Thank you for choosing this Icom product.
This product is designed and built with Icom' s state
of the art technology and craftsmanship. With proper
care, this product should provide you with years of
trouble-free operation.
D FEATURES
m Up to 2 channels of operation
You can install a channel extension module (op-
tional UR-FR5000/UR-FR6000) into a repeater. 2
channels can be operated on the same repeater
when a channel extension module is installed.
m Built-in 5-Tone, DTMF encoder & decoder
Multiple signaling systems are built-in as standard.
These systems are fully compatible with Icom F-
series radios.
m DTMF remote control capability
You can control the repeater from a remote location
over the air or over a phone line with DTMF.
m D-Sub 25 pin ACC port equipped
You can use optional equipment through the D-sub
25 pin ACC port on the repeater's rear panel.
m Online control and Digital Trunking opera-
tion
Online control and digital trunking operation are
available when the optional UC-FR5000
network controller
m Other features
- Wide frequency coverage
<VHF>
IC-FR5000 : 136 to 174 MHz
<UHF>
IC-FR6000/IC-FR6000-L
: 350 to 400 MHz,
- PC programmable
- 19 inch rack mount
- Optional Voice Scrambler Unit (UT-109R/
UT-110R) for base operating mode
Icom is not responsible for the destruction or damage
to the Icom transceiver, if the malfunction is because
of:
• Force majeure, including, but not limited to, fires,
earthquakes, storms, floods, lightning, other natu-
ral disasters, disturbances, riots, war, or radioactive
contamination.
• The use of Icom transceivers with any equipment
that is not manufactured or approved by Icom.
i
trunking
is installed in the repeater.
400 to 470 MHz,
450 to 512 MHz,
450 to 520 MHz

IMPORTANT

READ THIS INSTRUCTION MANUAL
CAREFULLY
before attempting to operate the re-
peater.
SAVE THIS INSTRUCTION MANUAL–
manual contains important safety and operating in-
structions for the IC-FR5000/IC-FR6000/IC-FR6000-L
vhf/uhf fm repeaters

EXPLICIT DEFINITIONS

WORD
Personal injury, fire hazard or electric
RWARNING!
shock may occur.
CAUTION Equipment damage may occur.
If disregarded, inconvenience only. No risk
NOTE
of personal injury, fire or electric shock.

SUPPLIED ACCESSORIES

The following accessories are supplied.
/ Handles
DC power cable
(OPC-1784)
DC power cable
2
(CAB-1149)*
Icom, Icom Inc. and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia, Australia,
New Zealand, and/or other countries.
All other products or brands are registered trademarks or
trademarks of their respective holders.
.
DEFINITION
For handles attachment
Spacers
Screws
Function name stickers*
KEY SEAL
* 1 Used for labelling the program-
mable function keys according
to their assinged functions.
2
* Not supplied, depending on
the repeater version.
