Reference
Removing Reference Waveforms from the Display.
waveform from the display, select that reference waveform and then
push the Waveform Off button
Scaling and Positioning a Reference Waveform.
scale a reference waveform independently from all other displayed
waveforms. Select the reference waveform and then adjust it with a
vertical or horizontal Position or Scale control. You can do this whether
acquisition is running or is stopped.
If a reference waveform is selected, scaling and repositioning of the
reference waveform operates the same way whether zoom is turned
on or off.
Gray-Scale Restriction.
most current acquisition and do not contain any gray-scale information.
NOTE.
The TDS3AAM Advanced Analysis application module adds new
math features, including arbitrary math expressions, DPO (gray scale)
math waveforms, and FFT analysis.

e*Scope Web-Based Remote Control

With e*Scope, you can access any Internet-connected TDS3000C
series oscilloscope from a browser on your work station, PC, or laptop
computer. No matter where you are, your TDS3000C oscilloscope is as
close as the nearest browser.
There are two levels to e*Scope: basic and advanced. The basic level,
which is hosted on the oscilloscope, lets you view a screen image of the
current acquisition, save or load waveform and setup files, and send
textual control and query commands to the oscilloscope.
The advanced level, which is hosted on your system, provides a
graphical interface to view automatically updated screen images
and to remotely control the oscilloscope. You can access the
www.tektronix.com/software Web page and download the free advanced
e*Scope Web-based Remote Control software.
144
.
Reference waveforms are always saved from the
TDS3000C Series Oscilloscope User Manual
To remove a reference
You can position and
