls You will see a waveform similar to that shown in Figure 3.6. These unstable signals overlapping on the screen are an overlap of many different delay conditions. Figure 3.6: Unstable overlapping waveforms Notice that the trigger markers show that the trigger point is positioned before the acquired waveform.
Page 129 Using HORIZONTAL Controls 12. In the TRIGGER section, push the MENU button. 13. Push the appropriate bottom-screen menu button to select Mode Auto & Holdoff. 14. Push the appropriate side-screen menu button to select Holdoff (Time). 15. At the top of the front panel, turn the general purpose knob to set the holdoff time between 10.000us and 11.000us.
Page 130 Using HORIZONTAL Controls 18. In the TRIGGER section, push the B TRIG button. 19. Turn the LEVEL knob to set the B-trigger level for 3.00 V on the display. 20. Push the appropriate side-screen menu button to select Set to Delay Time (B). Notice that the B Trigger After A changes to about 800us.
Page 131 Using HORIZONTAL Controls You should now see a stabilized B trigger display as shown in Figure 3.7. Figure 3.7: B TRIG enabled after a delay of about 800us This procedure enables B-trigger after A-trigger to stabilize unpredictable delayed events on the display. To summarize, you can use a second trigger (B Trig) to stabilize a displayed signal that is enabled after a specified delay from the first trigger (A Trigger).
Page 132: Summary
Using HORIZONTAL Controls Summary In this module, you learned to perform the following tasks: • Set up a TDS3000 oscilloscope for use with the HORIZONTAL controls. • Modify the horizontal scale of a displayed waveform using the HORIZONTAL SCALE knob. •...
Page 133: Using Trigger Controls
Using TRIGGER Controls This module focuses on the TRIGGER controls of a TDS3000 oscilloscope. The module provides procedures that you can use to modify a displayed waveform by using TRIGGER controls. This module includes the following sections: • Setting Up a TDS3000 Oscilloscope for TRIGGER Controls •...
Page 134: Setting Up Trigger Controls
Using TRIGGER Controls Setting Up TRIGGER Controls Figure 4.1 shows the TRIGGER controls of a TDS3000 oscilloscope. Figure 4.1: TDS3000 TRIGGER controls The trigger function of an oscilloscope synchronizes the horizontal sweep at the correct point of the signal, which is essential for clear signal characterization.
Page 135 Using TRIGGER Controls TRIGGER controls allow you to stabilize repeating signals and capture single-shot waveforms. Before you can use the TRIGGER for operation exercises, you must ensure that the oscilloscope is set to its default setting. To set up a TDS3000 oscilloscope for the TRIGGER controls, follow these steps.
Page 136 Using TRIGGER Controls 4. Push the appropriate bottom-screen menu button to select Recall Factory Setup. 5. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 6. In the ACQUIRE section, push the AUTOSET button. 7. In the VERTICAL section, turn the SCALE knob to set Ch1 for 1.00V on the oscilloscope display.
Page 137 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 4.2. Figure 4.2: Pseudo random signal Your TDS3000 oscilloscope is now set up for use with the TRIGGER controls. The next section covers various procedures that you can use to trigger complex signals and examine waveform details that are difficult to detect.
Page 138: Operating Trigger Controls
Using TRIGGER Controls Operating TRIGGER Controls After you set up a TDS3000 oscilloscope for TRIGGER controls, you can set a trigger for incoming signals. The advanced triggering functions of a TDS3000 oscilloscope allow you to trigger a complex signal and examine signal details.
Page 139 Using TRIGGER Controls 3. Push the appropriate bottom-screen menu button to select Source. Ensure that Ch1 is selected as the source. 4. Push the appropriate bottom-screen menu button to select Coupling. 5. Push the appropriate side-screen menu button to select DC. This option may be selected by default.
Page 140 Using TRIGGER Controls 9. Push the appropriate side-screen menu button to select Normal. 10. Push the appropriate bottom-screen menu button to select Level. This enables you to set the trigger level with the general purpose knob. 11. Turn the general purpose knob clockwise very slowly until the trigger level is set to 4.00V.
Page 141 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 4.3. Figure 4.3:Edge triggering Notice that the waveform shown in Figure 4.3 isolates and displays the most positive signal condition that was not visible in Figure 4.2. This is because one pulse width in this repeating complex signal has a higher amplitude.
Page 142: Using Variable Trigger Holdoff
Using TRIGGER Controls Using Variable Trigger Holdoff You can use variable trigger holdoff on a TDS3000 oscilloscope to stabilize a complex repeating signal on the oscilloscope display. The following procedure enables you to set a TDS3000 oscilloscope to trigger on a complex repeating signal. Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure.
Page 143 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 4.4. Figure 4.4: Triggering on complex repeating signals using trigger holdoff In the above procedure, you set a TDS3000 oscilloscope to trigger on a complex repeating signal using trigger holdoff.
Page 144: Assigning Trigger Holdoff For An Am Signal
Using TRIGGER Controls Assigning Trigger Holdoff for an AM Signal Triggering a complex repeating signal at the interval of the signal’s repeat time displays a stable waveform. You may need to analyze the waveform of the amplitude modulation of a complex repeating signal. For example, you might want to analyze the modulation index of a radio frequency transmitter.
Page 145 Using TRIGGER Controls 2. On the Training 1 signal board, push the POWER button until only the Analog PWR light is on. 3. On the top of the front panel, push the SAVE/RECALL menu button. 4. Push the appropriate bottom-screen menu button to select Recall Factory Setup.
Page 146 Using TRIGGER Controls 10. Push the appropriate bottom-screen menu button to select Mode Auto & Holdoff. 11. Push the appropriate side-screen menu button to select Holdoff (Time). 12. At the top of the front panel, turn the general purpose knob clockwise to set the holdoff time to approximately 100us.
Page 147 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 4.5. Figure 4.5: AM signal, with trigger holdoff In this procedure, you stabilized the triggered display of the amplitude modulation region of a complex repeating signal. You did this by assigning a trigger holdoff in the amplitude modulation region of the signal.
Page 148: Summary
• Use the trigger holdoff and level controls to view a stable AM communications signal. Note: TDS3000 and TDS3000B models may be equipped with application modules that provide advanced triggering functions. These capabilities may include special Logic, Pulse, Video, and Communication signal triggering functions.
Page 149: Using Acquire Controls
Using ACQUIRE Controls This module focuses on the ACQUIRE controls of a TDS3000 oscilloscope. This module provides various procedures that you can use to modify a displayed waveform by using the ACQUIRE controls. This module includes the following sections: • Setting Up a TDS3000 Oscilloscope for ACQUIRE Controls •...
Page 150: Setting Up Acquire Controls
Using ACQUIRE Controls Setting Up ACQUIRE Controls Figure 5.1 shows the ACQUIRE controls of a TDS3000 oscilloscope. Figure 5.1: TDS3000 ACQUIRE controls Before you begin using the ACQUIRE controls, you must set up the oscilloscope for operation exercises with the ACQUIRE controls.
Page 151 Using ACQUIRE Controls This section provides a setup procedure for the ACQUIRE controls. This procedure sets the default settings required for procedures with ACQUIRE controls. To set up a TDS3000 oscilloscope for ACQUIRE controls, follow these steps: 1. Connect the CH1 probe tip to the VARIABLE AMPL WITH GLITCH signal on pin 15 and the CH1 ground lead to GND on pin 14 of the Training 1 signal board.
Page 152 Using ACQUIRE Controls 5. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 6. In the TRIGGER section, push the MENU button. 7. Push the appropriate bottom-screen menu button to select Coupling. 8. Push the appropriate side-screen menu button to select HF Reject.
Page 153 Using ACQUIRE Controls 11. Push the appropriate side-screen menu buttons to select Normal. 12. In the VERTICAL section, turn the POSITION knob to position the waveform down to fit the oscilloscope display. 13. In the ACQUIRE section, turn the WAVEFORM INTENSITY knob clockwise for maximum display intensity.
Page 154 Using ACQUIRE Controls 16. In the HORIZONTAL section, turn the SCALE knob counterclockwise to set the displayed timebase to M 200ms. You will see a waveform similar to that shown in Figure 5.2. Figure 5.2: Noisy variable amplitude signal TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 155: Operating Acquire Controls
Using ACQUIRE Controls Operating ACQUIRE Controls You can control how an oscilloscope acquires signals and displays waveforms using the ACQUIRE controls on a TDS3000 oscilloscope. Displaying Hidden Waveform Details Figure 5.2 shows a noisy variable amplitude signal. However, the signal has more details than that are visible on the oscilloscope display.
Page 156 Using ACQUIRE Controls 2. Push the appropriate side-screen menu button to select Peak Detect. 3. Push the SINGLE SEQ button again. You will see a waveform similar to that shown in Figure 5.3. Figure 5.3: Noisy variable amplitude signal with glitches, captured with Peak Detect in SINGLE SEQ mode TDS 3000 Series Oscilloscopes –...
Page 157: Stopping The Acquisition System
Using ACQUIRE Controls In this procedure, you used the Peak Detect acquisition mode to capture glitches with very fast transition times. You can use the Peak Detect acquisition mode to capture fast signal glitches that fall between acquisition samples at slower time base settings. You use the Peak Detect acquisition mode when you need to see high- speed interference that couples into electronic signals.
Page 158 Using ACQUIRE Controls Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To view signal glitches on a TDS3000 oscilloscope without using the SINGLE SEQ acquisition mode, follow these steps: 1. In the ACQUIRE section, push the RUN/STOP button to restart acquisitions.
Page 159 Using ACQUIRE Controls You will see a waveform similar to that shown in Figure 5.4. Figure 5.4: Noisy variable amplitude signal with glitches, captured with Peak Detect mode in an intensity graded display You can see the glitches better by increasing the waveform intensity of the intensity graded display.
Page 160: Using The Average And Envelope Acquisition Modes
Using ACQUIRE Controls Using the Average and Envelope Acquisition Modes You can use the Average acquisition mode to reduce the random noise in a displayed signal by taking an average of multiple waveforms. The Average acquisition mode uses the Sample acquisition mode to acquire data and then takes an average of multiple waveforms to display a final waveform.
Page 161 Using ACQUIRE Controls Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To use the average and envelope acquisition modes to acquire a waveform, follow these steps: 1. Push the appropriate bottom-screen menu button to select Mode Pk Detect.
Page 162 Using ACQUIRE Controls 5. Push the appropriate side-screen menu button to select Average. You can see traces on screen with less noise. 6. In the ACQUIRE section, push the RUN/STOP button. 7. In the VERTICAL section, turn the POSITION knob to move the trace a small amount.
Page 163 Using ACQUIRE Controls 8. In the ACQUIRE section, push the RUN/STOP button to restart the acquisitions. 9. Push the appropriate side-screen menu button to select Envelope. 10. At the top of the front panel, turn the general purpose knob clockwise to set the envelope to Infinity.
Page 164: Step Response
Using ACQUIRE Controls You observed that signal noise is reduced when you shift from the Sample to the Average acquisition mode. When you shift to the Envelope mode, you can see both old and new peak-detected data. This is possible because the Envelope mode accumulates peak-detected waveforms continuously until acquisitions are stopped.
Page 165 Using ACQUIRE Controls The following procedure enables you to check the amount of signal distortion caused by the probe tip and ground lead. To perform the step response demonstration, follow these steps: 1. Connect the CH1 probe tip to the FAST RISE TIME signal on pin 16 and the CH1 ground lead to GND on pin 1 of the Training 1 signal board.
Page 166 Using ACQUIRE Controls 7. In the HORIZONTAL section, turn the SCALE knob clockwise for a time base readout of M 4.00ns. 8. In the TRIGGER section, push the MENU button. 9. Push the appropriate bottom-screen menu button to select Mode Auto & Holdoff. 10.
Page 167 Using ACQUIRE Controls You will see a waveform similar to that shown in Figure 5.7. Figure 5.7: Step response waveform with ground lead Note the large ring caused by the probe tip and the ground lead. The overshoot and ringing in the waveform is caused by the inductance of the probe ground and signal tip leads that interact with the probe and circuit capacitance.
Page 168 Using ACQUIRE Controls To view the step response signal without overshoot and ringing, follow these steps: 1. Pull the probe tip out of the probe tip lead. 2. Unscrew the plastic barrel sleeve from the probe tip and insert the exposed probe tip into the probe socket.
Page 169 Using ACQUIRE Controls You will see a waveform similar to that shown in Figure 5.8. Figure 5.8: Step response waveform, without ground lead and probe tip extension In this procedure, you used the single shot FAST RISE TIME signal on pin 16 of the Training 1 signal board to check the amount of signal distortion caused by the probe tip and ground lead.
Page 170: Summary
Using ACQUIRE Controls Summary In this module, you learned how to perform the following tasks: • Set up a TDS3000 oscilloscope for ACQUIRE controls. • Modify a displayed waveform using the controls of the ACQUIRE section. • Start and stop signal acquisitions. •...
Page 171: Using Menu Function Controls
Using Menu Function Controls This module focuses on the menu function controls of a TDS3000 oscilloscope. In this module, you will learn how to use the menu function controls to measure, save, and modify a displayed waveform. This module includes the following sections: •...
Page 172: Setting Up Menu Function Controls
Using Menu Function Controls Setting Up Menu Function Controls Figure 6.1:TDS3000 front panel menu function controls Before you begin using the menu function controls, you must set up the oscilloscope for operation exercises with these controls. This section provides a setup procedure for the menu function controls.
Page 173 Using Menu Function Controls 3. On the top of the front panel, push the SAVE/RECALL menu button. 4. Push the appropriate bottom-screen menu button to select Recall Factory Setup. 5. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 6.
Page 174: Operating The Menu Function Controls
Using Menu Function Controls Operating the Menu Function Controls In this section, you will learn how to use the menu function controls in combination with the primary control sections to perform various functions, such as measuring a waveform, saving a waveform or a setup, setting factory settings for the oscilloscope, and selecting a display language.
Page 175 Using Menu Function Controls Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To take automatic measurements with a TDS3000 oscilloscope, follow these steps: 1. On the top of the front panel, push the MEASURE menu button.
Page 176 Notice that the average signal frequency is 20.00 MHz and that it updates continuously. 6. Push the appropriate side-screen menu button to select Positive Pulse Width. (On TDS3000B models and non-B models with version 3.13 or later firmware, you will need to advance with –more- to select the appropriate option.)
Page 177 Using Menu Function Controls 9. Push the appropriate side-screen menu button to select -more- until Amplitude appears as a selection on the side-screen menu. 10. Push the appropriate side-screen menu button to select Amplitude. Notice that the average amplitude is about 4.10 V and that it updates continuously.
Page 178 Using Menu Function Controls You will see a waveform similar to that shown in Figure 6.3. Figure 6.3: Automatic measurements Figure 6.3 shows the waveform with the four measurements updating automatically. You can use a TDS3000 oscilloscope to take a maximum of four measurements at a time.
Page 179 Using Menu Function Controls Measuring Two Signals In the previous procedure, you took automatic measurements of an input signal. You can also use the MEASURE menu function controls to measure two signals simultaneously. In the following procedure, you will simultaneously measure two signals by using the MEASURE menu function controls.
Page 180 Using Menu Function Controls 5. In the VERTICAL section, turn the SCALE knob to set Ch2 for 2.00V on the oscilloscope display. 6. Turn the VERTICAL POSITION knob to position the CH2 waveform in the lower half of the oscilloscope display.
Page 181 Using Menu Function Controls You will see a display similar to that shown in Figure 6.4. Figure 6.4: Simultaneous amplitude measurement of CH1 and CH2 Observe that the amplitude of CH2 is displayed along with the three measurements on CH1. TDS 3000 Series Oscilloscopes –...
Page 182 Using Menu Function Controls Verifying an Incoming Signal Sometimes, you may need to verify whether or not an incoming signal has a specified rising edge. Typically, the transition time from a low logic level (0.8 V) to a high logic level (2.0 V) must be 10 ns or less. The following procedure enables you to verify the rising edge of an incoming signal by using the MEASURE menu function controls.
Page 183 Using Menu Function Controls 5. On the top of the front panel, push the MEASURE menu button. 6. Push the appropriate bottom-screen menu button to select Select Measrmnt for CH1. 7. Push the appropriate side-screen menu button to select -more- until Rise Time appears as a selection on the side-screen menu.
Page 184 Using Menu Function Controls 12. On the top of the front panel, use the general purpose knob and the COARSE button to set the High Ref voltage to 2.00V. You use the COARSE button to make large increments with the general purpose knob. If you see the measurement displayed in fV, pV, uV or mV, you need to use the COARSE button in conjunction with the general purpose knob to advance to 2.00V.
Page 185 Using Menu Function Controls You will see a display similar to that shown in Figure 6.5. Figure 6.5: Verifying an incoming signal Rise time is typically measured between the 10% and 90% amplitude levels of a signal. In this procedure, you measured the rise time of the signal between the 0.8 V and 2.0 V levels.
Page 186: Save/Recall Menu Function Controls
Using Menu Function Controls SAVE/RECALL Menu Function Controls You can save and recall instrument setups and waveforms in a TDS3000 oscilloscope. You can use the SAVE/RECALL menu function controls to save and recall up to 10 instrument setups. In addition, the SAVE/RECALL menu function controls allow you to save a waveform from any input channel, MATH, or reference memory location, and save this waveform to one of four nonvolatile memory locations or...
Page 187 Using Menu Function Controls 2. Push the appropriate bottom-screen menu button to select Save Current Setup. Observe that the side-screen menu provides options to save the selected instrument setup to one of the 10 internal setup memory locations or to a floppy disk.
Page 188 Using Menu Function Controls 6. Push the appropriate bottom-screen menu button to select Recall Saved Setup. 7. Push the appropriate side-screen menu button to select Setup 1. You will see a waveform similar to that shown in Figure 6.6. Figure 6.6: Recalled instrument setup 6-18 TDS 3000 Series Oscilloscopes –...
Page 189 Using Menu Function Controls Saving and Recalling a Waveform In the previous procedure, you saved and recalled an instrument setup using the SAVE/RECALL menu function controls. In this procedure, you will save and recall a waveform to/from a reference location by using the SAVE/RECALL menu function controls.
Page 190 Using Menu Function Controls To recall a saved waveform from a reference location, follow these steps: 1. On the top of the front panel, push the SAVE/RECALL menu button. 2. Push the appropriate bottom-screen menu button to select Recall Waveform. 3.
Page 191 Using Menu Function Controls 2. In the VERTICAL section, push the white REF button. 3. In the VERTICAL section, push the OFF button. 4. Push the appropriate bottom-screen menu button to select Ref1 (On). You will see a display similar to that shown in Figure 6.7. Figure 6.7: Recalled reference waveform TDS 3000 Series Oscilloscopes –...
Page 192: Quickmenu Function Control
Using Menu Function Controls QUICKMENU Function Control The QUICKMENU function control enables you to quickly and conveniently access the most frequently used functions of the VERTICAL, HORIZONTAL, TRIGGER, and ACQUIRE sections on the front panel. The following procedure enables you to use the QUICKMENU function control to access frequently used controls.
Page 193 Using Menu Function Controls 4. Push the appropriate bottom-screen menu button to select Fast Trigger. Note that the signal intensity changes when you select Fast Trigger. 5. Push the appropriate bottom-screen menu button to select Mode Avg 16. 6. Push the appropriate side-screen menu button to select Slope to be on the falling edge option.
Page 194 Using Menu Function Controls You will see a display similar to that shown in Figure 6.8. Figure 6.8: QUICKMENU display You can also use the QUICKMENU display to access and change various oscilloscope setup functions that are not directly accessible through the front panel or a single button push.
Page 195: Cursor Menu Function Controls
Using Menu Function Controls CURSOR Menu Function Controls The CURSOR menu function controls allow you to determine the vertical or horizontal waveform voltage/amplitude and time/frequency values. You can use the CURSOR menu function controls to manually select the paired horizontal H Bars (voltage) and vertical V Bars (time) and view their positions.
Page 196 Using Menu Function Controls The following procedure enables you to determine the baseline and delta measurements of both volts and time, when time is selected and voltage is measured. Note: This procedure assumes that the oscilloscope retains the settings from the previous procedure. To determine baseline and delta measurements, follow these steps: 1.
Page 197 Using Menu Function Controls 8. Push the appropriate side-screen menu button to select Bring Both Cursors On Screen. 9. On the top of the front panel, use the general purpose knob to position the active cursor at the topmost point of the waveform. 10.
Page 198: Display Menu Function Controls
Using Menu Function Controls Notice that the vertical cursors provide baseline and delta measurements of both voltage and time, when time is selected and voltage is measured. DISPLAY Menu Function Controls The DISPLAY menu function controls allow you to control how waveforms are displayed on a TDS3000 oscilloscope.
Page 199 Using Menu Function Controls 4. Push the appropriate bottom-screen menu button to select Graticule Full. 5. Push the appropriate side-screen menu button to select Grid. 6. Push the appropriate bottom-screen menu button to select Color Palette Normal. 7. Push the appropriate side-screen menu button to select Monochrome.
Page 200 Using Menu Function Controls Using the Persistence Mode You can use the Persist mode to allow old waveform data to remain visible with the current waveform data on the oscilloscope display. You can use persistence to track infrequent signal anomalies that accumulate in the oscilloscope display.
Page 201 Using Menu Function Controls 5. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 6. In the ACQUIRE section, push the AUTOSET button. 7. In the HORIZONTAL section, turn the SCALE knob counter-clockwise to set the timebase for M 1.00us. 8.
Page 202 Using Menu Function Controls You will see a vector waveform similar to that shown in Figure 6.11. Figure 6.11: Clock signal in vector form 11. On the top of the front panel, push the DISPLAY menu button. 12. Push the appropriate bottom-screen menu button to select Waveform Display.
Page 203 Using Menu Function Controls 13. Push the appropriate side-screen menu button to set Dots Only On. 14. In the ACQUIRE section, push the RUN/STOP button twice. 15. In the VERTICAL section, turn the POSITION knob to reposition the trace. You will see a waveform displayed in dots, similar to that shown in Figure 6.12.
Page 204 Using Menu Function Controls 16. Push the appropriate side-screen menu button to select Persist Time. 17. At the top of the front panel, use the general purpose knob to select Infinite. 18. In the ACQUIRE section, push the RUN/STOP button. 19.
Page 205 Using Menu Function Controls Using the XY Display Mode You can display waveforms in XY or YT formats. When you choose the XY display format, Channel 1 is displayed on the horizontal axis and other channels can be displayed on the vertical axis. When you choose the YT format, the vertical voltage is displayed in relation to time.
Page 206 Using Menu Function Controls 2. Connect the CH2 probe tip to the PHASE SHIFTED SINE WAVE signal on pin 11 and the CH2 ground lead to GND on pin 14 of the Training 1 signal board. 3. On the Training 1 signal board, push the POWER button until only the Analog PWR light is on.
Page 207 Using Menu Function Controls 10. On the top of the front panel, push the DISPLAY menu button. 11. Push the appropriate bottom-screen menu button to select XY Display Off. 12. Push the appropriate side-screen menu button to select Triggered XY. 13.
Page 208 Using Menu Function Controls You can use the XY display format to measure the phase shift between two synchronous signals with a phase difference. In this case, the circle means that the two signals are both sine waves, and that they are 90 degrees out of phase with respect to each other.
Page 209 Using Menu Function Controls 18. In the VERTICAL section, push the CH1 button. 19. Push the appropriate bottom-screen menu button to select Coupling DC. 20. Push the appropriate side-screen menu button to select GND. Notice the vertical line that appears on the oscilloscope display.
Page 210 Using Menu Function Controls 22. In the ACQUIRE section, turn the WAVEFORM INTENSITY knob to vary the intensity of the displayed waveform. The WAVEFORM INTENSITY knob enables you to vary the intensity of the displayed waveform and see the various intensity grading levels. This simulates the intensity graded feature of an analog oscilloscope display.
Page 211: Utility Menu Function Controls
Using Menu Function Controls UTILITY Menu Function Controls The UTILITY menu function controls provide access to the different utilities of a TDS3000 oscilloscope. The UTILITY menu function controls enable you to perform various tasks. These tasks may include changing the display language, setting up the hard copy parameters, or executing diagnostic checks on the oscilloscope functions.
Page 212 Using Menu Function Controls 5. Push the appropriate side-screen menu button to select OK Confirm Factory Init. 6. In the ACQUIRE section, push the AUTOSET button. 7. On the top of the front panel, push the UTILITY menu button. 8. Push the appropriate bottom-screen menu button to select System Config, and then keep pushing the same button until you select System Hard Copy.
Page 213 Using Menu Function Controls 14. Push the appropriate bottom-screen menu button to select Port. 15. Push the appropriate side-screen menu button to select File. 16. Push the appropriate bottom-screen menu button to select Format TIFF. You will see a display similar to that shown in Figure 6.14.
Page 214: Summary
Using Menu Function Controls Summary In this module, you learned how to use the menu options for the following menu function controls: • MEASURE • SAVE/RECALL • QUICKMENU • CURSOR • DISPLAY • UTILITY 6-44 TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 215 You have now completed all chapters of the TDS 3000 Series Oscilloscope Operator Training Kit. Tektronix congratulates you for your work to be a better oscilloscope user.
Page 217 Appendix A Training 1 Signal Board: Signal Definitions Appendix A Training 1 Signal Board: Signal Definitions Following is the regulatory compliance information for the Training 1 signal board. European EC Council EMC Directive Union 89/336/EEC, amended by 93/68/EEC. Demonstrated using: •...
Page 218 Appendix A Training 1 Signal Board: Signal Definitions Figure A1.1 depicts the layout of the Training 1 signal board. Figure A1.1: Training 1 signal board TDS 3000 Series Oscilloscopes – Operator Training Kit...
Page 219 Appendix A Training 1 Signal Board: Signal Definitions Pins 1, 7, 8, and 14 Description These pins provide the ground reference for the Training 1 signal board. Pin 2 CLK 20 MHz Specification 20 MHz digital signal, 4 V peak-to-peak Description This signal is the control clock for all of the digital signals on the Training 1 signal board.
Page 220 Appendix A Training 1 Signal Board: Signal Definitions Pin 5 PSEUDO RANDOM Specification 20 MHz digital clock signal, 3 V peak-to-peak Description This NRZ/OC1 pseudo random signal can be used to show how to trigger on a complex yet repeating signal sequence, such as a communication signal or computer control signal, with the use of trigger holdoff on a TDS200 or a TDS3000 oscilloscope.
Page 221 Appendix A Training 1 Signal Board: Signal Definitions Pin 9 AM SIGNAL Specification Analog signal Frequency: 5 kHz sine wave with 1 MHz carrier Amplitude: 3 V peak-to-peak Description This amplitude modulated signal uses a 5 kHz sine wave signal source and a 1 MHz carrier frequency.
Page 222 Appendix A Training 1 Signal Board: Signal Definitions Description The phase difference between these two 5 kHz sine waves is varied using a potentiometer. The maximum phase shift between the two sine waves is determined by turning the potentiometer to both extremes. This set of signals can be used to demonstrate the phase relationship of two time related signals, such as voltage and current in a power supply, by...
Page 223 Appendix A Training 1 Signal Board: Signal Definitions Pin 15 VARIABLE AMPL WITH GLITCH Specification Analog signal Frequency: 10 Hz Amplitude: Variable between 1 V and 4 V, following sine wave at 0.1Hz rate 20ns asynchronous glitch, 5V amplitude, at 1Hz rate Description This signal is a 10 Hz square wave with an...
Page 224 Appendix A Training 1 Signal Board: Signal Definitions Description This signal is a 100 ns wide 0.6 Volt pulse with a rise time of <2 ns. The signal is generated each time the PRESS FOR SINGLE SHOT button is pressed on the Training 1 signal board.
Page 225 Appendix B Glossary Term Description A mode that blocks the DC component Coupling of a signal but passes the dynamic (AC) component of the signal. Useful for observing an AC signal that is normally riding on a DC signal. Acquisition The process of sampling signals from input channels, digitizing the samples, processing the results into data points,...
Page 226 Appendix B Glossary Autoset A feature that automatically sets the vertical, horizontal, and trigger controls to provide a usable display. Average A mode in which the oscilloscope Acquisition acquires and displays a waveform that Mode is the averaged result of several acquisitions.
Page 227 Appendix B Glossary B Trigger A second trigger that occurs after a given time or number of events from the main A trigger. The B trigger can be used in combination with the A trigger to capture complex events. Complex Combines the characteristics of sine Wave waves, square waves, step waves,...
Page 228 Appendix B Glossary Delay A means to delay the acquisition to start after the trigger event has occurred. The trigger point need not be within a waveform when delay is on. Display The word used to refer to the screen of the oscilloscope.
Page 229 Appendix B Glossary Frequency Represents the number of times a signal repeats itself in one second. The frequency of a signal is measured in Hertz (Hz). Ground Coupling option that disconnects the (GND) input signal from the vertical system. Coupling Ground The ground reference lead for an Lead...
Page 230 Appendix B Glossary Normal A mode where the oscilloscope does Trigger not acquire a waveform record unless Mode a valid trigger event occurs. It waits for a valid trigger event before acquiring waveform data. Peak An acquisition mode that captures Detect spikes and glitches that may occur Acquisition...
Page 231 Appendix B Glossary Phase Shift Refers to the degrees of difference between two similar synchronous signals. Pretrigger The specified portion of the waveform record that contains data acquired before the trigger event. Pulse Wave Represents a sudden change in signal level followed by a return to the original level.
Page 232 Appendix B Glossary Reference A saved waveform selected for Waveform display. You can save and display up to four reference waveforms on a TDS200 or TDS3000 oscilloscope, depending on the model. Rise Time The time taken by a step or pulse to rise from 10% to 90% amplitude level.
Page 233 Appendix B Glossary Sawtooth Has a rising rate of change that is Wave different (faster or slower) from the falling rate of change. Sine Wave Basic waveform that represents voltage change with time. Signals produced by the oscillator circuit in a signal generator are sine waves.
Page 234 Appendix B Glossary TekProbe An interface that communicates Interface information, such as the probe type and its attenuation factor, between a probe and a TDS3000 oscilloscope. The interface also supplies power to active voltage probes. Time Base The set of parameters that let you define the time axis attributes of a waveform record.
Page 235 Appendix B Glossary Video Triggering on the line or field sync Trigger pulses of a composite video signal. XY Format A display format that compares the voltage level of two waveform records point by point. It is useful for studying phase relationships between two waveforms.

This manual is also suitable for:

Tds3000

Tektronix TDS3000B Operator Training Kit Manual

Quick Links

Related Manuals for Tektronix TDS3000B

Summary of Contents for Tektronix TDS3000B

This manual is also suitable for:

Table of Contents
