IMPORTANT

READ THIS INSTRUCTION MANUAL
CAREFULLY
before attempting to operate the re-
peater.
SAVE THIS INSTRUCTION MANUAL–
manual contains important safety and operating in-
structions for the IC-FR5200H/IC-FR6200H
.
fm repeaters

EXPLICIT DEFINITIONS

WORD
Personal injury, fire hazard or electric
RWARNING!
shock may occur.
Equipment damage may occur.
CAUTION
If disregarded, inconvenience only. No risk
NOTE
of personal injury, fire or electric shock.

SUPPLIED ACCESSORIES

The following accessories are supplied.
Handles
Connector
Function name stickers*
KEY SEAL
Square fuse
(FGB01 30A)
i
vhf/uhf
DEFINITION
For handles attachment
Spacers Hexagon wrench
Screws
For the connector
Screws Holder
1
Rack
1
* Used for labelling the program-
mable function keys according
to their assinged functions.

PRECAUTIONS

R WARNING HIGH VOLTAGE! NEVER
tach an antenna or internal antenna connector during
transmission. This may result in an electrical shock or
burn.
This
R WARNING HIGH VOLTAGE! NEVER
the antenna at any place that person touch the an-
tenna easily during transmission. This may result in an
electrical shock or burn.
R WARNING! NEVER
connector on the repeater rear panel. This could cause
a fire or damage the repeater.
R WARNING! NEVER
to the DC power connector on the repeater rear panel.
This could cause a fire or damage the repeater.
R WARNING! NEVER
cable polarity when connecting to a power source. This
could cause a fire or damage the repeater.
CAUTION: NEVER
touch any internal part or connectors on the rear panel
of the repeater. This may result in an electric shock.
CAUTION: NEVER
snow or any liquids.
DO NOT
operate or place the repeater in areas with
temperatures below –30°C (–22°F) or above +60°C
(+140°F). Be aware that temperatures can exceed
80°C (+176°F), resulting in permanent damage to the
repeater if left there for extended periods.
DO NOT
place the repeater in excessively dusty en-
vironments or in direct sunlight.
DO NOT
put anything on top of the repeater. This will
obstruct heat dissipation.
BE CAREFUL!
operating the repeater continuously for long periods.
BE CAREFUL!
set the repeater's RF output power to less than the
linear amplifier's maximum input level, otherwise, the
linear amplifier will be damaged.
Use Icom microphones only (optional). Other manu-
facturer's microphones have different pin assignments,
and may damage the repeater.
Place the repeater in a secure place to avoid inadver-
tent use by children.
For U.S.A. only
CAUTION:
Changes or modifications to this re-
peater, not expressly approved by Icom Inc., could
void your authority to operate this repeater under FCC
regulations.
apply AC to the DC power
apply more than 16 V DC
reverse the DC power
let metal, wire or other objects
expose the repeater to rain,
The heatsink will become hot when
If a linear amplifier is connected,
at-
install
